Summary of Contents for Saris ELECTRIC BIKE PUMP

  • Page 1 Customer Service 800.783.7257 ELECTRIC BIKE PUMP sarisinfrastructure.com OPERATION & MAINTENANCE MANUAL...
  • Page 2 Tell Us What You Think sarisinfrastructure.com/electricbikepump Register your product for updates sarisinfrastructure.com/registration...
  • Page 3 The Electric Bike Pump is made in the USA, and features an aluminum ramp channel. The stock length of channel is 8 feet. The channel is easily cut to length. For installations up to 16 linear feet, two sections of the channel are used. The second channel is cut to size and attached to an uncut 8’...
  • Page 4: Tools Needed

    Tools Needed Parallel Wall or object Setbacks: Tape Measure Both sides of the electric public bike pump should be at least 12” from ½” Masonry Drill Bit Drill walls or other obstructions. If pedestal mounting, we suggest mounting (Hammer drill recom- it tight against a wall.
  • Page 5 Wall Mounting or Vending Machine Mounting 1. Identify mounting location. Be sure to follow setbacks. The base of the electric pump should be mounted great- er than 37” from the ground. If installing on a vending machine, mount in a position that does not inhibit the door opening (we usually mount on the left side of the machine).
  • Page 6 The anchor size is designated by the inside diameter of the anchor. The Saris Infrastructure electric pump pedestal comes with 3/8”- Figure 4 16 anchors. The diameter of the hole to be drilled is the same size...
  • Page 7 5. When fastening to solid concrete with a drop in anchor, a hole must be drilled into the base material. A hammer drill should be used as it will drill the best quality hole. Once the bit is chucked into the hammer drill, the depth of the hole to be drilled can easily be set by using the depth gauge on the drill or by wrapping the bit with tape at the required depth.
  • Page 8 7. Before proceeding with installation, the hole must be cleaned of all concrete dust to ensure proper fastening. Use a wire brush, a vacuum or compressed air to clean out the hole completely. Figure 7 (Figure 7) 8. Next, insert the drop in anchor with the open side up. Drop the anchor into the hole.
  • Page 9 10. Place the pump over the 4 anchors. You will be using 2 studs/tamper resistant nuts and 2 hex bolts (opposite sides from each other). You will thread the studs into the anchors prior to installing the nuts. When tightening the special tamper resistant nuts, always set and first tighten the anchors using stan- dard nuts.
  • Page 10: Electrical Hook-Up

    4. It is important to use a strain relief on the incoming cable to avoid strain on the terminal strip connections. Air Line Hook up 1. The Saris Infrastructure electric pump comes without the airline connected. Ensure PTFE tape is installed on pipe fitting and tighten hose into fitting at the base of the enclosure. Use two wrenches to tighten.
  • Page 11: Required Maintenance

    The compressor does not need to be cleaned or drained. Connect valve to Press/hold button to If any performance issues arise, please contact your nozzle. Flip lever up. reach desired pressure. local Approved Saris Infrastructure Distributor. SCHRADER PRESTA Pump Operation Flip lever down. Remove nozzle.
