GOODWOOD AUDIO Audition Manual

AUDITION

MANUAL

Table of Contents

Need help?

Do you have a question about the Audition and is the answer not in the manual?

Page 1 AUDITION MANUAL...
Page 2 Audition is all about convenience. Do away with having to pull pedals off your board or even pull it all apart just to try a new mono or stereo effect. By using Audition as an insert point you can test out new pedals with absolute ease.
Page 3 Be sure to keep track of left and right. Mounting under an angled pedal board Audition can also be installed under an angled board that has side panel connections. Insert Audition where you want it in your effects chain and connect the send and return jacks to your pedal board’s...
Page 4 FX loop. When using an amp with an FX loop, connect Audition’s SEND to the input of the amp. Connect the amp’s FX loop send to Audition’s RETURN jack. Finally connect the last pedal in the chain to the amp’s FX loop return.
Page 5 Power Pass Through Audition can also be used to pass power from your power supply to the pedal you want to Audition. Audition itself is NOT a power supply for your pedal. Make sure to use centre negative power only.
Page 6 Specs Audition requires no power for audio to pass. Power is required for the LED to work. Dimensions (incl. all jacks and switches): 112mm wide x 64mm deep x 32mm high Weight: 185 grams @goodwoodaudio info@goodwoodaudio.com...
