- Page 1 PORTACOOL OWNER’S MANUAL FOR PAC2K482S, PAC2K363S, PAC2K361S, PAC2K36HPVS, PAC2K24HPVS and PAC163SVT...
-
Page 2: Table Of Contents
EXPLODED VIEWS ..............pages 16-20 GENERAL OPERATION ............... pages 9-10 WIRING DIAGRAM ................page 21 MAINTENANCE AND STORAGE ............page 11 FREQUENTLY ASKED QUESTIONS ..........page 22 STOP DO NOT RET URN ! For questions or comments, please call Portacool Customer Service at 936-598-5651. - Page 3 QUICK SET UP Remove box and palette Position product on level surface Plug into appropriate outlet Fill sump or attach water hose For setup, pads should appear wet before starting the fan. Check the water gauge to monitor water level in tank.The water ow valve on each unit is set at max ow.
- Page 4 16" VERTICAL TANK OVERVIEW PAC163SVT This unit does NOT have a hose fill option. Control Panel Water Adjustment Valve Cord Wrap Electrical Plug Manual Fill Water Gauge Locking Drain Casters Plug...
- Page 5 24" HP OVERVIEW Control Panel Water Adjustment Valve Hose Connection Flap Locking Electrical Casters Plug...
- Page 6 36" OVERVIEW PAC2K36HPVS Control Panel Water Adjustment Valve Cord Wrap Electrical Hose Plug Connection Locking Casters...
- Page 7 48" OVERVIEW PAC2K482S Control Panel Water Adjustment Valve Cord Wrap Hose Connection Electrical Plug Locking Casters...
-
Page 8: Safety Information
• Never wash the evaporative cooler cabinet with a garden hose; water may harm the motor and electrical system. • If the product is damaged or malfunctions, do not continue to operate it. Refer to the warranty, troubleshooting or FAQ section, call Portacool, LLC, Technical Support at... -
Page 9: General Operation
OPERATING PROCEDURES Each Portacool evaporative cooler has its own set of operational specifications, sizes, weights, voltage fre uency, current re uirements, etc. Please ask for the specifications for your model from your distributor, check the serial number plate, or visit www.portacool.com for the specifications for your product. - Page 10 This is a normal condition, as the cooling pads re uire a large amount of water for proper wetting. When the Portacool evaporative cooler is new, the new pads will re uire an initial breaking-in period. This period is re uired for the pads to begin readily absorbing water. It may re uire up to a week to achieve maximum efficiency.
-
Page 11: Maintenance And Storage
MAINTENANCE & STORAGE MAINTENANCE 1) Keep the product clean to ensure peak operating performance. 2) The rugged, corrosion-resistant construction ensures low maintenance will be re uired. However, in dusty or dirty environments, optional filters are available from your distributor or at www.portacoolparts.com. The pump should be turned off approximately 15 minutes before the fan is turned off. -
Page 12: Troubleshooting
TROUBLESHOOTING The Portacool evaporative cooler consists of three systems — the fan system, the electrical system, and the water system. It is important to determine with which of the systems the problem is associated. Certain problems may be associated with more than one system. A careful check of all systems should be made to fully understand the extent of the problem. - Page 13 The following troubleshooting guide is intended to address the most common symptoms which may occur. If you are unable to resolve the issue, please call Technical Support. Turn off all power to the evaporative cooler before attempting to troubleshoot any of the following symptoms. SYMPTOM POSSIBLE CAUSES REMEDY...
- Page 14 If the E uipment and/or its original component parts develop a defect covered by this limited warranty within the applicable time periods described above, the same will be repaired or replaced at Portacool s option. In the case of a breach of any implied or written warranty relating to the E uipment and/or its component parts, Portacool shall not be liable for any incidental or conse uential damages, and the limits of liability against Portacool for any such breach shall not exceed the cost of replacement or repair of the E uipment.
- Page 15 2. The defective part need to be returned to Portacool, LLC, labeled with the RMA number within 90 days of receipt of replacement parts. 3. The customer / distributor can call Tech Support to get an RMA number to send the defective part back to Portacool, LLC. Once the part is received by Portacool, a replacement part will be sent at no charge.
- Page 16 16" VERTICAL TANK PARTS PART # DESCRIPTION PART # DESCRIPTION BONNET-03 SPRAY BAR BONNET PRES-REG-01 WATER PRESSURE REGULATOR BOX-UL-01 3 SPD ELECTRICAL BOX PUMP BRACKET PLASTIC PUMP COVER/BRACKET CLAMP-01 1/2” CLAMP FOR PLASTIC TUBE PUMP-0150-1 PUMP 1/70HP W/NETTING CTRL-3SPD-02 3-SPD HARNESS W/SALZER PVC-ADP-01 3/4 X 1/2 ADAPTER SWITCH...
- Page 17 16" VERTICAL TANK PARTS PART # DESCRIPTION PART # DESCRIPTION 10FT POWER CORD W/STRAIN RELIEF/ BASE-JS/VT CASTER BASE ASSEMBLY FOR JS/VT POWERCORD-03F NUT/WASHER BONNET-03 SPRAY BAR BONNET FOR 16” PAC PAD6024/G 16” PAC REPLACEMENT PAD BOX-UL-01 3SPD ELECTRICAL BOX POLY-FTG-06 90DEG FITTING FOR SIGHT TUBE CASTERS-HD-4 4”...
- Page 18 24" HIGH PERFORMANCE PARTS PART # DESCRIPTION PART # DESCRIPTION BASE-2K24 CADDY LOCKNUT-FNG-516 5/16-18 FLANGE NYLON INSERT LOCK NUT BLADE-ASSM-02 VOSTERMAN 24” FAN BLADE ASSY. (33deg.) PAC-PLB-01 BRASS INLET FITTING BONNET-02 SPRAY BAR BONNET FOR 24” PAC PAC-PLB-02 BLACK PLUMBING ASSEMBLY BOX-UL-03 VARIABLE SPEED ELECTRICAL BOX PAD6036/G...
- Page 19 36" SINGLE-SPEED PARTS PART # DESCRIPTION PART # DESCRIPTION BASE-2K36 CADDY MOTOR-MNT-01 MOUNT FOR 36” MOTOR BEARING-FAN-01 BEARING FOR 24” & 36” PAC N-516-NYLOK 5/16” NYLOCK NUT FOR CASTERS BELT2K-38-01 A-38 FAN BELT PAC-PLB-01 BRASS INLET FITTING BONNET-01 SPRAY BAR BONNET PAD6048/G PAD FOR 36”...
- Page 20 36" THREE-SPEED PARTS PART # DESCRIPTION PART # DESCRIPTION BASE-2K36 CADDY MOTOR-MNT-01 MOUNT FOR 36” MOTOR BEARING-FAN-01 BEARING FOR 24”/36” FAN BLADE ASSEMBLY N-516-NYLOK 5/16” NYLOCK NUT FOR CASTERS BELT2K-38-01 A-38 FAN BELT PAC-PLB-01 BRASS INLET FITTING BONNET-01 SPRAY BAR BONNET PAD6048/G PAD FOR 36”...
- Page 21 36" VARIABLE SPEED PARTS ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION BASE-2K36 CADDY MOTOR-012-05 1/2 HP DIRECT DRIVE VOSTERMAN MOTOR BLADE-ASSM-01 VOSTERMAN 36” FAN BLADE ASSEMBLY N-516-NYLOK 5/16-18 NYLOK NUT BONNET-01 SPRAY BAR BONNET FOR 36” PAC PAC-PLB-01 BRASS INLET FITTING BOX-UL-06...
- Page 22 48" TWO-SPEED PARTS PART # DESCRIPTION PART # DESCRIPTION BASE-2K48 CADDY N-516-NYLOK 5/16-18 NYLOK NUT FOR CASTERS BELT2K-45-01 A-45 FAN BELT PAC-PLB-01 BRASS INLET FITTING BONNET-04 SPRAY BAR BONNET PAC-PLB-02 BLACK PLUMBING ASSEMBLY BOX-UL-02 2 SPD ELECTRICAL BOX PAD6060/G PAD FOR 48” PAC (6 per unit) BRACE-48-03 BRACE FOR BONNET POWERCORD-01F...
-
Page 23: Wiring Diagram
VARIABLE SPD WIRING DIAGRAM... - Page 24 ONE-SPEED WIRING DIAGRAM...
- Page 25 TWO-SPEED WIRING DIAGRAM...
- Page 26 THREE-SPEED WIRING DIAGRAM...
-
Page 27: Frequently Asked Questions
THERE’S AN UNPLEASANT ODOR! A. Replacement parts may be purchased from any Portacool product distributor or A. The pads, located in the back of your Portacool product, have never been wet directly from Portacool Parts/Technical Support department. You may also visit www. - Page 28 1-936-598-5651 • 1-888-COOLAID SUPPORT@PORTACOOL.COM VISIT PORTACOOL.COM MANR0003 OR CALL 1-936-598-5651 FOR MORE INFORMATION Portacool, LLC • Manufacturer of Portacool™ portable evaporative coolers and KÜÜL® Pads evaporative media 709 Southview Circle • Center, Texas 75935 • 936-598-5651 • www.portacool.com • www.kuulpads.com...
