bolid S2000-BI Instruction Manual

1.1 General
1.1.1 S2000-BI / S2000-BI Rev.02 Indicator Module (hereinafter referred to as the module) is
designed to operate as a part of an Orion integrated security system under the network controller
(S2000M control panel or Orion Pro Software Suite) together with control and indicating equipment
Signal-10, Signal-20, Signal-20M, Signal-20P Rev.01, Signal-20P SMD, S2000-4, or S2000-KDL
polling loop controller. To be part of a modular control and indicating device the module shall be
used only with an S2000M control panel of versions 3.00+.
1.1.2 The module provides light and sound indication of conditions of partitions (zones). The
module is to be installed inside protected premises and is intended for round-the-clock operation.
1.1.3 For monitoring a fire alarm system use the Fire Alarm indication type, and for
monitoring fire-fighting equipment use the Operated Appliance indication type.
1.1.4 The module is not intended to be operated in aggressive and dusty environments and in
ex-hazardous premises.
1.2 Specifications
Light Indication
Built-in Buzzer
Tamper Switch
RS-485 Port
(to operate as part of an Orion ISS)
Power Voltage
Consumed Power
Consumed Current
Alarm mode
Quiescent mode (all LEDs are off)
Pre-operation Time
Weight
Programming
External Reader
Content of precious materials: not subject to inventory accounting in case of storage, disposal
and recycling.
1.3 Standard Delivery
1) S2000-BI (S2000-BI Rev.02) Indicator Module
2) Instruction Manual
3) Woodscrew 1-3×25.016 GOST 1144-80 with Wall Plug 6х30
4) Package
INDICATOR MODULE
S2000-BI, S2000-BI Rev.02
INSTRUCTION MANUAL
1 TECHNICAL INFORMATION
- 60 two-color LEDs to indicate conditions of up to
60 partitions of Orion ISS
- 8 single-color LEDs to display alarms and troubles
in Orion ISS
- One LED to indicate the module conditions
- One LED to show that a sound is silenced
- One LED to show whether or not operating by
iButton is permitted
- Yes
- Yes
- Yes
- 10.2 – 28.4 VDC.
Bolid manufactured battery backed power supplies
of RIP-12 and RIP-24 series are advised to be used
- 3 W max
- 200 mA max at 12 VDC
- 100 mA max at 24 VDC
- 50 mA max at 12 VDC
- 50 mA max at 24 VDC
- 2 s max
- 0.6 kg max
- By means of UProg.exe
- One iButton reader can be connected to
– 1 pc.
– 1 copy
– 3 pcs.
– 1 pc.
