ASKOMA ASKOHEAT-E Series User And Service Manual

ASKOHEAT-
E
Fitting Instructions, user manual and service
Please keep in a safe place
Screw-in heater R 1½" for industrial and heating water
1.0 to 9.0 kW (type A)
•
AHIR-B-A-... / AHIR-BI-A-...
•
1.0 to 9.0 kW (type B)
•
AHIR-B-B-... / AHIR-BI-B-...
•
1.0 to 9.0 kW (type C)
•
AHIR-B-C-... / AHIR-BI-C-...
•
1.0 to 9.0 kW (type W)
•
AHIW-B-A-... / AHIW-BI-A-...
•
Index
User Manual
Fitting instructions
Circuit Diagram
Service
Malfunction
General safety information

•
Do not place the device into operation until after having read the user manual.
•
These devices may be used by children aged 8 or more and by persons with reduced physical, senso-
ry or mental capacity or those lacking in experience and/or knowledge if they are supervised or if
they have been instructed in safe operation of the device and understood the resultant dangers.
Children may not play with the device. The device may not be cleaned or serviced by children unless
they are supervised.
I n s t a l l a t i o n , s e t t i n g a n d r e m o v a l m u s t b e
c a r r i e d o u t o n l y b y q u a l i f i e d e l e c t r i c i a n s .
ASKOHEAT- _1-9_en
E
Insulated mounting
Screw-in heater R 1½"
MVGASV_440101_en www.askoma.com
Page 2
Page 3
Page 5
Page 6
Page 6
Page 1
