Parker isysNet E104P A Series Installation & Service Instructions Manual

! WARNING
To avoid unpredictable system behavior that can cause personal injury
and property damage:
• Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
• Disconnect air supply and depressurize all air lines connected to
this product before installation, servicing, or conversion.
• Operate within the manufacturer's specified pressure, temperature,
and other conditions listed in these instructions.
• Medium must be moisture-free if ambient temperature is below
freezing.
• Service according to procedures listed in these instructions.
• Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
• After installation, servicing, or conversion, air and electrical
supplies (when necessary) should be connected and the product
tested for proper function and leakage. If audible leakage is present,
or the product does not operate properly, do not put into use.
• Warnings and specifications on the product should not be
covered by paint, etc. If masking is not possible, contact your local
representative for replacement labels.
Safety Guide
For more complete information on recommended application guidelines, see
the Safety Guide section of Pneumatic Division catalogs or you can download
the Pneumatic Division Safety Guide at: www.parker.com/safety
isysNet EtherNet/IP Adapter User Manual
The isysNet EtherNet/IP Adapter User Manual PSS-UM004A-EN-P is
not available at this time. Please refer to Rockwell Automation 1734
POINT I/O EtherNet/IP Adapter User Manual 1734-UM011A-EN-P
for similar setup information, which is available online at
http://literature.rockwellautomation.com/.
Pneumatic Division
Richland, Michigan 49083
Installation & Service Instructions
E104P
isysNet EtherNet/IP Adapter,
Series A (PSSCENA)
ISSUED: December, 2006
Supersedes: December, 2005
Doc.# E104P, EN# 060961, Rev. 3
Introduction
Follow these instructions when installing, operating, or servicing the
product.
isysNet EtherNet/IP Adapter, Series A
(PSSCENA)
The sealed IP67 housing of the adapter requires no enclosure.
(Note that environmental requirements other than IP67 may require
an additional appropriate housing.) The EtherNet/IP connector is
a sealed D-coded M12 (micro) style. The EtherNet/IP adapter is
shown below.
PSSCENA
Eth erN et I/P
X10 0
M12
Connector
X10
Network
X1
Address
Switches
Mini 7/8"
Auxiliary
PW R
Power
Connector
!
WARNING
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED
ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY
DAMAGE.
This document and other information from Parker Hannifin Corporation,
its subsidiaries and authorized distributors provide product and/or system
options for further investigation by users having technical expertise. It
is important that you analyze all aspects of your application, including
consequences of any failure and review the information concerning the
product or systems in the current product catalog. Due to the variety of
operating conditions and applications for these products or systems, the
user, through its own analysis and testing, is solely responsible for making
the final selection of the products and systems and assuring that all
performance, safety and warning requirements of the application are met.
The products described herein, including without limitation, product
features, specifications, designs, availability and pricing, are subject to
change by Parker Hannifin Corporation and its subsidiaries at any time
without notice.
EXTRA COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FOR INCLUSION
IN EQUIPMENT / MAINTENANCE MANUALS THAT UTILIZE THESE PRODUCTS.
CONTACT YOUR LOCAL REPRESENTATIVE.
