Recommended Cable Types - TDSi MICROgarde I User Manual

2.3.2
Component
Magnetic Stripe Reader
EXprox / EXprox2
Optica
Digital IR
MIFARE / EXsmart2
DIGIgarde /
DIGIgarde Smart /
PALMgarde
Indala Proximity Reader
Dataline Keypad
RS-232
RS-485 1
Inputs
Relays
04. 20.11.18

Recommended cable types

Part No. Cable Type
5002-0360 Belden 9730
Belden 9503
OS6C24/Alpha 5096/BICC H8124
Screened Alarm Cable
5002-0354 Belden 9730
5002-0355
Belden 9503
OS6C24/Alpha 5096/BICC H8124
Screened Alarm Cable
5002-0390 Belden 9730
5002-0391
Belden 9503
OS6C24/Alpha 5096/BICC H8124
Screened Alarm Cable
5002-1781 Belden 9730
5002-1791
Belden 9503
OS6C24/Alpha 5096/BICC H8124
Screened Alarm Cable
5002-0433 Belden 9730
5002-0434
Belden 9503
5002-0435
5002-0436
OS6C24/Alpha 5096/BICC H8124
5002-0440
Screened Alarm Cable
5002 0441
5002-0450 Belden 9730
5002-0451
Belden 9503
5002-0460
OS6C24/Alpha 5096/BICC H8124
Screened Alarm Cable
5002-0133 Belden 9730
5002-0137
Belden 9503
5002-0217
5002-0218 OS6C24/Alpha 5096/BICC H8124
Screened Alarm Cable
5002-0286 Belden 9729
5002-0315
FBOS2P24
5002-0316
OS2P22/Alpha 5902/Belden 9502
OS4C24/Alpha 5094/BICC H8123
7/0.2 mm 3– core screened cable
Belden 9729
FBOS2P24
OS2P22/Alpha 5902/Belden 9502
OS4C24/Alpha 5094/BICC H8123
Screened Alarm Cable
7/0.2mm (screened)
7/0.2mm or 16/0.2mm (screened)
1 Up to 32 MICROgarde access control units can be connected to a single port.
MICROgarde controller I and II
Cores Maximum Distance
6 60m
6 25m
6 20m
8 Up to 30m
6 150m
6 150m
6 150m
8 150m
6 150m
6 150m
6 150m
8 150m
6 150m
6 150m
6 150m
8 150m
6 150m
6 150m
6 150m
8 150m
6 150m
6 150m
6 150m
8 150m
6 150 m
6 60 m
6 60 m
8 Up to 30m
4 140m
4 100m
4 60m
4 40m
3 15m
4 1200m
4 900m
4 530m
4 400m
8 300m
2 300m
2 Dependent on load and
cable choice
Page 11
