Technical Description and
Operating Instructions
General notes and information
Proper use
Only use the unit as described in these operating instruc-
tions. Any other use will be deemed as not in accordance with
the instructions and may lead to damage of property or even
persons. The manufacturer accepts no liability for damage
caused by use not in accordance with the instructions. The unit
is intended for private use.
Before operating the speakers please read the safety
notes and operating instructions carefully. This is the
only way to use all functions safely and reliably. Keep
the operating instructions safe and pass them on to anyone
who may own the unit after you.
Notice
The information in this document may change without prior
notice and in no way constitutes any liability on the part of
Lautsprecher Teufel GmbH. No part of these instructions may
be reproduced in any form or be broadcasted in any way elec-
tronically, mechanically, by photocopy or recording without the
written permission of Lautsprecher Teufel GmbH.
Active subwoofer
US 8112/1 SW
Original packaging
If you wish to exercise your eight-week right of return, we ask
that you be absolutely sure to hold onto the packaging. We can
only accept the return of a unit WITH THE ORIGINAL PACKAGING.
Empty boxes are not available!
Complaints
In case of a complaint we implicitly need your invoice number
and the serial or lot number for processing. The serial number
can be found on the back side of the device.
Many thanks for your support!
Contact
For questions, suggestions or any other issues please contact
our customer service department:
Lautsprecher Teufel GmbH
Gewerbehof Buelowbogen
Buelowstrasse 66
10783 Berlin (Germany)
Phone 00800 - 200 300 40 (toll-free)
Fax: +49 (0)30 / 300 930 930
E-Mail: service@teufelaudio.com
www.teufelaudio.com
Advertisement
Table of Contents
Related Manuals for Teufel US 8112/1 SW
Summary of Contents for Teufel US 8112/1 SW
-
Page 1: General Notes & Information
Lautsprecher Teufel GmbH Lautsprecher Teufel GmbH. No part of these instructions may Gewerbehof Buelowbogen Buelowstrasse 66 be reproduced in any form or be broadcasted in any way elec-... -
Page 2: Table Of Contents
Connecting to a power supply .......... 5 Product contents and technical data Product contents 1 Subwoofer US 8112/1 SW Check that all items have been delivered and that nothing is damaged. If you find damage, do not oper- 1 power cord ate the device;... -
Page 3: Safety Notes
Safety notes Caution icons Danger Risk of injury You will find the following caution icons in these instructions: Placing the unit on an unstable surface may cause the unit to tip over and cause serious injury or High risk! Failure to observe the warning may result Danger even death, particularly to children. -
Page 4: Control Elements And Connections
Control elements and connections Item Name Description HP-Filter High-pass filter to fade out low frequencies Volume Subwoofer volume control Set the input sensitivity for the Auto Level automatic activation Line In Audio input jack On/Auto Switch for automatic activation Power control LED Power Overload LED Clip... -
Page 5: Preparation
Center • Avoid placing the unit close to sources of heat or in direct sunlight. US 8112/1 SW • Do not place any heavy objects on the cables or the speak- ers. • The location of the subwoofer can be freely selected and does not influence the other speakers. -
Page 6: Settings And Operation
Settings and operation Activating and deactivating • With the switch 9 “POWER” the subwoofer is activated or deactivated. When the subwoofer is on, the LED 6 “Power” is illuminated in – green, if the subwoofer is in operating mode – red, if the subwoofer is in standby mode. Automatic activation/switching to standby mode •... -
Page 7: Cleaning And Care
Cleaning and care Clean the subwoofer regularly with a soft, damp microfiber Attention Risk of damage! cloth. Please be absolutely sure to observe the following notes Using the wrong cleaning materials may damage in the process: the delicate surface of the case. •... -
Page 8: Protecting The Environment
For separately from household waste, e.g. at a collec- this reason, electrical equipment is labelled with the displayed symbol. Lautsprecher Teufel GmbH Gewerbehof Buelowbogen - Aufgang D1 Phone: 00800 - 200 300 40 Buelowstr. 66, 10783 Berlin (Germany)
