Summary of Contents for Portacool PAC163SVT
- Page 1 PORTACOOL CLASSIC OWNER ’ S MANUAL PAC163SVT, PAC161SVT, PAC2K36HPVS, PAC2K361S, PAC2K482S, PAC2K481S * Applies to all 120 and 240V products for global configurations...
-
Page 2: Quick Setup
Remove product from packaging Position on level surface Fill tank or attach water hose Plug into appropriate outlet Your Portacool portable evaporative cooler is meant For setup, KUUL Comfort evaporative media should to be used in an open-air environment, such as a appear wet before starting the fan. -
Page 3: Operation Warnings
Remove the plug from the electrical receptacle by pulling on troubleshooting or FAQ sections of this owner’s manual, call the plug, not the power cord. Portacool, LLC Customer Service at (936) 598-5651 or • Operation near open flames or sparks is not recommended. - Page 4 OVERVIEW ™ PORTACOOL CLASSIC 48” TWO SPEED Serial plate Control panel ™ KUUL Comfort evaporative media Water adjustment valve Power cord Drain valve with GFCI Hose connection Casters...
- Page 5 OVERVIEW ™ PORTACOOL CLASSIC 48” ONE SPEED *Sold only through select distributors Serial plate Control panel ™ KUUL Comfort evaporative media Water adjustment valve Drain valve Power cord with GFCI Hose connection Casters...
- Page 6 OVERVIEW ™ PORTACOOL CLASSIC 36” VARIABLE SPEED Serial plate Control panel ™ KUUL Comfort evaporative media Water adjustment valve Drain valve Power cord with GFCI Hose connection Casters...
- Page 7 OVERVIEW ™ PORTACOOL CLASSIC 36” ONE SPEED Serial plate Control panel ™ KUUL Comfort evaporative media Water adjustment valve Drain valve Power cord Hose connection with GFCI Casters...
- Page 8 OVERVIEW ™ PORTACOOL CLASSIC 16” THREE SPEED ™ KUUL Comfort evaporative media Serial plate Water adjustment Control panel valve Power cord with GFCI Casters Drain located in back...
- Page 9 OVERVIEW ™ PORTACOOL CLASSIC 16” ONE SPEED *Sold only through select distributors ™ KUUL Comfort evaporative media Serial plate Water adjustment Control panel valve Power cord with GFCI Casters Drain located in back...
- Page 10 The GFCI on these models will automatically reset when the evaporative cooler is plugged into an electrical outlet. If the GFCI is tripped and a simple “reset” will not work, please contact the Portacool Customer Service at (936) 598-5651 or (800) 695-2942 for more troubleshooting information.
-
Page 11: Starting The Pump And Adjusting The Water Flow
When turning the evaporative cooler off at the end of the day or week, the pump should be turned off about 15 minutes before the fan to allow the KUUL evaporative media to dry. STARTING THE PORTACOOL EVAPORATIVE COOLER Start the fan by turning the fan switch to either the high or low position. Before starting your evaporative cooler, make sure any... -
Page 12: Daily Maintenance
WEEKLY MAINTENANCE Your Portacool portable evaporative cooler should be shut down, disconnected from power and the tank should be drained once a week by removing the drain cap. Once the tank is drained and the power disconnected, the KUUL evaporative media may be removed to allow cleaning of the tank, where dust may collect over time. -
Page 13: Troubleshoot
TROUBLESHOOT Turn off all power to your evaporative cooler before attempting to troubleshoot any of the following symptoms. For problems not listed, please contact Customer Service. REMEDY SYMPTOM POSSIBLE CAUSES 1. Check power Evaporative cooler fails to 1. No electricity to the evaporative cooler A. - Page 14 TROUBLESHOOT REMEDY POSSIBLE CAUSES SYMPTOM 1. Drain, flush and clean tank 1. Stale or stagnant water in tank Musty or unpleasant odor 2. Replace KUUL evaporative media 2. KUUL evaporative media is mildewed or clogged 1. Make sure KUUL evaporative media 1.
-
Page 15: Warranty
Portacool replacement parts; iii) the product has been modified in any way (other than repairs made by qualified individuals with Portacool replacement parts); iv) the product has not been appropriately registered by its original purchaser;... - Page 16 PORTACOOL PROTECT Portacool, LLC is proud to provide world-class service and support. Portacool Protect™ brings together our commitment to service and support in the form of best-in-class warranties, service programs, technical support and live customer service to provide our customers with an ownership experience that is second to none.
- Page 17 Q. What assembly is required? Q. How often should my KUUL Comfort evaporative media be A. None. Portacool Classic evaporative coolers are ready to use right replaced? out of the box. A. Depending on the quality of maintenance and frequency of use, KUUL Comfort evaporative media typically last up to five years.
- Page 18 EVAPORATIVE MEDIA Step 1 Be sure to unplug your Portacool portable evaporative cooler before doing any maintenance. When present, lock the casters to keep your evaporative cooler from moving while you are working. Remove the flap and KUUL Comfort evaporative media from the evaporative cooler.
- Page 19 CONTROLS PAC-CVR-03 PAC-CVR-01 PAC-CVR-01 PAC-CVR-04 COVER HARD WATER PARPACHWTB00 PARPACHWTB00 PARPACHWTB00 PARPACHWTB00 TREATMENT Additional parts can be found at www.portacoolparts.com For products sold outside North America, contact Customer Service at 800-695-2942 or email support@portacool.com for item numbers and product availability.
- Page 20 NOTES...
- Page 21 NOTES...
- Page 22 NOTES...
- Page 23 NOTES...
-
Page 24: Customer Service Contact
Le manuel est disponible en d’autres langues. Pour télécharger une copie numérique, se il vous plaît visitez www.portacool.com. VISIT PORTACOOL.COM OR CALL 1-936-598-5651 FOR MORE INFORMATION Portacool, LLC • Manufacturer of Portacool ® portable evaporative coolers and MANR0015 KUUL evaporative media ®...
