ComAp InteliMains NT IM-NT-BB Reference Manual page 179

Range [units] 10 .. 30000 [V]
Related FW standard v3.1.0
Force value YES
possible
Description This setpoint is used to adjust the nominal bus voltage (phase to neutral). If
you do not know the phase-neutral nominal voltage, you can adjust the
phase-phase nominal voltage BusNomVph-ph. The controller will then
recalculate the phase-neutral nominal voltage automatically.
N :
OTE
The actual setpoint units and range depend on setting of the Power format in
GenConfig.
N :
OTE
If different voltage on Mains and on Bus is required the following procedure is
required:
Both setpoints
values according to the value of actual Bus nominal voltage. E.g. Bus
nominal is 231 V but Mains nominal is 240 V.
In this case both setpoints need to be adjusted to 231 V and setpoints of
corresponding protections for Mains need to be set assymetrically.
For 240 V on Mains it is typical to open MCB when voltage reaches 254 V or
225 V. Since the setpoint is adjusted to 231 V corresponding protection
setpoints need to be adjusted to
the desired values are reached).
11.2.2.8 Setpoint: BusNomVph-ph
Group Basic settings
Range [units] 17 .. 60000 [V]
Related FW standard v3.1.0
Description This setpoint is used to adjust the nominal bus voltage (phase to phase). This
setpoint is also recalculated automatically when the phase-neutral nominal
voltage
This setpoint can be used if you know the phase-phase nominal voltage only.
The controller will recalculate the phase-neutral nominal voltage
automatically when this setpoint is changed.
N :
OTE
The actual setpoint units and range depend on setting of the Power format in
GenConfig.
N :
OTE
If different voltage on Mains and on Bus is required the following procedure is
NT
InteliMains , SW version 3.2.0
InteliMains-NT-MCB-MGCB-3.2.0-Reference Guide.pdf, ©ComAp – April 2015
(BusNomV and MainsNomV) must be adjusted to the same
Bus >V
BusNomV is changed.
= 106% and Bus <V = 97 % (hence
