Team Assocciated RC10B6.1 Dirt Light Team Kit Manual & Catalog page 5

4/19
:: Bag 1 - Step 1
x2
31382
FT Ballstud
Washer,
Note orientation
of steering rack.
Aluminum
(1mm)
x2
91048
Heavy-duty
Ballstud,
8mm
:: Bag 1 - Step 2
! M3 x 20mm
The steering
bellcrank brace
has offsets on one
Steering
side. They should be
installed towards
Bellcrank
the bearings.
89202
M3 x 12mm
BHCS
!
Do not overtighten steering bolts. Make sure
there is free movement in the steering rack.
:: Bag 2 - Step 1
91656
Bulkhead
Front
!
TOP
x2
91678
BHCS
Shouldered
91667
Brace
x2
x2
25204
M3 x 16mm
FHCS
91667
Steering
x4
91475
Bellcrank
3 x 7 x 3
(Right)
Ball Bearing
91667
Steering
Rack
x2
31382
FT Ballstud
Washer,
Aluminum
(1mm)
31283
91049
5mm Ball
Heavy-duty
Stud, Long
Ballstud,
10mm
x2
31382
FT Ballstud
Washer,
Aluminum
(1mm)
91765
Chassis,
B6.1
91475
3 x 7 x 3
Ball Bearing
x2
Ball Stud
!
There are two bulkhead settings
(25 °, 30 °). 25 ° is the standard used.
The arrow should point
forward for the desired setting.
25
5
x4
91667
Steering
Bellcrank
(Left)
91766
Front
Mount
