Instruction Guide | OSIT Table
U.S. & Canada (888) 520-4998 | International (801) 875-4998 | www.mti.net
This manual is for the following part numbers:
PART NUMBER
7000010-XXX
7000011-XXX
7000066-XXX
7000067-XXX
DATE
REvISION
5/3/2016
A
DESCRIPTION
OSIT-1000 Instrument Table w/o Tray, Laminate Top
OSIT-1001 Instrument Table w/Tray, Laminate Top
OSIT-2000 Instrument Table w/o Tray, Solid Surface
OSIT-2001 Instrument Table w/Tray, Solid Surface Top
REvISION HISTORy TABLE
CO#/ECO#
CO-0066/EC-0310
WARNING/AVERTISSEMENT
Read this manual before installation and use.
Lisez ce manuel avant l'installation et l'utilisation.
Required Tools
none
DETAILS
Initial release
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MTI OSIT-1001
Summary of Contents for MTI OSIT-1001
- Page 1 Instruction Guide | OSIT Table U.S. & Canada (888) 520-4998 | International (801) 875-4998 | www.mti.net WARNING/AVERTISSEMENT Read this manual before installation and use. Lisez ce manuel avant l’installation et l’utilisation. Required Tools none This manual is for the following part numbers:...
- Page 2 Instruction Guide | OSIT T able OPERATION Positioning the Table The table rolls over the foot/seat of most chairs. (Figure 3). However, the OSIT table does not fit over any Raising and Lowering the Table chair with a “Low-Boy” Mobile Base. On a 440 Mobile Loosen the handles on each side of the table located Stretcher Bed, the OSIT casters and the bed casters on the posts by twisting counter clockwise.
- Page 3 Instruction Guide | OSIT T able EXPLODED vIEwS 7000010-XXX OSIT-1000 INSTRUMENT TABLE w/O TRAy, LAMINATE TOP PART NUMBER DESCRIPTION 032101 PHP SCREW, 1/4-20 x 1 ZINC 037007 HANDLE, ADJ CLAMP, 3/8-16X2.48,3-1/6" HANDLE 043142 THRUST BEARING, 3/8 ID x .812 OD x .078 THK 045032 SAE WASHER, 3/8 ZINC 045148...
- Page 4 Instruction Guide | OSIT T able 7000011-XXX OSIT-1001 INSTRUMENT TABLE w/TRAy, LAMINATE TOP PART NUMBER QTY DESCRIPTION 032050 6 PHP SCREW, 8-32 x 1/4 ZINC 032054 8 PHP SCREW, 8-32 x 1/2 ZINC 032101 6 PHP SCREW, 1/4-20 x 1 ZINC 037007 2 HANDLE, ADJ CLAMP, 3/8-16X2.48,3-1/6"...
- Page 5 Instruction Guide | OSIT T able 7000066-XXX OSIT-2000 INSTRUMENT TABLE w/O TRAy, SOLID SURFACE PART DESCRIPTION NUMBER 032101 PHP SCREW, 1/4-20 x 1 ZINC 037007 HANDLE, ADJ CLAMP, 3/8-16X2.48,3-1/6" HANDLE 043142 THRUST BEARING, 3/8 ID x .812 OD x .078 THK 045032 SAE WASHER, 3/8 ZINC 045148...
- Page 6 Instruction Guide | OSIT T able 7000067-XXX OSIT-2001 INSTRUMENT TABLE w/TRAy, SOLID SURFACE TOP PART DESCRIPTION NUMBER 032050 6 PHP SCREW, 8-32 x 1/4 ZINC 032054 8 PHP SCREW, 8-32 x 1/2 ZINC 032101 6 PHP SCREW, 1/4-20 x 1 ZINC 037007 2 HANDLE, ADJ CLAMP, 3/8-16X2.48,3-1/6"...
-
Page 7: Specifications
Holder hang on the side of the table. Special Color Counter top Customer chosen counter top color Contact MTI for quote on availability and additional costs. CAUTION/PRÉCAUTION WARNING/AVERTISSEMENT Do not leave any moisture on any part of the table for an No modification of this equipment is allowed. -
Page 8: Limited Warranty
MTI or its authorized agents indicates the product has been repaired or website. In the U.S. & Canada, call (888) 520-4998, or altered in any way by persons other than MTI or its authorized agents, has International, call (801) 875-4998 to request a copy.
