- Page 1 ZigBee Plug-in Installation Guide For Inverters with SetApp Configuration Version 1.2...
-
Page 2: Table Of Contents
About This Guide Overview Package Contents Installing the Antenna Clipping the Antenna to the Inverter Connecting the Antenna to a Vertical Surface using a Bracket Installing the ZigBee Plug-in Configuring Communication Appendix A: Technical Specifications ZigBee Plug-in Installation Guide MAN-01-00554-1.2... -
Page 3: Revision History
Revision History Revision History Version 1.2 - April 2019 Removal of Monitoring support Version 1.1 - February 2019 Addition of Smart Energy Management support Version 1.0 - January 2019 First version of this guide. ZigBee Plug-in Installation Guide MAN-01-00554-1.2... -
Page 4: Disclaimers
SolarEdge reserves the right to make changes to the material at any time and without notice. You may refer to the SolarEdge web site (www.solaredge.com) for the most updated version. All company and brand products and service names are trademarks or registered trademarks of their respective holders. -
Page 5: Emission Compliance
Increase the separation between the equipment and the receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. ZigBee Plug-in Installation Guide MAN-01-00554-1.2... - Page 6 Disclaimers 5 Changes or modifications not expressly approved by the party responsible for compliance may void the user’s authority to operate the equipment. ZigBee Plug-in Installation Guide MAN-01-00554-1.2...
-
Page 7: Support And Contact Information
Support and Contact Information Support and Contact Information If you have technical problems concerning SolarEdge products, please contact us: Support Center: https://www.solaredge.com/service/support Country Phone E-Mail Australia (+61) 1800 465 567 support@solaredge.net.au APAC (Asia support- 073 240 3118 Pacific)(+972) asia@solaredge.com Belgium (+32) 0800 76633 support@solaredge.be... - Page 8 System configuration information, including the type and number of modules connected and the number and length of strings. The communication method to the SolarEdge server, if the site is connected. The software version as appears in the status screen. ZigBee Plug-in Installation Guide MAN-01-00554-1.2...
-
Page 9: About This Guide
This guide is intended for Photovoltaic (PV) system owners, installers, technicians, maintainers, and integrators who use the SolarEdge power harvesting system. This guide assumes that the SolarEdge power harvesting system is already installed and commissioned. For additional information about how to install and commission the SolarEdge power harvesting system, refer to the relevant installation guide. -
Page 10: Overview
ZigBee is a technology that enables wireless connection between several SolarEdge devices. Smart Energy uses the ZigBee Home Automation protocol with up to 10 devices connected to a SolarEdge inverter that serves as a Smart Energy manager. Smart Energy devices include:... -
Page 11: Package Contents
Package Contents Package Contents The package contains the following items. Other items may be included, if necessary. ZigBee Plug-in Antenna This installation guide WARNING! When installing the ZigBee Plug-in, follow the safety instructions of the inverter. ZigBee Plug-in Installation Guide MAN-01-00554-1.2... -
Page 12: Installing The Antenna
b. Turn the Safety Switch (if applicable) to OFF. c. Disconnect the AC to the inverter by turning off the circuit breakers on the distribution panel. 2. Clip the antenna vertically to the heatsink fins or the inverter side. ZigBee Plug-in Installation Guide MAN-01-00554-1.2... - Page 13 5. Remove the rubber seal from the gland and insert the cable through the gland. 6. Insert the rubber seal with the cable into the gland body and reconnect the gland to the inverter. Tighten the sealing gland. ZigBee Plug-in Installation Guide MAN-01-00554-1.2...
-
Page 14: Connecting The Antenna To A Vertical Surface Using A Bracket
Figure 2: Example of an antenna bracket 1. Drill two holes in the surface and attach the bracket to it with two screws. 2. Clip the antenna onto the bracket. Make sure the antenna is positioned vertically. ZigBee Plug-in Installation Guide MAN-01-00554-1.2... -
Page 15: Installing The Zigbee Plug-In
Installing the ZigBee Plug-in 1. Make sure the inverter is powered off. 2. Remove the inverter cover as explained in the inverter installation manual. 3. Install the ZigBee Plug-in on the communication board as shown below. ZigBee Plug-in Installation Guide MAN-01-00554-1.2... - Page 16 Installing the ZigBee Plug-in 15 4. Connect the antenna cable to the ZigBee Plug-in and tighten the connector. 5. Close the inverter cover as explained in the inverter installation manual. ZigBee Plug-in Installation Guide MAN-01-00554-1.2...
-
Page 17: Configuring Communication
RS485-1 SolarEdge Slave › Multi -Device RS485-2 (Modbus) › ZigBee None › Wi-Fi None › Cellular PCL › Modbus Disable TCP port 2. From the Communication screen, select the following: ZigBee è Protocol è Home Automation. ZigBee Plug-in Installation Guide MAN-01-00554-1.2... -
Page 18: Appendix A: Technical Specifications
Bandwidth O-QPSK with DSSS Modulation coding Antenna gain Dimensions 78x32/3x1.3 mm/in Certification FCC (USA), IC (Canada), ETSI Regulatory approvals (Europe), C-Tick (Australia), Telec (Japan) * Approximate values, may differ depending on specific installation conditions ZigBee Plug-in Installation Guide MAN-01-00554-1.2... - Page 19 lf you have technical queries concerning our products, please contact our support through the SolarEdge service portal: www.solaredge.com/service/support APAC (Asia Pacific)(+972) 073 240 3118 Australia (+61) 1800 465 567 Belgium (+32) 0800-76633 China (+86) 21 6212 5536 DACH & Rest of Europe (+49)
