TTS Rugged Robot User Manual page 4

o Mode 3 - Button will flash and Robot will not pause between each sequence
when travelling in a straight line, and additionally the turns will be faster for better
performance on uneven surfaces.
¥ There is a light sensor which will automatically activate the headlights when the Robot
enters a darker environment.
Status LED's
¥ There are 6 segments within the ring around the command buttons, during each step
these will light green to indicate the command being carried out.
¥ When first turned on the segments will light to indicate the battery level, more
segments indicate the Robot has more charge.
¥ When connected to Bluetooth the segments will light blue.
¥ In programming mode the lights will flash yellow to indicate the button has been
pressed.
Recharging
¥ Turn off the Power to charge, the Robot will not work whilst charging.
¥ To recharge the Robot use the USB cable provided by inserting the DC Jack into the
charging socket and the USB into a USB socket or a suitable 5V 1A power supply.
¥ During charging the segments will light green in turn to indicate the charge level.
¥ Charging will take approximately 1-2 hours to fully charge.
¥ Once fully charged your Robot will give 1-2 hours running time in normal use.
Compatibility
¥ Rugged Robot will operate with an iOS or Android device containing compatible Blue-
tooth hardware. Please download the App from either Google Play or the App store.
Rugged Robot is compatible with the following operating systems:
Android:
◦ Android 5.0(Lollipop) Minimum
◦ Android 5.1(Lollipop)
◦ Android 6.0(Marshmallow)
◦ Android 7.0(Nougat)
◦ Android 7.1(Nougat)
◦ Android 8.0(Oreo)
◦ Android 8.1(Oreo)
◦ Android 9.0(Pie) Latest
