bolid S2000-SP4/220 Instruction Manual

Addressable executive module

Advertisement

Quick Links

1.1
General
1.1.1 This Instruction Manual describes S2000-SP4/220 Addressable Executive Module along
with its operation algorithms and characteristics.
1.1.2 The module is used as part of a multipart executive device in fire and intrusion alarm
systems under control of an S2000-KDL ver.2.01+ or S2000-KDL-2I ver.1.00+ controller and an
S2000M console.
1.1.3 Meeting requirements for sound and light indication of control and indicating equipment
is provided together with the S2000-KDL and S2000M.
1.1.4 The module is designed to monitor and control fire dampers, smoke control dampers,
deluge valves, and other executive devices powered by mains power 220 V.
1.1.5 The module is to be attached at a suitable place (on a wall, above a suspended ceiling, or
on another constructions near the connected executive device) protected against atmospheric
fallouts, mechanical damage, and unauthorized access. The module is designed for round-the-clock
1.1.6 The module must not be used in aggressive medium or dust condition, or in explosion-
hazardous premises.
1.1
Specifications
1) Input Voltage
2) Insulating Voltage of the Polling Loop
and Executive Part
3) Consumed Current:
4) Outputs
5) Max Switching Current per an Output
6) Switching Voltage
7) Circuit Control Current
8) Monitored Limit Switches
9) Pre-Operation Time
10) Operating Temperatures
11) Humidity
12) Overall Dimensions
13) Weight
14) Ingress Protection Rating
ADDRESSABLE EXECUTIVE MODULE
S2000-SP4/220 Ver 1.04
INSTRUCTION MANUAL

1 TECHNICAL DATA

Communication Part
Executive Part
Communication Part
Executive Part
– 8 V to 12 V via the polling loop
– An external power supply, 220 V ac
– Up to 500 V
– 1.5 mА max
– 50 mА max(without regard to output's current)
– 2
– 3 А
– 220 V
– 0.5 mА max
– 2
– 15 s max
– Minus 30°C to +55°С
– 93 % at +40°С
– 156 mm × 107 mm × 39 mm
– 0.2 kg max
– IP20
– IP30, if wall mounted
Table 1. Specifications
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S2000-SP4/220 and is the answer not in the manual?

Questions and answers

Summary of Contents for bolid S2000-SP4/220

  • Page 1 INSTRUCTION MANUAL 1 TECHNICAL DATA General 1.1.1 This Instruction Manual describes S2000-SP4/220 Addressable Executive Module along with its operation algorithms and characteristics. 1.1.2 The module is used as part of a multipart executive device in fire and intrusion alarm systems under control of an S2000-KDL ver.2.01+ or S2000-KDL-2I ver.1.00+ controller and an S2000M console.
  • Page 2 Standard Delivery Table 2. Standard Delivery Item Q-ty S2000-SP4/220 Addressable Executive Module Instruction Manual Woodscrews Wall Plugs 6×30 Flat Head Tapping Screw 2.2х6.5 MF 1/4W-8k2-5% Resistor Fuse 3.15 A (the spare part) Fuse 0.25 А (the spare part) Package 2 OPERATION Outputs 2.1.1...
  • Page 3 1N5406 diode if the operational current exceeds 1А). The diodes must be brought closely to the executive device (see Figure 1). 2.1.6 If the control voltage is 5 V and the load effective resistance exceeds 50 kOhm (the voltage between terminals of the output exceeds 4 V), a resistor with resistance less than 50 kOhm and the relevant wattage (47 kOhm &...
  • Page 4 Power Inputs 2.4.1 The module monitors input power voltage at the power inputs during operation. 2.4.2 Status of powering the module is indicated by READY LED. 2.4.3 If power voltage at both power inputs is between 150 V and 280 V, the module enters in the Power Norm mode and the READY LED is lit steady.
  • Page 5 Figure 1. Connection Diagram. Table 7. How to Connect an Actuator to the S2000-SP4/220 Manufacturer Article How to Connect Directly to the required output, the unused output is shunted Belimo BLF-230 by a 47 kOhm @ 2 W resistance Belimo...
  • Page 6 Uprog software. To use the module, by means of the UProg program set the Device Type in the ‘S2000-SP4/220’ value for the first of the five addresses which are to be used for the S2000- SP4/220 and, if necessary, associate S2000-KDL zones with outputs on the Dampers tab. The algorithms of setting types of addressable devices and configuration parameters are described at the exploitative documents for S2000-KDL, S2000M, and Orion Pro software.
  • Page 7 Orion Pro software and the connected S2000-KDL controller. 3.5.7 Test the damper manually by using the TEST button connected to the S2000-SP4/220 (if connected). To do so, switch the module to the Test Mode, issuing the relevant command from the network controller.
