• Use SIP Proxy: This option determines whether the SIP function is "registered" to a SIP cloud server. If
this setting is enabled the address, user name, and password for the proxy must be added in the relevant
fields.
• SIP Proxy Address: IP address or URL of the SIP proxy used.
• SIP Username: Username for logging into registered SIP server; provided by the SIP service provider.
• SIP Password: Password for logging into registered SIP server; provided by the SIP service provider.
Aes67 system
AES67 Enabled: Enables the use of the AES67 AoIP engine. This is Enabled by default.
Network Interface: Allows selection of which network interface should be used for AES67. Users have the option
between Primary and Secondary network interfaces. The secondary interface is selected by default.
AES67 Frame Size: Allows selection for the size of AES67 frames. Users have the option for 1ms and 1/4ms. 1ms is
selected by default.
PTP Clocking and Clock Domain: This allows configuration of the settings and status of the PTP clock subsystem. The
Clock Domain allows selection of which PTP clock domain to synchronize with. This accepts a value between 0-128
and is set to 0 by default.
Inputs: This setting allows users to set the delay and network name of the source settings. Delay allows users to set
delays in their audio streams and is default set to 0. Source allows for selecting a Network name of the source for this
input to receive from. This option is set to 0 by default.
Outputs: This setting allows users to configure the Network Name and address of the NX Rack's AES67 output. Both
the Network Name and Address are left blank by default.
AdvANced system settINgs
When the Show Advanced Settings option is enabled, additional options and categories are displayed.

securIty

Remote Diagnostics: When activated, this option allows for remote diagnostics capability. The default setting is Off.
Web Server Port: This controls the port that the UI web server uses when remote control is enabled. The default
setting is TCP 80.
DHCP Client ID: Allows for configuring a custom client ID prefix for DHCP. This is left blank by default.

coNNectIoNs

Disable Congestion Avoidance: When activated, this option allows for disabling the congestion avoidance feature.
This is set to No by default.
