- Page 1 Quick Assembly Guide - BESV CF1 Quick Assembly Guide Quick Assembly Guide Quick Assembly Guide Quick Assembly Guide BESV CF BESV CF1 1 1 1 BESV CF BESV CF V. 0.0, 20150513...
-
Page 2: Table Of Contents
Quick Assembly Guide - BESV CF1 Contents What’s in the Box ............................2 Main Box Contents .......................... 2 Accessary Box Contents ........................ 2 Assembly Procedures ..........................3 Stem and Handlebar ........................3 Pedal ..............................5 Seat Post and Saddle Set ......................6... -
Page 3: What's In The Box
Quick Assembly Guide - BESV CF1 1. What’s in the Box 1.1 Main Box Contents Main Bike Assembly Accessary Box Saddle/Seat Post Set 1.2 Accessary Box Contents 1. User Manual 2. Charger 3. Pedal 4. Keys for Seat Post Lock... -
Page 4: Assembly Procedures
Quick Assembly Guide - BESV CF1 2. Assembly Procedures 2.1 Stem and Handlebar 2.1.1 Loosen stem fixing screw Press button(a) on the side to open stem lever, and loosen the screw(b) inside. 2.1.2 Adjust stem height and orientation Adjust stem to proper height and face forward. - Page 5 Quick Assembly Guide - BESV CF1 2.1.4 Adjust handlebar Adjust handlebar to center of the stem and rotate to proper angle. 2.1.5 Closure stem lever Closure stem lever. If stem lever is loosen, adjust the screw on the stem, “+” to tighten, “-“ to loosen.
-
Page 6: Pedal
Quick Assembly Guide - BESV CF1 2.2 Pedal 2.2.1 Take out the pedal in the box. 2.2.2 Set up the right pedal. Assemble the pedal with marking “R” onto the right crank clockwise clockwise and tighten it. clockwise clockwise 2.2.3 Set up the left pedal Assemble the other one with marking “L”... -
Page 7: Seat Post And Saddle Set
Quick Assembly Guide - BESV CF1 2.3 Seat Post and Saddle Set 2.3.1 Open seat clamp, make sure the slit on the shim is aligned to the slit on the frame, and then push the shim to bottom. 2.3.2 Insert seat post... -
Page 8: Checklist
3.1 Check the tire pressure is normal. 3.2 Check the function of the brakes, derailleur, and chain. 3.3 Check the function of the electric module and the battery power. Please refer to CF1 user manual. Finish BESV CF1 Quick Assembly.
