Leviton JBL AEC80 Product Data

PRODUCT DATA
AEC80 In-Ceiling Speakers Powered by JBL
Leviton Architectural Edition

APPLICATION

When room aesthetics are critical, the AEC65
and AEC80 In-Ceiling Speakers may be used
in surround-sound installations. The JBL low-
diffraction swivel tweeter makes it easy for the
installer to optimize the sound field for a particular
room's geometry.

FEATURES

• JBL titanium-laminate drivers maintain musical
accuracy and clarity even at frequency extremes
• Straight-line Signal Path™ (SSP™) crossover
network for minimal signal distortion
• Long-excursion woofers with butyl-rubber
half-round surrounds and extended pole-piece
magnetic structures for maximum bass impact
and dynamic range
• Low-diffraction, swivel-tweeter mounting system
for optimum stereo imaging
• Heavy-duty push-type input terminals for long-
term connection integrity
• Integrated dog-ear mounting brackets (optional
rough-in kits available for pre-construction
installation in new homes)
• Acoustically transparent paintable baffles
and grilles

ORDERING INFORMATION

DESCRIPTION
Pair of 8" Two-Way In-Ceiling Loudspeakers, 100 watts, 8 ohms
8" Pre-Construction Speaker Kit for In-Ceiling Speaker
Leviton Manufacturing Co., Inc. Global Headquarters
201 N. Service Rd. Melville, NY 11747-3138 Tech Line: 1-800-824-3005 Fax: 1-800-832-9538
Leviton Manufacturing Co., Inc. Energy Management, Controls and Automation.
4330 Michoud Blvd., New Orleans, LA, 70129 Tel: 1-504-736-9810 Fax: 1-504-253-2954
Visit our Website at: www.leviton.com/emca
©2016 Leviton Manufacturing Co., Inc. All rights reserved. Subject to change without notice.
®

COUNTRY OF ORIGIN

China

PHYSICAL SPECIFICATION

• AEC80 8-inch (200 mm) Two-Way In-Ceiling
Loudspeaker
• Driver Complement: 1" (25 mm) titanium-laminate
• dome tweeter; 8 in (200mm) titanium-laminate
woofer
• Frequency Response (-10dB): 32 Hz-20 kHz
• Sensitivity (2.83V/1m): 89 dB
• Power Handling: 100 Watts
• Impedance: Nominal 8 Ohms
• Physical Dimensions and Weight:
• Diameter: 10.87" (275 mm)
• Depth: 4.25" (108 mm)
• Mounting Cutout Size: 9.5" (240 mm) diameter
• Weight: 5.6 lb/2.5 kg per speaker (sold in pairs)

WARRANTY INFORMATION

For a copy of Leviton product warranties, visit
www.leviton.com/warranty.
®
CAT. NO.
AEC80-000
AEPC8-KIT
