Summary of Contents for Aiphone JPTLIIP
- Page 1 JPTLIIP VoIP INTERFACE FOR JP SYSTEM INSTALLATION MANUAL AIPHONE 13.08.2015-V1.2...
- Page 2 13.08.15 – V1.2 AIPHONE...
- Page 3 Contenu de l’emballage : [1] Installation manual [2] User manual [3] JPTLIIP cabinet [4] Power supply [5] Fast installation manual JPTLI can be installed: - on desktop or - wall mounted (use for example two screws type M3,5). JPTLI must be installed as far as possible from humidity or heating source.
- Page 4 1 blinking all the seconds Correct functioning 3 blinking all the seconds JPTLIIP did not find an IP address (DHCP did not work). JPTLIIP started with an address 192.168.0.100 4 blinking all the seconds JPTLIIP has no connection with server proxy...
- Page 5 1 – JPTLIIP wiring JPTLIIP See wiring method of JPTLIIP Power supply 12VDC / 0,5A Door lock: 12VDC / 2A 24VDC / 1A NO: normally open C: common NC: normally closed PT: Power Transformer 13.08.15 – V1.2 AIPHONE...
- Page 6 It can have several type of installation of JPTLIIP. 2 – Physical connection 2.1- Behind Box or modem router (livebox, freebox, …) Connect JPTLIIP directly on box or modem router with Ethernet straight cable (not supplied). 13.08.15 – V1.2 AIPHONE...
- Page 7 If no port Ethernet is available on your equipment, you will have to add a Switch 10/100Mbits/s (multiport Ethernet). 13.08.15 – V1.2 AIPHONE...
- Page 8 Go to 4 (connection via the proxy). If DHCP does not work, JPTLIIP is automatically with a fixed IP address (192.168.0.100). In this case, it is necessary to verify if JPTLIIP is in the same sub-network as our PC: ...
- Page 9 ) on the toolbar then choose “Network and Sharing Center”. Click on ‘Ethernet’. In the box of properties of the connection to the LAN, choose the object «Internet Protocol Version 4 (TCP/IP) » and click on ‘Properties’. 13.08.15 – V1.2 AIPHONE...
- Page 10 Enter an IP address in the range of JPTLIIP address by default: 192.168.0.X (where X is a number between 1 and 254, here in our example 32) and use 255.255.255.0 for the mask of sub-network. 4 –JPTLIIP setting: Launch your web browser (Internet Explorer, Firefox, …) and in the address field of browser, enter ‘http://vps37790.ovh.net/login.php’.
- Page 11 Enter the password of JPTLIIP, specified on the sheet of fast installation joined with JPTLIIP. The welcome screen of JPTLIIP appears: The screen gives us information onto the state of the connections with the proxy and with the server Astérisk To modify the operating parameters of JPTLIIP, click 'Parameters'.
- Page 12 In this menu we can choose to use the product in dynamic IP (active DHCP) or static IP. By using the choice static IP, it is afterward simpler to connect in local with the Internet browser (always the same IP address). 13.08.15 – V1.2 AIPHONE...
- Page 13 With application « Barcode Scanner » (for example on the box and/or in the manual), the Smartphone goes directly on the corresponding store (Android or IOS). b. Without application, go to the store and search application « AiphoneJP » 2- Open the software 13.08.15 – V1.2 AIPHONE...
- Page 14 3- Welcome screen Click on ‘Tools’. 4- Automatic entry 5- Manual entry User name : fr140801_1 or fr140801_2 Password : specified on Fast installation manual Domain : vps37790.ovh.net And click on ‘Apply’ 13.08.15 – V1.2 AIPHONE...
- Page 15 Stand-by 350mA, when relay is on 430mA. Standards: EN60950 EN55022 Edition 98 Classe B EN55024 Edition 98 Classe B Exit Contact: 1 (N.O., N.F.) Programming: By Internet. Saving of parameters: No volatile memory Material: ABS module 13.08.15 – V1.2 AIPHONE...
- Page 16 Distributed by AIPHONE Printed in France 13.08.15 – V1.2 AIPHONE...
