- Page 1 Range of Hotplates & Stirrers S T IR H E A H O T o ff P o w o n /o User Guide Version 1.0...
- Page 2 Figure 1 - Front view Figure 2 - Rear view LED heat display Retort Stirrer fitting light ST IR H EA H O T o ff Po w o n /o DIN socket Temperature Power on green light Controller indicator IEC power Power on/off ‘Hot’...
-
Page 3: Electrical Installation
Hotplates & Stirrers Introduction Thank you for purchasing this Cole-Parmer product. To get the best performance from the equipment, and for your own safety, please read these instructions carefully before use. Before discarding the packaging check that all parts are present and correct. This equipment is designed to operate under the following conditions: ❖... -
Page 4: Safety Advice
NOTE: Refer to the equipment rating plate to ensure that the plug and fusing are suitable for the voltage and wattage stated. The wires in the power cable (230V) are colored as follows: BROWN - HOT/LIVE BLUE - NEUTRAL GREEN/YELLOW - EARTH The wires in the power cable (120V) are colored as follows: BLACK - HOT/LIVE WHITE - NEUTRAL... -
Page 5: Operation
Operation Analog Hotplate Models Switch the unit on using the power on/off switch (see Figure 2). The control dial labelled “HEAT” on the front panel controls the heat output and hence the plate temperature. The approximate temperature is indicated visually by LED back-lighting that increases from Green to Red. -
Page 6: Cleaning And Care
Stirring Models Your unit is provided with two 25mm (1 in.) PTFE stirrer bars. These should be placed in the liquid to be stirred. They are suitable for liquid volumes up to 500mL (16 fl oz). Turn ON by turning the dial clockwise from the OFF position. The control dial labelled “STIR”... - Page 7 During cleaning and general operation take care not to scratch the surface of the top plate as this could result in subsequent thermal breakage. WARNING: A ceramic top which is scratched, chipped, chemically etched or damaged must not be used. Metal Top Units: The metal top plate should be cleaned using a damp cloth and a mild detergent solution.
-
Page 8: Troubleshooting
Heating Blocks A complete range of modular heating blocks for heating round bottom flasks is available for use with the metal top hotplates. Please visit the Cole-Parmer website www.coleparmer.com for further information. Troubleshooting Error Codes The following error codes are displayed if the instrument detects an error condition. On the digital models the errors are shown as Er1, Er2 etc. -
Page 9: Warranty
Warranty Cole-Parmer warrants this equipment to be free from defects in material and workmanship, when used under normal laboratory conditions, for a period of three (3) years. In the event of a justified claim, Cole-Parmer will replace any defective component or replace the unit free of charge. This warranty does NOT apply if: ❖ A ceramic top has broken due to mechanical impact, scratching, chipping or chemical etching. -
Page 10: Technical Specification
Technical Specification Stirring Hotplates 230v: 04801-67 230v: 04801-62 230v: 04801-70 230v: 04801-66 120v: 04801-65 120v: 04801-60 120v: 04801-68 120v: 04801-64 Plate material Coated Glass ceramic Coated Glass ceramic aluminum/silicon aluminum/silicon Plate dimensions 150 x 150mm / (6 x 6 in.) all models... -
Page 11: Declaration Of Conformity
These products meet the relevant EC and we cannot guarantee that interference will not occur harmonized standards for radio frequency in practice. Where there is a possibility that injury, interference and may be expected not to damage or loss might occur if equipment malfunctions interfere with, or be affected by, other equipment with due to radio frequency interference, or for general advice similar qualifications. - Page 12 For technical, sales or servicing information, contact: Cole-Parmer 625 East Bunker Court Vernon Hills, IL 60061-1844 Toll-Free: 800-323-4340 Phone: 847-549-7600 Fax: 847-247-2929 www.coleparmer.com...
