- Page 1 JKTLI 130226 TELEPHONE LINE INTERFACE FOR JK SYSTEM WITH VOICE MESSAGES AIPHONE GB356 - 31.08.11– Edition notice V1.0...
- Page 2 AIPHONE 31.08.11 – V1.0...
- Page 3 [4] Power supply (230V 50Hz European plug) JKTLI can be installed: - put down on a furniture or - wall mounted (use for example two screws type M3,5). JKTLI must be installed as far as possible from humidity or heating source AIPHONE 31.08.11 – V1.0...
- Page 4 - Power supply 12VDC +/- 10% linear regulated: internal connection + (12VDC), external connection - (0V) (Consumption: 350mA in work), installed not far from 3 meters from JKTLI. - Connection with JK1MED: - connect B1 from JK1MED to B1 of JKTLI,...
- Page 5 We propose here a few examples depending on the existing installation, one telephone set, two to three telephone sets, XDSL Box or with a Pabx. WARNING: JKTLI accepts a maximum of 3 telephone sets. 2.1 – Installation with one telephones set...
- Page 6 2.2- Installation with two telephones sets From telephone provider socket (can be RJ plug or other special plug) Connecting box * LINE RJ/RJ cable RJ/RJ cable RJ/RJ RJ/RJ cable cable LINE JKTLI * Connecting box provided on request (reference: 902991) AIPHONE 31.08.11 – V1.0...
- Page 7 2.3 – Installation with three telephones sets To wall mounting socket from telephone provider RJ/RJ cable RJ/RJ cable LINE JKTLI 2.4 – With XDSL Box which includes an analog port: To wall socket from Internet provider Analog port RJ/RJ cable RJ/RJ...
- Page 8 2.5 - With PABX CO line 2 wires PABX Telephone B1 Analog port Telephone B2 RJ/RJ cable RJ/RJ cable Telephone B3 LINE JKTLI AIPHONE 31.08.11 – V1.0...
- Page 9 Red Led lighting means power on POWER : Programming switch LOCAL PROG : Programming by using internal ON : OFF : telephone set JKTLI is activated JKTLI is out of service AIPHONE 31.08.11 – V1.0...
- Page 10 JKTLI allows connecting a doorphone type JK-DV using a internal JK-1MED (which is installed at the door entry of an home) to the internal telephone set of the home or to the external telephone line of this villa. The communications with the internal house phone are free of charge; Calls with external parties will be charged depending on telephone provider.
-
Page 11: Table Of Contents
3.4 SPECIAL ROGRAMMATIONS ........18 3.4.1 Communication ends after activation of JK relay ..18 3.4.2 Communication ends after activation of JKTLI relay .. 3.4.3 Call Notification when Telephone is busy ..... 18 3.4.4 Type of ringing signal on internal phone ..... 18 3.4.5 Ringing time before answering ...... - Page 12 QUICK PROGRAMMING AIPHONE 31.08.11 – V1.0...
-
Page 13: Quick Programming
3 Quick Programming JKTLI is programmed via any one of the house telephones (DTMF) or remotely via a touch-tone (DTMF) telephone (GSM for example). 3.1 Programming Access Local Remote programming programming via via Touch Tone house telephone (DTMF) Telephone Dial the telephone number... - Page 14 JKTLI confirms by emitting 3 short beeps and goes on idle mode. Notes : A maximum of 10 seconds are allowed for each programming input - if exceeded, JKTLI reverts to standby mode. No programming entries are possible when JKTLI is emitting acknowledgement beeps..
-
Page 15: Minimal Programming
3.2 Minimal programming In the delivery of your JKTLI, here is its functioning (you can use it directly if you don’t use the transfer function): The following 4 programming must be entered. This allows a quick using of JKTLI. You can pass directly to paragraph 3.2.3 if the default parameters suit you. -
Page 16: Remote Control (Relay)
Example: time required is 9 seconds * 2000 # (3 short beeps) 31 (long beep) 09 (3 short beeps) 3.3.2 Remote control for JKTLI relay Default door release code = 20 Programming DTMF Code for activating the relay – Function 30: From the handset called ie to activate the relay, the person answering the call must enter a 2 digit(s) code on the keypad of the handset. - Page 17 SPECIAL PROGRAMMING AIPHONE 31.08.11 – V1.0...
-
Page 18: Special Rogrammations
Default setting = 1 = Voice message. JKTLI can be programmed to notify that there is a call from the panel when the telephone is busy. * 2000 # (3 short beeps) 43 (long beep) 0 (3 short beeps) = Notification via beep. -
Page 19: Country Selection
Ireland, 32 = Belgium, 33 = France, 34 = Spain, 39 = Italy, 41 = Switzerland, 44 = UK, 49 = Germany, 61 = Australia, 86 = China.). Example: JKTLI used in Australia * 2000 # (3 short beeps) 05 (long beep) 61 (long beep) This procedure does the following programming: - choose basics parameters (as function 29) : tones, call-numbers,…... -
Page 20: External Communication Level
This programming can be done automatically when connected behind a Pabx. This programming can be done manually when connected behind a Pabx or on a public telephone line. At delivery time, JKTLI is programmed to recognize the country tones. 3.5.1 Switching modes into communication with external telephone – Function 95... -
Page 21: Disconnect After Silence Of Or Continuous Signal Of Xs
Default setting = 3. JKTLI can be programmed to pause from 1 – 6 seconds before dialling. A pause can also be included in the phone number (ie if JKTLI is installed on an extension port of a Pabx). * 2000 # (3 short beeps) 98 (long beep) X (3 short beeps) With X = time in seconds, from 1 to 6 seconds. -
Page 22: Programming The Tones Manually
(*) these values are basically programmed into the system and can be reminded when doing a RESET. if there is no EOC tone or if the EOC tone is continuous (no OFF signal), enter 000 for IMPORTANT: the 4 values of this tone. AIPHONE 31.08.11 – V1.0... -
Page 23: Audio Messages
Message 10: ‘Routing off’ Message 11: ‘Your call is in progress’ Note: if the installation includes a JKDEL module, we recommend to disable message 2 on JKTLI. To do that, proceed as below: * 2000 # (3 short beeps) 41 (long beep) 02 (long beep) 0 (3 short beeps) -
Page 24: Programming Parameters Summary
Command of JKTLI relay 2 digits Operating time for JK-1MED 3.3.1 01 second to 10 seconds relay 3.3.2 Operating time for JKTLI relay 01 second to 10 seconds 0:Communication continue 1-0: communication ends immediately after activation Communication ends for 3.4.1... - Page 25 Default Password Code Chapitre Function Parameters value JKTLI activated after a call 3.2.1 Reactive Call-Button from Door Panel 3.2.1 Disabling Call-Button JKTLI disabling Ringing duration of internal 3.2.2 From 10 to 45 seconds house phone 3.2.3 External Call number Max 16 chiffres + “#”...
-
Page 26: Basic User Operation
Note 2: Exactly the same applies for Relay n° 2 which might be used to open a second door or a pedestrian gate or turn on camera or turn on lights or…. (Relay n°2 is installed on the JKTLI card). -
Page 27: Mode Selection
The selector 3 positions is on ‘ON’ and the transfer mode is reactived. In this mode, if the visitor presses the Call-button, JK-1MED panel rings and after 10 seconds it stops and the external telephone set rings. AIPHONE 31.08.11 – V1.0... - Page 28 #** to reactivate the Call-button. The caller hears 3 short beeps. No answer Mode To deactivate the JKTLI system, from an external telephone set, call the JKTLI, dial #00 in the eight first seconds. From now, for the next call, JKTLI does not answer.
-
Page 29: Quick Programming
30 long beep (DTMF code for activating the relay) # “The code entered is correct” then 00 to exit. Operating time of the relay 2 (on JKTLI) *2000# “The Code entered is correct” 32 long beep (operating time in seconds) “The code entered is correct” then 00 to exit. -
Page 30: Main Parameters Of The Installation
End of communication after activation of relay 1 (on JK-1MED) End of communication after activation of relay 2 (on JK-1MED) Default Value Installation Parameters Programming Password 2000 Call-Button Programming Password 2001 Phone Number of JKTLI: S/N of JKTLI : AIPHONE 31.08.11 – V1.0... -
Page 31: Default Parameters
During the final test in factory, or after a reset by function 29, the following parameters are programmed: - External Call number - Ringtone for Call from Door Panel 1,5s / 3,5s - Automatic pause prior dialling - Ringing tone Country settings - Busy tone Country settings AIPHONE 31.08.11 – V1.0... -
Page 32: Revision Notes For Panel Functions
Press 10 and hang up. From internal telephone set : Answer to visitor, Press 20 and hang up. OPENING CONTACT OF JKTLI CARD DURING COMMUNICATION From external telephone set: Answer to visitor, Press 20 and hang up. From internal telephone set : - Handset off hook, - Disabling ‘transfer mode’... -
Page 33: Technical Precautions
Standards: EN60950 EN55022 Edition 98 Classe B EN55024 Edition 98 Classe B CTR21 Programming: Local or remotely via a Touch-tone (DTMF) telephone. System Capacity: 1 call-number (16 figures maximum per call-number). No-volatile Memory: Material ABS module AIPHONE 31.08.11 – V1.0... -
Page 34: First Aid
‘CO LINE’. Re-program the call number (see 3.2.3). Inopportune switching in communication when * JKTLI is installed on an internal line of a the external number is called. PABX: tones are different from those basically programmed in JKTLI. Please contact AIPHONE HOT LINE to do an automatic programming of the tones. - Page 35 AIPHONE 31.08.11 – V1.0...
-
Page 36: Warranty
Distributed by AIPHONE Printed in France AIPHONE 31.08.11 – V1.0...
