Powernail FLEX Conversion Kit Operation And Maintenance Manual

For the model 50p 18-gauge nailer
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Operation and Maintenance Manual
Powernail FLEX Conversion Kit
A truly FLEXIBLE nailer, the FLEX is built to install 3/8" to 3/4"
Tongue & Groove fl ooring without the use of pads or shims.
Read this manual before you use the Powernail FLEX. Follow all safety warnings and instructions. If you are
uncertain about the operation of the Powernail FLEX foot, call us directly at 1-800-323-1653 for assistance
or contact the closest Powernail Dealer for help. Please retain this information for future reference.
POWERNAIL
1300 Rose Road, Lake Zurich, IL 60047
Phone: 1-800-323-1653
Website: www.powernail.com
For the Model 50P 18-Gauge Nailer
WARNING
®
CO.
REV 12.7.17

Advertisement

loading
Need help?

Need help?

Do you have a question about the FLEX Conversion Kit and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Powernail FLEX Conversion Kit

Summary of Contents for Powernail FLEX Conversion Kit

  • Page 1 Tongue & Groove fl ooring without the use of pads or shims. WARNING Read this manual before you use the Powernail FLEX. Follow all safety warnings and instructions. If you are uncertain about the operation of the Powernail FLEX foot, call us directly at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help.

  • Page 2: Operation

    POWERNAIL FLEX Adding to the fl exibility of the Powernail Groove fl ooring as well as some 3/4" exotics, bamboo, FLEX, the new Power Roller speeds up the and other solid wood fl ooring. installation and requires less effort on the The Powernail Flex uses an 18 gage Powercleat part of the installer.
  • Page 3 FLEX Foot Adjustment: FLEX Adjustment Lever Wood varies from one manufacturer to the next. The different wood profi les may be due Figure 1. to height and length of the fl ooring tongue and whether or not there is a nail pocket. First, loosen the two hex bolts under the FLEX foot with the Allen Wrench supplied with the nailer.
  • Page 4 INSTALLING THE FLEX ADJUSTABLE FOOT Nailer Disassembly: Remove any remaining Powercleats ® nails from the nail channel. Mount the nailer upside-down in a padded vise. Using a 3/16” hex Allen wrench, loosen the (4) hex screws (with Figure 1. lock washers) from the base of the existing nailer foot (see fi...
  • Page 5 INSTALLATION (continued) Slide the FLEX foot sideways onto the nailer and nail channel Figure 3. (see fi gure 3). Line up the 4 screw holes for each component; the foot, the nail channel, and the nailer body. Figure 4. Replace and tighten the (4) hex screws (with lock washers) using the 3/16”...
  • Page 6 A-17, A-18, A-19 09-50P3102 1/4"-20 x 3/4"L FHCS S, A-17, A-18 09-44529802 Hex Wrench 5/32" S, A-17, A-18 Powernail FLEX Assemblies, Kits and Accessories ITEM PART NO. DESCRIPTION 09-200-3058A Seal Kit (1 Each Of All Seals) 09-445-29759A Long Handle Assembly...
  • Page 7 Powernail FLEX Schematic For this and other Powernailer schematics, please visit the Powernail Parts Store at http://www.powernail.com 48 54 76 78 FLEX Tri-Glide Conversion Parts.
  • Page 8 Visit www.Powernail.com • Dealer Locator • Repair Tech Videos • Rental Locator • Cool Tools Cleat Calculator • Parts Store • Cleat Depth Chart • Product Information • Training Schools Featured Accessory Products Powerjack® Model 500 Truly a Tinker's TOOL, the POWERJACK Model 500 is designed to push or pull fl...
