- Page 1 M300 Mini(G) GNSS Receiver Quick Guide ComNav Technology Quick Guide M300 Mini(G) GNSS Receiver 2018 March...
-
Page 2: Table Of Contents
M300 Mini(G) GNSS Receiver Quick Guide CONTENTS 1. Introduction ..........................1 1.1 Safety Information ....................... 1 1.2 Warning and Cautions ......................1 1.3 Use and Care ........................1 1.4 Technical Assistance ......................2 1.5 Your Comments ........................2 2. Overview ............................3 2.1 Package list .......................... -
Page 3: Introduction
M300 Mini(G) GNSS Receiver Quick Guide 1. Introduction Thank you for choosing the M300 Mini(G) GNSS receiver. This Getting Started Guide will provide useful information about M300 Mini(G). It will also guide you through your first step of using M300 Mini(G) GNSS receiver. 1.1 Safety Information Before using the receiver, please make sure that you have read and understood this Getting Started Guide, as well as the safety requirements. -
Page 4: Technical Assistance
If you have any question and can’t find the answer that you need in this manual, please contact your local dealer from which you purchased the M300 Mini(G). Alternatively, please request technical support using the ComNav Website at:www.comnavtech.com or technical support email:support@comnavtech.com... -
Page 5: Overview
M300_G Mini GNSS Receiver User Guide 2. Overview 2.1 Package list Thanks for choosing ComNav M300 Mini(G) GNSS receiver. Please check the evaluation package you received with the package list as following. Items Picture M300 Mini(G) Receiver Double female RS232 cable 1*2P-5.08 Power cable... -
Page 6: M300 Mini(G) Enclosure Receiver Introduction
M300_G Mini GNSS Receiver User Guide GPRS antenna 2.2 M300 Mini(G) enclosure receiver introduction M300 Mini(G) GNSS receiver with ComNav GNSS OEM Board inside which integrated with GPRS data link, is mainly used in high accuracy application, such as UGV, GIS, deformation monitoring etc. -
Page 7: Receiver Installation
M300_G Mini GNSS Receiver User Guide 3. Receiver Installation 3.1 Interface introduction Front panel of M300 Mini(G) receiver ❶ 3 LEDs indicate the work status of the receiver. PWR: power indicator. After power on, this LED will light in red color. LINK: correction message.Flash once per second when receive correction message. -
Page 8: Installation
M300_G Mini GNSS Receiver User Guide Back panel of M300 Mini(G) receiver ❺ GPRS: SMA GPRS antenna connector ❻ GNSS: TNC GNSS antenna connector 3.2 Installation Connect the Power cable and data cable as below. -
Page 9: Configure M300 Mini(G) By Cru Software
M300_G Mini GNSS Receiver User Guide The Installation of GNSS antenna is a very important factor affecting the performance of receivers. It will have a great influence on the visibility of satellites and SNR, so the antenna should be placed in open area and far away from big power electromagnetic radiation devices. - Page 10 M300_G Mini GNSS Receiver User Guide Go to “Command”, then send the command “log version” After send “log version”, if output message like this means that connection is success, you can do the next step. Make the cursor to next line on the end of commands.
-
Page 11: Receiver Configuration
M300_G Mini GNSS Receiver User Guide If it do not output the version information, you should change the baud rate to try, the normally baud rate may changed to 38400/9200. ❶ Connection status: SN No. of receiver, the data download path. You can select the data download path from the left function bar->... -
Page 12: Main Information Check
M300_G Mini GNSS Receiver User Guide unlogall tst gprsmsg on set datalink gprs on tst connect com2 gprs tst setgprs cmnet 1 1 // APN Username Password interfacemode gprs auto auto on tst setcors 211.144.120.104 8888 roy roy // IP PORT Username Password tst setcorsmp PRORTCM3 client // The Sourcetable which you want to use log gpgga ontime 1... -
Page 13: Rtk Status Indication
M300_G Mini GNSS Receiver User Guide Messages shows the list of output messages by receiver, such as BESTPOSB, BESTVELB and TIMEB information Tracking shows satellite information, such as SNR and elevation. Sky View: go to main menu, View-> Sky view. Click the constellation to enable or disable the SV system. - Page 14 M300_G Mini GNSS Receiver User Guide After the receiver receives correction message, the receiver will calculate the ambiguity and turn to differential mode. ❶ Position mode: SINGLE->Narrow Float ->NARROW INT (autonomous mode-> RTK Float->RTK fixed) ❷ Differential age: 99 (No correction message), 1 (received correction message). ❸...
-
Page 15: Frequently Used Ascii Command
2. After inputting every command, press Enter button to change line and input another command. 3. For more detailed command information, please refer to ComNav OEM CARD REFERENCE MANUAL. 5.1 GPGGA Message After M300 Mini(G) receive the correction data, It will go to the differential mode automatically. -
Page 16: Satellites Constellation System Configuration
1. After sending those commands, the raw data will output by receiver, save the data in your PC. Use ComNav Rinex convert tools to covert the data to Rinex, then you can analyse the data in any software. 5.3 Satellites constellation system configuration...
