- Page 1 User guide IRON DOG 07 ©2018...
- Page 2 Winter can come; we’re looking forward to it. Welcome to the IRON DOG family. Eggenfelden, August 2007 Ulrich Brunner The name >>EISERNER HUND<< - >>IRON DOG<< - is a registered and protected mark. Individual models are registered as design patents. User guide (1.1) © 2017 Brunner GmbH...
-
Page 3: Table Of Contents
Guide, as well as national or EU standards and local regulations must be observed. Your specialized enterprise and IRON DOG partner can give you the most current information and details. Please keep the User Guide for future reference! © 2017 Brunner GmbH User guide (1.1) -
Page 4: My Iron Dog
Do not bring inflammable materials within an 80 cm radiation range of the IRON DOG! Fire risk! Don’t put inflammable objects on the stove top, under the cast iron stove or in between the rear of the stove and the wall behind. User guide (1.1) © 2017 Brunner GmbH... - Page 5 24 h in a fire resistant container. Fire risk by re- maining glow! In case of fire, call the fire-brigade! Chimney fire In case of a chimney fire, remove all inflammable objects from the chimney. Beware of flying sparks. Call the fire-brigade! © 2017 Brunner GmbH User guide (1.1)
-
Page 6: Basic Principles
The wood load degases with beautiful flames in approximately 60 - 70 minutes and produces a heating output between 5 - 9 kW/h depending on the quantity of wood (1,5 kg - 2,5 kg). User guide (1.1) © 2017 Brunner GmbH... - Page 7 For a simple operation the air income is regulated with one single air con- trol rod. Please heat with the given combustion air regulations. Insufficient combustion air leads to an increased environmental impact, bad efficiency and creosote in the stove and the chimney. © 2017 Brunner GmbH User guide (1.1)
-
Page 8: Firewood And Heating Power
Use only brown coal briquettes and dry, natural wood with a residual humidity factor below 20%, or wood briquettes according to DIN EN 14961-3, Class A1, length >14 cm (5.51 in), diameter >8 cm (3.15 in). User guide (1.1) © 2017 Brunner GmbH... - Page 9 >8 cm (3.15 in) (right). What amount of heat will I get when buying wood per weight? 500 kg freshly cut wood Water content 50% 500 kg x 2.0 kWh/kg = 1000 kWh © 2017 Brunner GmbH User guide (1.1)
- Page 10 Too much of firewood or inappropriate fuel types can cause overheating and damage. No kind of waste shall be burned in a fireplace! Waste on fire = Toxins in your garden! User guide (1.1) © 2017 Brunner GmbH...
-
Page 11: Seasoning Of Firewood
Our best 3 tips for heating with wood to become an experience. 1) dry wood 2) dry wood 3) dry wood AMOUNT OF FUEL Heat output regulation by combustion air reduction is wrong! © 2017 Brunner GmbH User guide (1.1) -
Page 12: Components
Log length Log size 1,5 kg - 2,5 kg 25 cm - 48 cm 20 cm - 30 cm for nominal heat output 1,6 kg for full heat output 2,5 COMPONENTS Operating elements User guide (1.1) © 2017 Brunner GmbH... - Page 13 Inlay for cleaning Firing door Air control push rod Combustion chamber Stove door Hot plate © 2017 Brunner GmbH User guide (1.1)
- Page 14 Upper air duct right K012027 side Upper air duct K012031 Upper air duct cross- K012032-01 Push rod plate K012020-01 Upper air difuser K012038 Front inlay K012039 Bottom plate K012040 Identification plate ID K012077 Baffle plate K012033 User guide (1.1) © 2017 Brunner GmbH...
-
Page 15: Operation
The max. fuel quantity of logs can be used only after the heating of the combustion chamber lining. Start-up Combustion air completely open for a fast heating up Full load output Heating operation for a full heat output © 2017 Brunner GmbH User guide (1.1) - Page 16 Nominal heat output Heating operation for a nominal heat output Closed Combustion air completely closed User guide (1.1) © 2017 Brunner GmbH...
-
Page 17: Lighting Fire In A Cold Fireplace
Move the combustion air control element into position for lighting up and put a desired amount of logs on the glowing embers. After wood is laid on the embers it gets warm, moisture is driven out and evaporates. © 2017 Brunner GmbH User guide (1.1) -
Page 18: Cleaning
Remove the cleaning inlays from the hotplate and clean the ashes with a suitable vacuum cleaner. When the fireplace was not used for a long time, call the chimney sweep to inspect and clean your chimney. User guide (1.1) © 2017 Brunner GmbH... - Page 19 The sealing ropes could get in contact with glowing embers and eventually burned. Damage of sealing ropes arising from inappropriate operation or cleaning are excluded from warranty. Please follow the safety precautions regarding the handling of ashes and embers. © 2017 Brunner GmbH User guide (1.1)
-
Page 20: Hint
Wait until outside temperature is below indoor temperature Fuel unsuited Wood logs are to big Use dry and smaller wood Wood is damp or wet User guide (1.1) © 2017 Brunner GmbH... - Page 21 Check whether other stoves The chimney draught can be or fireplaces are connected worsened by other connected to the chimney. fireplaces. © 2017 Brunner GmbH User guide (1.1)
-
Page 22: Attention
Actual standards and reg- ulations must be observed. IRON DOG - Partner: Purchase date: User guide (1.1) © 2017 Brunner GmbH... - Page 23 Brennholz kaufen: www.brennholz.com Ulrich Brunner GmbH Zellhuber Ring 17-18 D-84307 Eggenfelden Tel.: +49 (0) 8721/771-0 Fax: +49 (0) 8721/771-100 Email: info@brunner.de Art.No: © 2017 Brunner GmbH User guide (1.1)
