Specification
Forward/Backward movement
Left/Right turn
Obstacle Sensor
Battery
Battery Life
Frequency Band range
Maximum Radio-Frequency power
Speed of movement:
Troubleshooting
Problem
Product will not operate
Product will not move as expected
Sound is not audible
Lights have come on but no movement
Product is working intermittently
Robot is not avoiding obstacles
Rugged Robot
Approx. 20cm
Approx. 45 degree turns
Approx. 20cm
3.7V 850mAh Lithium polymer
approx. 1-2 hours in normal use (depends
mainly on amount of movement)
2.400-2.483GHz
<10mW
1 x speed = Approx. 0.15m/s
2 x speed = Approx. 0.27m/s
Solution
Ensure that the power switch is pressed
and the battery is sufficiently charged
Check the ground is suitable and the
wheels are free from dirt
Ensure the sound button is pressed and
the battery is sufficiently charged
Recharge by plugging in the USB cable
Switch the product off and on again to
reset.
Press the obstacle avoidance button - it
should illuminate green when active.
Ensure the obstacle is high enough to
trigger the sensor - small objects may not
be seen by the sensor.
