Diagonal 11mm (Type 2/3) CCD Image Sensor for CCIR B/W Video Cameras
Description
The ICX423AL is an interline CCD solid-state image
sensor suitable for CCIR B/W video cameras with a
diagonal 11mm (Type 2/3) system. Compared with the
current product ICX083AL, basic characteristics such
as sensitivity and smear are improved drastically and
high saturation characteristics are realized.
This chip features a field period readout system and
an electronic shutter with variable charge-storage
time. This chip is compatible with the pins of the
ICX083AL and has the same drive conditions.
Features
• High sensitivity (+3.0dB compared with the ICX083AL)
• Low smear (–10.0dB compared with the ICX083AL)
• High saturation signal (+2.0dB compared with the ICX083AL)
• High resolution and Low dark current
• Excellent antiblooming characteristics
• Continuous variable-speed shutter
Device Structure
• Interline CCD image sensor
• Optical size:
• Number of effective pixels: 752 (H) × 582 (V) approx. 440K pixels
• Total number of pixels:
• Chip size:
• Unit cell size:
• Optical black:
• Number of dummy bits:
• Substrate material:
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
Diagonal 11mm (Type 2/3)
795 (H) × 596 (V) approx. 470K pixels
10.25mm (H) × 8.5mm (V)
11.6µm (H) × 11.2µm (V)
Horizontal (H) direction: Front 3 pixels, rear 40 pixels
Vertical (V) direction:
Horizontal 22
Vertical 1 (even fields only)
Silicon
ICX423AL
20 pin DIP (Ceramic)
V
3
Front 12 pixels, rear 2 pixels
– 1 –
Pin 1
H
40
Pin 11
Optical black position
(Top View)
2
12
E01X23A41
