- Page 1 Installation Instructions Modernist Prorange DOP36M96GL* Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 1 2019-02-15 5:46:13...
-
Page 2: Table Of Contents
Contents Before you begin Important About this manual Important note to the installer Important note to the consumer Important note to the servicer Customer service information Important safety instructions Read all instructions before using this appliance Symbols used in this manual Product specifications What's in the box Installation requirements... - Page 3 WARNING: Failure to follow the instructions in this manual exactly may cause a fire or explosion, and, consequently, property damage, personal injury, or death. • DO NOT keep or use gasoline or other flammable products near this appliance. • IF YOU SMELL GAS: - DO NOT light any appliances.
-
Page 4: Before You Begin
Before you begin Important Installer • To promote safety and minimize problems, read this manual thoroughly before starting the installation. Leave this manual with the user. • Write the appliance’s model/serial numbers in this manual for service/ maintenance reference. User •... -
Page 5: About This Manual
About this manual READ THESE INSTRUCTIONS COMPLETELY AND CAREFULLY. Important note to the installer • Read all instructions contained in these installation instructions before installing the range. • Remove all packing materials from the cooktop compartments before connecting the electric and gas supply to the range. •... -
Page 6: Customer Service Information
Customer service information This section should appears as follows: For installation issues, contact your Dacor dealer or Dacor Customer Assurance. Have available the appliance's model and serial numbers. (See the graphic below for location.) Dacor Customer Assurance Phone: 833-35-ELITE (833-353-5483) USA, Canada Mon –... -
Page 7: Important Safety Instructions
Important safety instructions ANTI-TIP DEVICE WARNING ALL RANGES CAN TIP, RESULTING IN PERSONAL INJURY. TIPPING RANGES CAN CAUSE BURNS FROM SPILLS, PERSONAL INJURY, AND/OR DEATH. INSTALL AND CHECK THE ANTI-TIP BRACKET FOLLOWING THE INSTRUCTIONS AND TEMPLATE SUPPLIED WITH THE BRACKET. •... -
Page 8: Read All Instructions Before Using This Appliance
Important safety instructions READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE • Electrical and gas equipment with moving parts can be dangerous. The important safety instructions in this manual are intended to minimize the risk of property damage, personal injury, and death. Be sure to read them. •... - Page 9 California Proposition 65 Warning WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov. Commonwealth of Massachusetts This product must be installed by a licensed plumber or gas fitter qualified or licensed by the State of Massachusetts. When using ball-type gas shut-off valves, you must use the T-handle type.
- Page 10 Important safety instructions • Use only dry pot holders. • Do not use the product to heat unopened food containers. • Do not strike the oven glass. • When disposing of the range, cut off the power cord and remove the door. •...
- Page 11 To remove safely from the pallet 1. Remove the screws from the bottom bracket on either side of the unit. 2. Press the bracket on either side to pull out. 3. Have two persons hold both bottom sides of the unit and lift up to remove from the pallet.
- Page 12 Important safety instructions Fire safety WARNING To reduce the risk of fire, electric shock, personal injury, or death, observe these precautions: • Do not store/place/use combustible materials (e.g., paper, plastic, pot holders, linens, gasoline, alcohol) near the product. • Do not wear loose fitting or hanging garments while using the product.
- Page 13 Gas safety WARNING To reduce the risk of fire, electric shock, personal injury, or death, observe these precautions: If you smell gas: • Close the valve and do not use the product. • Do not light a match, candle, or cigarette. •...
- Page 14 Important safety instructions Electrical and grounding safety WARNING To reduce the risk of fire, electric shock, personal injury, or death, observe these precautions: • Plug into a grounded 3-prong outlet. • Do not remove the ground prong. • Do not use an adapter or an extension cord.
- Page 15 Installation safety WARNING To reduce the risk of fire, electric shock, personal injury, or death, observe these precautions: • This product should be installed and properly grounded by a qualified installer, as specified in the Installation Instructions. Adjustments and service should be performed only by qualified gas range installer or service technician.
- Page 16 Important safety instructions Location safety WARNING To reduce the risk of fire, electric shock, personal injury, or death, observe these precautions: • This range is for indoor household use only. Do not install the range outdoors or anywhere that it will be exposed to weather/water or wind/ strong drafts.
- Page 17 Cooktop safety WARNING To reduce the risk of fire, electric shock, personal injury, or death, observe these precautions: • Make sure all burners are off when not in use. • Do not use aluminium foil to line the grates or any part of the cooktop. •...
- Page 18 Important safety instructions • When frying, always heat the oil slowly, and monitor the oil as it heats. When frying foods at high heat, monitor the oil throughout the cooking process. If combining fats or oils for frying, mix them together before heating. •...
- Page 19 • Do not use aluminium foil or foil liners anywhere in the oven. Do not use aluminium foil or like material to cover any holes or passages in the oven bottom or to cover an oven rack. • Stand away from the oven when opening the oven door. •...
- Page 20 Important safety instructions Self-cleaning oven safety WARNING To reduce the risk of fire, electric shock, personal injury, or death, observe these precautions: • The self-cleaning feature operates the oven at temperatures high enough to burn away food soils in the oven. The range is extremely hot during a self-cleaning cycle.
-
Page 21: Product Specifications
Product specifications What's in the box Grate Side L&R (2) Burner heads (6) and Flat rack (1) Grate Mid (1) Burner caps (6) Convection filter (2) Temp. Probe (1) Gliding racks (2) WOK ring (1) Anti-tip bracket (1) Front leg covers (2) The range is supplied with two different types of burner caps (brass and porcelain) to suit the customer’s preference. - Page 22 Product Specifications Parts needed Gas line shut-off valve Flexible metal appliance Flare union adapter ¾ in connector ½ in (ID) x 5 ft (NPT) x ½ in (ID) 135-degree elbow Lag bolt or ½-in (OD) Flare union adapter ½ in (optional) sleeve anchor (NPT) x ½...
-
Page 23: Installation Requirements
• The range may be installed flush to the rear wall. Dacor strongly recommends installing a non-combustible material on the rear wall above the range and up to the vent hood. - Page 24 Installation requirements Minimum dimensions WARNING If overhead cabinets are used, a range hood should installed that projects horizontally a minimum of 5" (12.7 cm) beyond the front of the cabinets. This will dissipate any heat buildup in the overhead cabinets to prevent risk of personal injury, fire, or death.
-
Page 25: Product Dimensions
Product dimensions NOTE Product tolerances: ±1/16” (±1.6 mm) 48 7/8’’ (124.1 cm) Front of open door Front of handle 29 5/8’’ (75.3 cm) 29’’ (73.7 cm) Front of edge of bull nose 27 1/2’’ (69.7 cm) Front panel 25 3/4’’ (65.4 cm) Rear of oven door 36 1/2’’... - Page 26 Installation requirements Cabinet dimensions • All maximum and minimum dimensions and clearances shown in the diagrams below must be maintained for safe operation. • Verify that the range installation site is away from any type of draft. • To reduce risk of fire and personal injury, cabinets should not be installed above the range.
-
Page 27: Location Requirements
Location requirements DOP36M96* Back of range Gas Inlet 5 3/8’’ (13.8 cm) 7 3/8’’ (18.6 cm) Power cord Measurement with appliance legs adjusted to lowest height. The hole size for the electrical wiring may be increased to 1 1/8” (2.9 cm) by removing the conduit bracket in the bottom of the range electrical box. - Page 28 Installation requirements Gas and Electrical Service • The black dots in the graphic below represent the recommended locations of the gas inlet and power outlet. Existing utilites may be used if they do not interfere with the range installation. Check local building codes for permissible gas-valve locations. •...
-
Page 29: Gas Requirements
Gas requirements Provide adequate gas supply. This range is designed to operate at a pressure of 5 in (13 cm) of water column on natural gas or 10 in (25 cm) of water column on LP gas (propane or butane). Make sure you are supplying your range with the type of gas for which it is designed. -
Page 30: Special Gas Requirements (Gas Models Sold In Massachusetts)
Installation requirements The pressure regulator located at the inlet of the cooktop manifold must remain in the supply line regardless of whether natural or LP gas is being used. NOTE • The rangetop has its own regulator. Use only the provided regulator, which must be installed in the gas line that runs from the cooktop gas inlet to the gas shut-off valve. -
Page 31: Electrical Requirements
Electrical requirements • Failure to follow these instructions can result in death, fire, or electrical shock. WARNING • It is the owner’s responsibility to make sure that the electrical service meets electrical requirements and that he electrical outlet has been properly installed by a licensed electrician. -
Page 32: Installation Instructions
Installation instructions Preparing for installation WARNING • If the gas or electric service provided does not meet the product specifications, do not proceed with the installation. Call the dealer, the gas supplier or a licensed electrician. • Before installing the range, you must locate and secure the anti-tip bracket to the floor. Unpacking the Range Unpack the parts box and verify that all required components have been provided. - Page 33 An anti-tip bracket and screws, installation instructions, and template are shipped with every range (PN DG94-00870B). The instructions include information necessary to complete the installation of the anti-tip bracket. Read and follow the instructions on the sheet and use the template for anti-tip bracket installation.
- Page 34 Installation instructions Anti-Tip bracket *approximatel 1 ” (35.1 mm) Screw must enter wood or concrete NOTE To install the Anti-Tip bracket, release the leveling leg. A minimum clearance of 1 ” (35.1 mm) is required between the range bottom and the kitchen floor. To check if the bracket is installed and engaged properly, remove the kick panel and look underneath the range to see that the leveling leg is engaged in the bracket.
- Page 35 Removing the Oven Door WARNING • Do not attempt to disengage the hinge catches with the door(s) removed from the range. The hinge springs could release causing personal injury. • Do not lift or carry the oven door(s) by the handle. NOTE To make the range easier to move, remove the door(s) to reduce weight.
- Page 36 Installation instructions Electrical connection CAUTION For personal safety, do not use an extension cord with this appliance. Remove the house fuse or open the circuit breaker before beginning installation. This appliance must be supplied with the proper voltage and frequency, and connected to an individual properly grounded branch circuit, protected by a circuit breaker or fuse having amperage...
- Page 37 Gas connection WARNING • Make sure the gas supply valve is off and that the power to the range is turned off at the circuit breaker or fuse box prior to connecting the gas line. • Do not overtighten the gas connections and fittings. •...
- Page 38 Installation instructions Before sliding the range into the cabinet: 1. Make sure the gas supply valve is in the off position and that power to the range is off. 2. Connect a flexible gas supply line to the gas shut-off valve previously installed on the stub out.
-
Page 39: Final Installation
Final installation 1. Peel the protective coating off of the range, including the door. 2. Measure from the floor to the countertop. Adjust the leveling legs as required to position the trim around the cooktop even with or above the countertop. - Page 40 Installation instructions 7. Assemble the provided convection filters on the upper and lower fan holes. Determine the proper sides of the filter by locating the word ‘UP’ on the filter. Then, carefully hook the metal clips on the back of the filter over the metal bar across the fan hole.
- Page 41 Re-installing the Oven Door(s) WARNING To avoid personal injury or damage to the door from it falling off its hinges: • Make sure that the notch on the bottom of each hinge rests on top of the lower lip of each hinge receptacle before attempting to open the oven door.
- Page 42 Installation instructions Door adjustment After re-installing the oven doors, make sure the oven doors are parallel and flush. There are 2 bolts around the Steam oven, under the each door hinge. The lower two bolts help adjust the door up and down. Adjust the door up and down 1.
-
Page 43: Installing The Knobs For Surface Burners
Installing the knobs for surface burners WARNING Installing the range knobs in the wrong position may result in damage to the griddle included with the range. The knobs for the center burners are marked with the maximum griddle settings. NOTE When installing the knobs, align the “D”... -
Page 44: Cooktop Assembly
Installation instructions Cooktop assembly Assembling the rangetop burners CAUTION • Do not operate the rangetop burners without all burner parts in place. • Do not push in any rangetop controls while removing the burner; a slight electrical shock might result, perhaps causing you to knock over hot cookware. •... - Page 45 Burner head / caps 1. Orient the burner head so the opening for the electrode aligns with the electrode. 2. Install the burner head so the electrode passes through its opening in the head. Ensure the burner head lies flat on the stove top.
- Page 46 Installation instructions Installing the grates NOTE For best results and longest life, install the grates as instructed below. When installed properly, the openings in the grates are centered over the burners. The grates occupy specific positions on the rangetop. For maximum stability and safe operation, these grates should only be used in their proper positions.
-
Page 47: Verifying Proper Operation
Verifying proper operation Before operating the range, read the accompanying use and care manual completely. It contains Important safety, service and warranty information. 1. Before beginning the test procedure, ensure that all cooktop control valves are in the OFF position, and all burner rings, burner caps, and grates are properly positioned on the cooktop frame. -
Page 48: Removal And Re-Installation
Do not attempt to repair the appliance yourself. Have the model and serial numbers available when you call. See page 6 for location. Dacor is not responsible for the cost of correcting problems caused by a faulty installation. Removal and Re-installation Removing the Range for Service 1. -
Page 49: Installation Checklist
Installation checklist WARNING • To ensure a safe and proper installation, the following checklist should be completed by the installer. • Proper installation, which the homeowner shall ensure, is vital to the safe operation of the range. - Has the plastic coating been peeled off the outside of the range? Have all packaging materials been removed from inside the oven? - Do the leveling legs contact the floor? Is the unit level? See page 39. - Page 50 MEMO Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 50 2019-02-15 5:46:25...
-
Page 51: Warranty Information
IMPORTANT: Your warranty will not begin until you activate it online or return this form to Dacor. If you have purchased more than one Dacor product, please return all forms in one envelope, or activate the warranty for each product online. - Page 52 DG68-01106C-00 Dacor ∙ 14425 Clark Avenue, City of Industry, CA 91745 ∙ Phone: (833) 353-5483 ∙ Fax: (626) 403-3130 ∙ www.dacor.com Install_NX9900R_PRORANGE_DOP36M96_DA_DG68-01106C-00_EN+MES+CFR.indb 52 2019-02-15 5:46:25...
