  • Page 1 Instructions for use and warranty details Wall Mounted RHGV90...
  • Page 2 Once installation is complete, please read this instruction manual carefully and get to know the controls and the features of your new Kleenmaid appliance. These simple instructions will enable you to achieve excellent results from the very first time you use it.

  • Page 3: Recommendations And Suggestions

    RECOMMENDATIONS AND SUGGESTIONS INSTALLATION  The manufacturer will not be held liable for any damages resulting from incorrect or improper installation.  The safety gap between the rangehood and the hob below must comply with the recommendations of the hob manufacturer. In case of no instructions, a minimum distance of 600mm (or other minimum distance as may be specified by AS/NZS 5601 and interpreted by a certified installer) should apply.
  • Page 4 COMPONENTS Ref. Qty. Product Components Hood Body, complete with: Controls, Light, Blower, Filter. Lower Decorative Chimney Upper Decorative Chimney Carbon Filter (optional accessory) Qty . Ref. Installation Components Screws 5 x 50 Wall Plugs Screws 4.2 x 9.5 Hood fixing bracket ( optional ) Chimney fixing bracket ( 0 / 1 optional ) Qty.
  • Page 5 DIMENSIONS Min. Min. 600mm 600mm The safety gap between the rangehood and the hob below must comply with the recommendations of the hob manufacturer. In case of no instructions, a minimum distance of 600mm (or other minimum distance as may be specified by AS/NZS 5601 and interpreted by a certified installer) should apply.

  • Page 6: Installation

    INSTALLATION WALL DRILLING AND BRACKET FIXING (OPTIONAL) WARNING: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. As a first step, proceed with the following drawings:  A vertical line up to the ceiling or up to the upper limit, at the center of the area in which the hood is to be fitted.

  • Page 7: Ducted Version Air Exhaust System

     Mark a point (3) on the horizontal line C, 130 (250 optional) mm to the right of the vertical reference line.  Repeat this operation on the other side, checking that the two marks are on the same horizontal line.

  • Page 8: Chimney Assembly

    CHIMNEY ASSEMBLY The chimney can only be installed with rangehood. Lower Decorative Chimney  Fix a Chimney fixing bracket 21 onto the Lower Decorative Chimney with 2 screws 12 (4.2 x 9.5) supplied with the hood.  Slightly widen the two sides of the flue and hook them onto the hood body, making sure that they are well seated.

  • Page 9: Control Panel

    CONTROL PANEL Button Function Remarks Turns the Motor ON. When is off. Enables shutdown of the Motor with a 3 When is on. minute delay, flashes. Turns the Motor OFF. When is flashing. Turns the Motor on at LOW speed . Buttons are on.

  • Page 10: Maintenance

    MAINTENANCE GREASE FILTERS CLEANING METAL SELF-SUPPORTING GREASE FILTERS  The filters must be cleaned after every 2 months of operation, or more frequently if there is particularly heavy usage, and can be washed in a dishwasher.  There is a fire risk if cleaning is not carried out in accordance with the instructions.

  • Page 11: Light Replacement

    LIGHTING LIGHT REPLACEMENT 1.5W LED light. Switch off the rangehood and isolate the rangehood by pulling out the mains  plug or switching off the fuse. Remove the grease filter.  Remove the light by levering its fitting from the hood body. (This may require ...

  • Page 12: Troubleshooting

    TROUBLE SHOOTING Fault Cause Solution The blades are blocked. The capacitor is damaged. Replace capacitor. Light on, but The motor is damaged. Replace motor. motor does not The internal wiring of motor is cut off/ work Replace motor. disconnected. An unpleasant smell may be produced.
  • Page 13 The benefits given to you under this Kleenmaid Warranty are in addition to other rights and remedies to which you may be entitled under the Australian Consumer Law in relation to the Product to which this Kleenmaid Warranty relates. Subject to the conditions below, the Product is warranted by Kleenmaid and/or its agents to be free from defects in materials and workmanship for the Warranty Period for normal Domestic Use.
  • Page 14 13. Kleenmaid accepts no liability for items that are lost, damaged, or stolen as a result of freight, transport or storage. If you are required to transport the Product to an authorised service centre, you must ensure that it is securely packed and insured.
  • Page 16 Other products available in the Kleenmaid range of appliances Washing machines Clothes dryers Dishwashers Ovens Cooktops Steam ovens Microwave ovens Built in espresso coffee machines Rangehoods Freestanding ovens Compass Capital Services Pty Limited trading as Kleenmaid ABN 96138214525 Level 2, 204 Botany Road Alexandria...
