3.3. Mode LOOP

Play the evelopes in loop while hold down the key (or high level via KEY input). Each envelope
create after the end a short trigger impuls via the END output jack. Set the lenght of the enve-
lopes with POT TIME, set the shape with POT SHAPE and set the output level with POT LEVEL.
Gate via KEY input
END Output Trigger

4. PARAMETER

4.1. SHAPE (shape of envelope)

POT SHAPE set the shape of the envelope. Please note the logarithmic release of channel 1.
If you use the SHAPE CV input, then the POT is an attenuator of the CV input. Set the level of
the CV output of the envelope between 0..+10v via the POT LEVEL.
CHANNEL 1
Attack = linear
Release = logarithmic
Keypress or
CV Output
KEY Output
6
CHANNEL 2
Attack = linear
Release = linear
