- Page 1 MTS-MPM Multi-Panel Mounting System 2775 E Philadelphia St, Ontario, CA 91761 1-800-330-8678...
- Page 2 Important Safety Instructions Please save these instructions. This manual contains important safety, installation, and operating instructions for the hardware system. The following symbols are used throughout the manual to indicate potentially dangerous conditions or important safety information. WARNING: Indicates a potentially dangerous condition. Use extreme caution when performing this task.
- Page 3 WARNING: these instructions are intended to be used by individuals with sufficient technical skills for the task. Knowledge and use of hand tools, measuring devices, and torque equipment is also required WARNING: Electrocution Hazard! Check for clearance to overhead power lines before bringing any installation.
-
Page 4: Table Of Contents
Material List ................................5 Installation ................................9 Foundation ..............................10 Compatibility with Renogy Panels ..................... 11 1- Install Base Column on the Foundation ..................12 2- Install Connector on Base Column ....................12 3- Install Main Girder and Angle Adjustment Connector ............13 4- Install Cross Beams on Main Girder ..................... -
Page 5: General Information
General Information The Renogy MTS-MPM is designed for off-grid applications when mounting on a roof is not ideal. Composed of high strength steel and corrosion resistant welded components, the MTS-MPM can support up to 400 Watts of power. The system comes complete with all fasteners to adhere panels to the mounting surface. - Page 6 4.5(diameter)x Q235 Connector 5.91 Steel Angle Adjustment Q235 1.2x1.2x12.8 Connector Steel Main Girder Q235 2.4x2.4x78.8 Steel Cross Beam Q235 1.6x1.6x63.0 Steel 8+(2) 1.5x1.6x1.6 End Clamp Piece spare* Aluminum...
- Page 7 4+(1) 1.4x1.0x2.0 Mid Clamp Piece spare* Aluminum 12+(2) Plastic Strut Channel Nut 2.0x1.3x0.7 with Plastic Wing spare* and steel Q235 Positioning Plate 7.9x7.9x0.3 for Base Column steel 7.1x6.0x0.4(di Q235 U-Bolt for Base Installation ameter) Steel S304 Socket Head 14+(2) Stainless M8 x 50 Screw spare*...
- Page 8 S304 8+(2) Socket Head M10 x 20 Stainless Screw spare* Steel S304 1+(1) Socket Head M12 x 100 Stainless Screw spare* Steel S304 2+(2) Stainless Hex Nut spare* Steel S304 12+(2) Stainless Hex Nut spare* Steel S304 1+(1) Stainless Hex Nut spare* Steel S304...
-
Page 9: Installation
Steel *Spare parts serve as safety margins for installation, spare parts quantity is not guaranteed. Installation Renogy assumes no responsibility for your foundation installation. Consult a local professional for proper installation. Recommended tools to have before installation (Not provided): •... -
Page 10: Foundation
Foundation WARNING! Windy conditions can exert extreme forces on the PV array, foundation, and mounting mast of your array. WARNING! Keep hands clear of pinch points! NOTE: Choose an optimum solar location that is free from obstructions such as trees and buildings. -
Page 11: Compatibility With Renogy Panels
Compatibility with Renogy Panels NOTE: Depending on the user, each multi-panel mount will be optimized for certain PV module(s). In terms of Renogy arrays, the following are recommended to be affixed: 4 x 100W Poly 4 x 100W Mono 1 x 270W to 300W NOTE: The provided end clamps are only compatible with 100W-150W panels. -
Page 12: 1- Install Base Column On The Foundation
1- Install Base Column on the Foundation WARNING! The mount is heavy! Depending on the modules you are using, the weight will only increase. Therefore, it is recommended to have the aid of another person and/or lifting devices that can help install this safely. Failure to observe this warning can hurt or kill you. -
Page 13: 3- Install Main Girder And Angle Adjustment Connector
3- Install Main Girder and Angle Adjustment Connector WARNING! Keep hands clear of pinch points! Attach the main girder and angle adjustment connector to the connector. Please follow the next 3 steps for this part of installation. -
Page 14: 4- Install Cross Beams On Main Girder
Step 1: Attach the angle adjustment connector to the connector with a M8x50 socket head screw, a M8 split lock washer, a M8 flat washer and a M8 hex nut. Step 2: Attach the main girder to the connector with a M12x100 socket head screw, a M12 split lock washer, a M12 flat washer and a M12 hex nut. -
Page 15: 5- Install Solar Panels With End Clamps And Mid Clamps
5- Install Solar Panels with End Clamps and Mid Clamps WARNING! Keep hands clear of pinch points! Step 1: Push the strut channel nut with plastic wing into the cross beam from side. Then turn the plastic wing 90 degrees to align with the cross beam. Step 2: Put solar panel in the desired position on top of the cross beam. -
Page 17: 6- Check All Parts To Ensure Safety
6- Check All Parts to Ensure Safety Check all screws and clamps to make sure all parts are securely installed. Maintenance You should be inspecting your multi-panel mount once per year. While inspecting, make sure of the following: 1. Ensure hardware is tight, tighten if need be 2. -
Page 18: Compatibility
GB50018 – 2002 (Cold – formed thin – Walled Steel Structure Technical Specification GB50429 – 2007 (Code for Design of Aluminum Alloy Structures) GB50797 – 2012 (Design Code for Photovoltaic Power Station) Warranty 1 year Compatibility RENOGY Solar Module Compatibility* INCOMPATIBLE RNG-10D-SS INCOMPATIBLE RNG-20D-SS INCOMPATIBLE...
