POWERNAIL
CO.
Models 445FS Pneumatic PowerStapler™
OPERATION AND MAINTENANCE MANUAL
MANUAL DE OPERACION Y DE MANTENIMIENTO
MANUEL D'INSTRUCTIONS ET D'ENTRETIEN
WARNING
Read this manual before you use this PowerStapler®. Follow all safety warnings and
instructions. If you are uncertain about the operation of the stapler, call us directly
at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help.
Please retain this information for future reference.
rev. 2019.04.09
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Powernail PowerStapler 445FS
Summary of Contents for Powernail PowerStapler 445FS
- Page 1 Read this manual before you use this PowerStapler®. Follow all safety warnings and instructions. If you are uncertain about the operation of the stapler, call us directly at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help. Please retain this information for future reference.
-
Page 2: Table Of Contents
10 years from date of purchase, (“warranty period”); shall be free of defects in materials and workmanship and will meet POWERNAIL’s specifi cations in eff ect at the time of Product shipment. POWERNAIL will repair or replace, at its option, any Powernailer® that does not conform to this warranty. -
Page 3: Safety Instructions
Stapler is intended for use installing wood fl ooring and is not to be used for purposes not specifi ed in the operations manual. Do not use any nails other than Powernail Powercleats Nails which are specifi cally designed for use in any Powerstapler. Powercleats Nails are available in various lengths. Contact your Powernail Dealer for Powercleats Nails. -
Page 4: Operating Instructions
OPERATING INSTRUCTIONS Consult the staple depth chart for the appropriate of Air Tool Oil, supplied with your Stapler, into the adapter pad to use with the thickness of fl ooring disconnected air line male connector attached to the you are installing and the selection of Powerstaple® Stapler. -
Page 5: Parts & Service
OPERATING INSTRUCTIONS, continued WARNING: Never work on the Stapler if the air line OPERATING STAPLER: is attached. Always disconnect the air line from the To use the Model 445FS, simply place the stapler on the Stapler fi rst. fl oor, pull nailer back so locating ears catch the edge Stapler DISASSEMBLY: of the fl... -
Page 6: Seal Replacement
OPERATING INSTRUCTIONS, continued SEAL REPLACEMENT: There are 7 seals that may should slide out of the Stapler Body when you pull out require replacement. We recommend that you have your the Driving Blade Assembly. PowerStaple Dealer replace the Seals. 2.) Remove the metal Support Ring (#19) and Rubber Seat from inside the Stapler body. - Page 7 Pneumatic Light Air Tool Oil lubricant. For Step-by-Step Videos and Instructions, Visit our Web Site at: www.Powernail.com REASSEMBLING THE Stapler: 1.) Be sure the Rubber Seat, Support Ring and Cylinder are installed in the Body and are facing the correct way.
-
Page 8: Parts List
MODELS 445FS PARTS LIST For this parts list and other Powernailer schematics, please visit the Powernail Parts Store at http://www.powernail.com PART NO. DESCRIPTION QTY REQ TU SEAL AVAIL ITEM 09-44529320 BODY 09-445293150 CAP (LOW PROFILE) 09-50P3202 1/4-20 X 5/8” S.H.C.S. W/PATCH (CAP) - Page 9 MODELS 445FS PARTS LIST, CONTINUED PART NO. DESCRIPTION QTY REQ AVAIL ITEM # 09-44529705 ADAPTER FOOT 09-44529819 .030 PLASTIC SHIM 09-44529757 1/4-20 x 1/2” F.H.C.S. w/Patch (PAD) 09-44529736 1/2” ADAPTER PAD (Accessory) 09-44529737 5/8” ADAPTER PAD (Standard) 09-44529738 3/4” ADAPTER PAD (Standard) 09-44529802 HEX WRENCH 5/32 KEY: S=Sold Separately, A= Sold as part of assembly, TU=Tune-up Kit, F=Factory replacement only, or Seal Kit.
-
Page 10: Seal Locations Diagram
Pneumatic Seal Part Numbers and Locations... -
Page 11: Schematic
Part #: 09-445FSTUKIT Schematic #'s: 4, 10, 11, 12, 17, 18, 21 Schematic #'s: 4, 7, 10, 11, 12, 14, 15, 17, 18, 21, 22, 24, 28, 29, 35, 36 For Step-by-Step Videos and Instructions, Visit our Web Site at: www.Powernail.com... -
Page 12: Safety Labels
STAPLER SAFETY DECALS Warning! • Read and understand the tool labels and manuals before operating. • Operators and others in work area MUST wear EYE and EAR protection. • Use safety glasses with side shields. • NEVER point tool at yourself or others in the work area. -
Page 13: Troubleshooting Chart
PowerStapler 445FS Trouble Shooting Chart PROBLEM POSSIBLE CAUSE SOLUTION 1. Zero of Low air pressure Check air supply for 80 psi minimum to 110 psi maximum 2. Lack of lubrication Manually lubricate through male air inlet fi tting 3. Excessive dirt inside Stapler... -
Page 14: Depth Chart
POWERSTAPLE DEPTH CHART This chart will assist you in determining the proper length ® of PowerStaple to use for various thicknesses of fl ooring. Approximate vertical penetration of the PowerStaple under the hardwood fl oor is shown for each application. This is only a guide. -
Page 15: Fasteners
15.5-GAUGE POWERSTAPLES 15.5 Gauge PowerStaples™ Powernail Powerstaples fl ooring have the strength and holding power you need to build a fl oor you can depend on. The Carbon Steel Powerstaples are designed for use with the Tongue and Groove PowerStapler 445FS, but can be used with all 15-15.5 gauge 1/2″ crown fl ooring staplers. -
Page 16: Accessory Products
Part number: PALM001 Pneumatic PowerPalm™ FLEX Power Roller Conversion Kit (for Models 445, 445FS) When comfort and control make the diff erence, Powernail’s new Tri-Glide Power Roller Conversion Kit allows the 445LS or 445FS to convert into a Tri-Glide Power Roller.
