Please read this en re guide before a emp ng to install this system.
This system should only be installed by an authorized installer/dealer.
Before installing this system, you need to be sure that there is good GSM cell coverage in the area
it is to be installed. It is recommended that you conduct a site survey, and check recep on on the site for a
GSM network. If recep on is poor in the area, then this system is not recommended. This unit currently
operates on AT&T and T‐Mobile networks in the USA. It is recommended that the system be set up, config‐
ured, commissioned and tested on a workshop bench before being taken to customer site for installa on.
You will need a GSM network SIM card in order to use this system. It should be a regular voice and SMS text
SIM card. Do not use a data only SIM, as this type of SIM is only for tablets and will not work in the Cellu
lar Select Gate.
SIM Card has already been installed in your New Cellular Select Gate
Make certain that the power is OFF on the Cellular Select Gate.
Slide the SIM card holder in the open direc on, and carefully open the door.
Do NOT force it.
A er power‐up, wait 20—30 seconds for Cellular Select Gate to boot up and connect to a network.
Test the Cellular Select Gate for correct opera on.
Send SMS text message *20# to Cellular Select Gate phone number to determine signal strength.
Response range is 1 to 31, but the most reliable opera on is at signal strength 14 or above.
(The larger the value, the be er the signal strength.)
Note: This unit is a dual 2G/3G system, opera ng on either 2G or 3G network frequencies of
850/900/1800/1900MHz.
This system comes with a 16.5 volt 20 VA AC transformer power supply. It is recommended that it is
located within 50 feet of the Cellular Select Gate and cabled using 18 gauge cable less than 50 feet in
length. Current draw (at idle) is 90mA @ 12 VDC; 80 mA @ 24 VDC (with lights).
Cellular Select Gate Overview
Site Survey
SIM Card
Ac va on Instruc ons.
Locate the AT&T SIM card holder
a ached to the ac va on card en‐
closed with the Cellular Select Gate.
Call 786‐202‐0862 to ac vate SIM
card. (Basic informa on is required
for add‐on or ac va on of new ac‐
count).
Provide SIM number shown on ID
Card.
Obtain and record new cell num‐
ber for future reference.
Ac va on is complete. Verify voice
and text is func onal; otherwise,
contact your carrier.
Select Gate is ready to go!
You may also use a GSM SIM added
onto your own cellular account,
if preferred.
Installing SIM Card
Power
