- Page 1 Technical description and instruction manual Concept E 450 Digital Active subwoofer CM 2014 SW...
-
Page 2: Table Of Contents
Setup as a PC sound system .......8 Disposal of the unit ..........16 Connecting ..............9 Troubleshooting ............17 Connecting external players ......9 Connection examples ........10 Technical data ............18 Connecting satellite speakers ......11 Connection to the grid ........11 • Concept E 450 Digital... -
Page 3: General Notes And Information
Budapester Strasse 44 cally, mechanically, by photocopy or recording without 10787 Berlin (Germany) the written permission of Lautsprecher Teufel GmbH. Phone 00800 - 200 300 40 (toll-free) © Lautsprecher Teufel GmbH Fax +49 (0)30 / 300 930 930 Version 1, October 2014 E-mail: service@teufelaudio.com... -
Page 4: For Your Safety
• Only use the device in indoor areas. • Never let children use electrical equipment unsu- • Do not operate the device in wet rooms and protect pervised. it from dripping and splash water. • Concept E 450 Digital... -
Page 5: Explanation Of Symbols
This may have psycholog- ical consequences and also cause physical injury. Children and pets are particularly at risk. Set your signal source device volume control to a low setting before turning on the power. • Concept E 450 Digital... -
Page 6: Overview
LED illuminates if 5.1 CH is set as the output (12), but if the input signal con- Pro Logic II sists of fewer channels (the Concept E 450 Digital gener- ates an upmix) VOL – / + Set the volume Switch the device on/to... -
Page 7: Setup Panel
Input jack for the integrated USB sound card LINE IN Analogue 5.1 inputs DIGITAL IN Digital optical input OPTICAL DIGITAL IN Digital RCA input COAXIAL ANALOG IN Analogue stereo input SPEAKER Outputs for satellite speakers • Concept E 450 Digital... -
Page 8: Preparation
PC workstation is advisable, that is, the area where the Surround Surround monitor and listener are located. Set up as PC sound system • Please position the speakers within the grey areas. • Concept E 450 Digital... -
Page 9: Connecting
Connecting external players 1. Pull the mains plug of all devices to be connected out of the socket to prevent accidental activation. 2. Connect the Concept E 450 Digital to your external players as shown in the following examples. • PC: –... -
Page 10: Connection Examples
Coaxial 2 Optical 1 Optical 2 DC +12 V/1A DecoderStation DIGITAL AUDIO OUT COAXIAL AUDIO OUT Sat-Receiver DIGITAL AUDIO OUT COAXIAL CM 2014 SW MP3-Player Smartphone AUDIO OUT OPTICAL DIGITAL AUDIO OUT AUDIO OUT Blu-Ray-Player • Concept E 450 Digital... -
Page 11: Connecting Satellite Speakers
1. The connector terminals SPEAKER OUT (28) for the satellite speakers are located on the back side of the Concept E 450 Digital. Run the speaker cables from the subwoofer to each satellite speaker. -
Page 12: Remote Control
1. Turn the Concept E 450 Digital on. 2. Position the remote control at a distance of no more than 25 cm to the Concept E 450 Digital. 3. Hold the side button (22) down until the LED ring (21) starts to blink and release it. -
Page 13: Functions
Functions • Activating the Concept E 450 Digital: Push the mid- dle of the control dial (20). • Switching the Concept E 450 Digital to standby: Selected input LED illuminates: Push and hold the control dial (20) for 3 seconds. -
Page 14: Bluetooth Pairing
“Teufel Concept E” should appear in the list of the detected devices after the search run. 4. Select the Teufel Concept E from the list of detect- ed devices. Pairing is now complete and your Concept E 450 Digital will now function similar to Bluetooth headphones. -
Page 15: Setting The Volume
(ends at LEFT). 6. Set the optimal volume for each speaker this way. After the subwoofer has been set, the Concept E 450 Digital returns to normal mode. The settings are saved as a result. • Concept E 450 Digital... -
Page 16: Cleaning & Maintenance
Please only turn in batteries and storage batteries which are empty! For this reason, electrical equipment is labelled with the displayed symbol. *) labelled with: Cd = cadmium, Hg = mercury, Pb = lead • Concept E 450 Digital... -
Page 17: Troubleshooting
Playback is noisy. Generally speaking, the Make sure that the external player emits a clear Concept E 450 Digital is a very signal to the Concept E 450 Digital. low-noise system. In most cases, speaker systems with excellent resolution in the high range area expose the poor quality of a sig- nal source (e.g. -
Page 18: Technical Data
You can find further technical data on our website. No responsibility is assumed for the correctness of this information. Technical changes, typographical errors and other errors reserved. This product conforms with Council of the European Union guidelines 2004/108/EC, 2006/95/EC and 1999/5/EC. • Concept E 450 Digital... - Page 19 • Concept E 450 Digital...
- Page 20 Please contact our customer service with any questions, suggestions or criticism: Lautsprecher Teufel GmbH Phone: 00800 - 200 300 40 No responsibility is assumed for the BIKINI Berlin (toll-free) correctness of this information. Budapester Strasse 44 Fax: +49 (0)30 - 300 930 930...
