Outdoor living today 8x4 SpaceSaver Bevel Assembly Manual

Garden shed
Hide thumbs

Advertisement

Quick Links

Download this manual
Thank you for purchasing
an 8x4 SpaceSaver Garden
Shed. Please take the time
to identify all the parts prior
to assembly.
Please be aware that it is the
customers' sole responsibility
to acquire the necessary
building permits and or obtain
approval from their local
county, municipality or HOA
prior to purchasing. Generally,
shed structures under 100
square feet do not require
permits in most jurisdictions
in the United States and
Canada.
In the event of a missing or broken piece, simply call the Outdoor Living Today Customer
Support
Line
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Outdoor Living Today
8x4 SpaceSaver Garden Shed
@
1-888-658-1658
www.outdoorlivingtoday.com
Bevel Model
Assembly Manual
Optional door
configuration
within
30
days
Page 1
Revision #23
October 2, 2019
of
the
delivery
sales@outdoorlivingtoday.com
of
your

Advertisement

loading

Related Manuals for Outdoor living today 8x4 SpaceSaver Bevel

Summary of Contents for Outdoor living today 8x4 SpaceSaver Bevel

  • Page 1 United States and Canada. Optional door configuration In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line 1-888-658-1658 within days delivery your purchase.

  • Page 2: Table Of Contents

    Thank you for purchasing our 8x4 Bevel SpaceSaver Garden Shed. Please take the time to identify all the parts prior to assembly. Parts List: D. Miscellaneous Section (Skirting, Trim, Door, Facia & Misc. Parts A. Floor Section 6 - ¾” x 4 ½” x 45 ”...
  • Page 3 8x4 BEVEL SPACESAVER HARDWARE PACKAGE Hardware Kit (Provided) 4” x 240 1 1/2” Finishing Nail 2 1/2” x 150 x 145 Square Drive Bit 1 1/4” 3/4” x 22 2” Black Headed Barrel Bolt Door Handle x 1 Simpson Strong Tee Hinge x 3 Tie x 8 Tools Required...
  • Page 4 A. Floor Section Exploded view of all parts necessary to complete Floor Section. Identify all parts prior to starting. Note: Floor Footprint is 96” wide x 45 1/2” deep. Exploded Floor Section Plywood Floor Floor Joists (2) Small Floor Joist Frame Large Floor Joist Frame Floor Runners (5)
  • Page 5 4th Runner Flush with Floor Framing. Position and attach Floor Runners (1 1/2” x 3 1/2” x 45 1/2”) to completed floor frames with 6 - 2 1/2” screws per Runner. With Floor Joist Frames positioned Make sure Runners are flush with outside together flush, attach with 6 - 2 1/2”...
  • Page 6 Note: Plywood is cut slightly smaller than floor framing. Keep plywood seams tight. Position Plywood so it sits almost flush with outside of floor joist framing (see Note). When correctly positioned, attach to all floor joists with 1 1/4” screws. Use screws every 16”. Exploded view of all parts necessary to B.

  • Page 7: Steps

    Starting on side, position a Solid Wall Panel on top of plywood floor. The Wall Panel bottom framing will sit flush with floor framing. Wall siding will overhang the floor. Important: Make sure all walls are aligned in their upright position. If not, water may leak into your shed. Unsure if panel is facing up or down? Recently attached Bottom Plate is on bottom of panel.
  • Page 8 Pilot Hole first. With the corner wall attachment complete, position the second rear wall panel in place so bottom 2x3 wall framing is sitting flush with outside floor framing. Wall siding should overhang floor by approximately 3/4”. When positioned correctly, attach both wall panel studs together as per Step 12 with 3 - 2 1/2”...
  • Page 9 Align front corner Window Wall Panel as per Steps 11 & 12. using 3 - 2 1/2” screws to secure wall studs together. 2x3 wall plate flush with plywood floor. Once again position the 2x3 wall plate so it sits flush on floor and siding overhangs. Note: Narrow Wall Panel is only 73”...
  • Page 10 Jamb flush with top of narrow wall. Gap on window side. Jamb flush with siding butt. Position Door Jambs flush against narrow and window wall studs and tight to floor. The Jamb is 3 1/2” wide and will sit flush to outside of wall siding. When positioned correctly, secure Jambs using 4 - 2 1/2”...
  • Page 11 Siding lines up. Sidings will overlap. Wall framings flush. Align wall framing of Angled Wall Extendor and Side Wall so they are flush at the back. The siding for both walls should also align evenly from front to back. With Angled Wall Extendor and Side Wall aligned correctly, secure together from the inside with 4 - 2 1/2”...
  • Page 12 Siding of Extension Wall. Siding of rear wall. Locate one Wall Extendor and place on rear wall panel with siding of extendor overlapping that of the rear wall. With 2x3 wall framing aligned, attach Wall Extendor to both the Angled Wall Extendor framing and the rear wall framing with 5 - 2 1/2”...
  • Page 13 Attach Horizontal Wall Cleats (1 @ 3/4” x 3 1/2” x 70”, 1 @ 3/4” x 3 1/2” x 21”) to Wall Extendor bottom framing and Rear Wall top framing, so that cleat is flush with extendor framing. There is a short and a long wall cleat.
  • Page 14 Note: We recommend you drill a 1/8” pilot hole for each screw, to avoid splitting wood. The hole depth should be equal to 3/4 the length of screw. 3” wide Rear Soffit Board (2) 96” Mid Rafter Mid Rafter 21 3/4” 48”...
  • Page 15 Carefully flip completed Rafter Section over so 3 1/2” wide Soffit is facing the front and place on SpaceSaver walls. Note: once again, make sure 3 1/2” wide Soffit is positioned to the front of the shed. 3 1/2” Wide Soffit Rafter sits on framing.
  • Page 16 Simpson Strong Tie Connectors. With Rafter Section correctly aligned, secure rafters to walls using Simpson Strong Tie Connectors. Start with outside rafters and secure 2 Strong Ties with 1 1/4” screws. Screw into Wall Extension Framing at the rear and Wall Panel top framing at the front. Complete both sides. With outside rafters properly secured, completely secure remaining interior rafters using 8 - 2 1/2”...
  • Page 17 Shingles overhang plywood on outside. Nailing plate to outside edge. Plywood flush with shingles Front of plywood on inside. 1/8” recessed with rafter end. Correctly orientate Left Side Roof Panel, with shingles overhanging plywood on the side of the shed and flush with plywood to the middle. Place on rafters with front of plywood just about flush with rafter ends but just slightly recessed.
  • Page 18 To cover roof seam, slide one Filler Shingle (5 1/2” wide) up and underneath second shingle row. Push or bang filler carefully with a hammer until evenly spaced and butt is even with other 1st row of shingles. Butt - thicker. Attach above the exposure line.
  • Page 19 Slide 3rd and 4th Filler Shingles up and underneath appropriate shingle rows and follow Steps 41 - 42 to align and attach. On last filler, screws will get covered by Roof Ridge Board (4 1/2” wide). Strong Ties. Secure roof panels to walls at both ends by positioning 2 Simpson Strong Ties on plywood and outside rafters and securing with 2 - 1 1/4”...
  • Page 20 D. Miscellaneous Section Exploded view of all parts necessary to complete the Skirting, Trim, Facia and Miscellaneous Pieces. Identify all parts prior to starting. Not Shown: Door Stops, Flange, Threshold, Rear Trim, Horizontal Door Trim and Roofing Felt) Roof Ridge Rear Facia (2) Boards (2) Side Angle...
  • Page 21 Skirting meets flush in center. Rear skirting pieces will meet together in the center. Secure with 4 - 1 1/2” finishing nails per piece. Gaps on outside will be covered by Corner Trim pieces later. Complete front and side skirting attachments.
  • Page 22 Gap to be covered. Attach Corner Filler Trims where gaps exist in front corners (2 per side). Hammer with 8 - 1 1/2” finishing nails. Position bottom filler just below wall siding. Top filler just below soffit. Gap in middle. Rear Center Corner Filler Trim.
  • Page 23 Step 65 before attaching Door Trim. Use Narrow Wall and Above Door Trim as a template to align trim. Flush with Narrow Tight under- Wall stud. Vertical neath soffit. Door Trim. Locate Vertical Door Trim (2 - 1/2” x 3 1/2” x 79”). Position Door Trim flush with outside of narrow wall stud.

  • Page 24: Step

    To completely trim out rear corners, locate Side Rear Corner Trims (1/2” x 2 1/2” x 88 3/4”) and Rear Corner Trims (1/2” x 5 1/2” x 88 3/4”). Align and attach as per Step 58. Attach Rear Middle Trim (1/2” x 2 1/2” x 88 3/4”) where wall panels come together at rear seam. Attach with 8 - 1 1/2”...
  • Page 25 Hint: Use Shim Shingle or extra piece of siding to help space Door at top and bottom. With Hinges attached, position door in opening. You will need some assistance to hold door in place. Important - Drill Pilot holes to prevent splitting. 3/8”...
  • Page 26 Side Angle Cut Facia Front Rafter/Facia Nailing Plate. Facia. Locate and identify all Facia pieces: Front & Rear Facia (4) (1/2” x 4” x 50 1/2”). Side Angle Cut Facia (2) (1/2” x 4” x 54 1/8”). In front corner, align side and front Facia together. Front facia will cap side facia.
  • Page 27 Position first Roof Ridge Board (1/2” x 4 1/2” x 51 5/8”) at the rear of roof to cap off shingles and facia. Ridge Boards should meet on seam of roof panels. When aligned correctly, attach with 4 - 1 1/2” nails per piece. Attach Facia / Detail Plates to cover seams where Front and Rear Facia pieces come together.
  • Page 28 Window frame. Caulk gap. Screw insert into bottom (thick) part of siding. To reduce possible water from penetrating into the window cavity, caulk gap on both sides of window opening prior to installing Window Insert. Position insert in cavity and screw with 6 - 8 1 1/4” screws. On sides, make sure to screw insert into the thick butt of the siding only.
  • Page 29 Attach Door Handle. Handle should be Assemble Flower Box with Assembly Instructions positioned with larger flange to top. Mount included with this Manual. Center completed flower with 3/4” Black Headed Screws. box below bottom of window trim and secure with 2 - 2 1/2”...
  • Page 30 Optional - Door Configuration on End Instructions. (New Door Jamb and Door Trim.) Install Narrow Wall as per Step 17. Attach Door Header as per 1 1/2” x 3 1/2” x 73” Step 21. Optional Door Jamb. Door Header Position Optional Door Jamb as shown to the right using 6 - 4”...
  • Page 31 Assembly Manual may be downloaded or copied provided that ALL copies retain the copyright and any other Please call, write or email us at: proprietary notices contained on the Outdoor Living Today materials. material modified, edited or taken out of context Canadian Address...
