Superior VRE3236ZENWS Installation And Operation Instructions Manual

Outdoor decorative gas fireplace

Advertisement

P/N 900990-00 REV. C 06/2019
Ce manuel est disponible en francais,
simplement en faire la demande. Numéro
de la pièce 900990-03.
P900990-00
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
DANGER
WARNING: Do not store gasoline or other flammable vapors and liquids in the vicinity of this or any other appli-
ance. An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.
Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could
result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neigh-
bor's phone. Follow the gas supplier's instruc-
tions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
PFS
C
Report No. F14-020
WHEN USED AS AN OUTDOOR APPLIANCE
CARBON MONOXIDE WARNING
This appliance can produce
carbon monoxide which has
no odor.
Using it in an enclosed space
can kill you.
Never use this appliance in
an enclosed space such as a
camper, tent, car or home.
Installation and Operation Instructions
OUTDOOR DECORATIVE GAS FIREPLACE
Models
VRE3236ZENWS
VRE3236ZENWH
®
VRE3236ZEPWS
US
VRE3236ZEPWH
Installateur : Laissez cette notice avec l'appareil.
Consommateur : Conservez cette notice pour consultation ultérieure.
WARNING: For Outdoor Use Only.
DANGER
IF YOU SMELL GAS:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and
immediately call your gas supplier or fire depart-
ment.
AVERTISSEMENT:
RISQUED'INDENDIE OU D'EXPLOSION
Le non-respect Des avertissements de sécurité pourrait
d'entraîner des blessures graves, la mort ou des dom-
mages matériels.
- Ne pas entreposer ni utilizer d'essence ni d'autres vapeurs
ou liquides inflammables dans le voisinage de cet appareil
ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucan interrupteur. Ne pas vous servir des
téléphones se trouvant dans le bâtiment où vous trouvez.
• Sortez immédiatement de bâtiment.
• Appelez immédiatement votre fournisseur de gaz depuis
un voisin. Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz, appelez
le service des incindies.
- L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifié ou par le
fournisseur de gaz.
VRE3242ZENWS
VRE3242ZENWH
VRE3242ZEPWS
VRE3242ZEPWH
1

Advertisement

Table of Contents
loading

Summary of Contents for Superior VRE3236ZENWS

  • Page 1 Installation and Operation Instructions OUTDOOR DECORATIVE GAS FIREPLACE Models P/N 900990-00 REV. C 06/2019 VRE3236ZENWS VRE3242ZENWS Ce manuel est disponible en francais, VRE3236ZENWH VRE3242ZENWH simplement en faire la demande. Numéro ® de la pièce 900990-03. VRE3236ZEPWS VRE3242ZEPWS VRE3236ZEPWH VRE3242ZEPWH Report No. F14-020 P900990-00 INSTALLER: Leave this manual with the appliance.
  • Page 2: Table Of Contents

    Thank you for your purchase. We appreciate your business! GENERAL INFORMATION Please carefully read and follow all instructions in this manual. Pay special attention to These appliances are designed to operate all warnings and safety information. on natural or propane gas only. An electronic Following these safety, care, and operation instructions will help ensure many years of intermittent pilot ignition system provides safe, dependable and enjoyable service from your fireplace.
  • Page 3: Massachusetts Requirements

    Orifice Sizes - Sea Level To High Altitude All Models - This appliance is only for use (All Models) All models have a manually modulated gas valve. with the type of gas indicated on Input is shown in Table 1: These appliances are tested and approved the rating plate.
  • Page 4: Location

    ASSEMBLY OUTLINE Carefully consider the position of the fireplace ASSEMBLY STEPS opening with respect to the location of adjacent Before You Start or nearby stairwells, doors, windows, walkways NOTE: The following steps represent the and over hanging trees, patios and wires. normal sequence of installation.
  • Page 5: Appliance Clearances

    When Planning for the installation of the fire- place, the framing height must be increased from 46-1/2" to 47-1/4", when installing the drain pan. An additional space below the fireplace will also be required to plumb a drain line. Threaded Threaded Reducer Elbow 3/4...
  • Page 6: Clearance Specifications

    CLEARANCE SPECIFICATIONS (See Note 2) J or K = FIREPLACE OPENING = AIR SUPPLY INLET = AREA WHERE FIREPLACE IS NOT PERMITTED 2 in..clearances above grade, 3 ft. (USA) ..clearance to service regulator veranda, porch, deck or 6 ft.
  • Page 7: Fireplace Installation

    ROUTING GAS LINE TYPICAL INSTALLATION Route a 1/2" (13 mm) gas line along the inside Weatherproof of the right side framing as shown in Figure 5. Enclosure Gas lines must be routed, constructed and made of materials that are in strict accordance with local codes and regulations.
  • Page 8: Fireplace Specifications

    FIREPLACE SPECIFICATIONS Dimensions - Inches (millimeters) Dimensions - Inches (millimeters) Model Model No. 41-3/4 23-1/2 41-3/4 23-1/2 VRE3236 Polaris36 (1061) (597) (940) (940) (1061) (597) 47-3/4 29-1/2 47-3/4 29-1/2 Polaris42 VRE3242 (1092) (1213) (749) (1213) (749) (1092) (508) Weight And Volume Model Ship.
  • Page 9: Framing Specifications

    FRAMING SPECIFICATIONS Back Wall Of Corner Installation Opening VRE3236 VRE3242 Chase/Enclosure 42-3/4" (1086) 48-3/4" (1238) Including Finishing Materials If Any 46-1/2" (1181) 46-1/2" (1181) 23-5/8" (600) 29-5/8" (753) 11-1/4" (286) 14-1/4" (362) 63-1/2" (1613) 69-1/2" (1765) 31-3/4" (807) 34-3/4" (883) 20-1/2"( 521) 20-1/2"( 521) 44-1/4"...
  • Page 10: Field Wiring

    FIELD WIRING Gas Flex Line Connector CAUTION: LABEL ALL WIRES PRIOR TO DIS- 3/8" NPT x 3/8" 1/2" x 3/8" Flare CONNECTION WHEN SERVICING CONTROLS. Flare Fitting Shut-Off Valve Valve WIRING ERRORS CAN CAUSE IMPROPER AND DANGEROUS OPERATION. VERIFY PROPER OPERATION AFTER SERVICING.
  • Page 11: Installing The Logs

    Install the Logs and Glowing Embers WARNING • Turn OFF all gas and electricity to the appliance before installing the embers, and logs. • Do NOT install the logs until the appliance has been completely installed, the gas line connected and tested for leaks, and the initial burner operation has been confirmed.
  • Page 12 Installing the VRE3200 Series Log Set The logs have notches/tabs to assist proper positioning. Upper logs rest on lower logs via notches/tabs. Proper log placement is critical to prevent sooting. Place the logs in the gaps between flame peaks, so they do not impinge the flames. Follow the log placement instructions precisely.
  • Page 13 Installing the VRE3200 Series Log Set (continued) 5. Position top right log (5) using the round protrusion on the rear log (1) and the square protrusion on the middle log (2) (Figure 19). 6. Position middle twig log (6) using the pin on top right log (5) (Figure 20). Cut-out fits over protrusion on Log 2 Cut-out fits over...
  • Page 14: Burner Air Shutter Adjustments

    FLAME APPEARANCE AND SOOTING Sooting is indicated by black puffs developing at the tips of very long orange flames. Sooting results in black deposits forming on the logs, appliance inside surfaces and on exterior sur- faces adjacent to the face opening. These appliances should not smoke.
  • Page 15: Checking Appliance Operation

    CHECKING APPLIANCE OPERATION FIREBOX FINISHES Use noncombustible caulking materials only to seal the metal facing to the surround material With gas line installed run initial system check- Only noncombustible materials like marble, on the finished wall. See Figure 24. out before installing any additional accessories. stone, tile, brick, etc.
  • Page 16: Gas Conversion Kits

    GAS CONVERSION KITS WARNING Gas conversion kits are available to adapt your This conversion kit shall be installed by a qualified service agency in appliance from the use of one type of gas to the use of another. These kits contain all the accordance with the manufacturer’s instructions and all applicable codes necessary components needed to complete the and requirements of the authority having jurisdiction.
  • Page 17: Operation/Care Of Your Appliance

    OPERATION AND CARE OF YOUR All Models - WARNING APPLIANCE To light these appliances refer to the detailed FAILURE TO COMPLY WITH THE INSTAL- lighting instructions found on Page 21. The Appliance operation may be controlled by a LATION AND OPERATING INSTRUC- appliance lighting instructions may also remotely located wall switch.
  • Page 18: Variable Flame Adjustment

    IGNITER ASSEMBLY Variable Flame Height Adjustment WARNING The igniter assembly is factory preset for 1. All appliances are equipped with a variable proper ignition of the burner. Alterations may Turn off gas and any electrical • gas control valve. Flame height for these have occurred during shipping and handling.
  • Page 19: Gas Control Module System

    GAS CONTROL MODULE SYSTEM Learn Button AUX Connection REMOTE CONTROL FEATURE The module has a built in remote control receiver that allows the user to program the remote transmitter at any time during or after the instal- lation of the burner. 1.
  • Page 20: Accessory Components

    ACCESSORY COMPONENTS Drain Pan Hood Kit The drain pan is used with the appliance. This attractive brushed stainless Hood Kit is easy to install and enhances the appearance of the appliance. Drain Pan Outdoor Weather Cover Drain Pan Outdoor Weather Cover Cat.
  • Page 21: Lighting Instructions, Electronic

    LIGHTING INSTRUCTIONS, ELECTRONIC FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result caus- ing property damage, personal injury or loss of life. A. This appliance does not have a pilot, it is equipped •...
  • Page 22: Troubleshooting

    TROUBLESHOOTING WARNING: Turn off appliance and let cool before servicing. Only a qualified service person should service and repair appliance. NOTE: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When ''ON'' button on remote control 1.
  • Page 23 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Leave the building immediately. •...
  • Page 24: Maintenance Schedule

    MAINTENANCE SCHEDULE Annually (Before the onset of the Burning Season) MAINTENANCE TASK ACCOMPLISHING PERSON PROCEDURE Inspecting/Cleaning Burner, Logs Qualified Service Technician Inspect valve and ensure it is properly operating. Check piping for leaks. and Controls Vacuum the control compartment, fireplace logs and burner area. Refer to Page 17.
  • Page 25: Replacement Parts List

    REPLACEMENT PARTS Cat.# Model Description Cat.# Model Description F4118 VRE3236ZENWS 36" White Stacked, NG F4122 VRE3242ZENWS 42" White Stacked, NG F4119 VRE3236ZENWH 36" White Herringbone, NG F4123 VRE3242ZENWH 42" White Herringbone, NG F4120 VRE3236ZEPWS 36" White Stacked, LP F4124 VRE3242ZEPWS 42"...
  • Page 26 REPLACEMENT PARTS LIST VRE3236 VRE3242 Item No. Description Part No. Qty. Part No. Qty. 1, 2, 3, 4, 5 Refractory Set, White Stacked F4155 F4157 Refractory, LH White Stacked Refractory, RH White Stacked Refractory, Rear White Stacked 1H, 2H, 3H, 4H, 5H Refractory Set, White Herringbone F4156 F4158...
  • Page 27 REPLACEMENT PARTS (continued) NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
  • Page 28 REPLACEMENT PARTS (continued) VRE32 36/42 NG VRE32 36/42 LP Item No. Description Part No. Qty. Part No. Qty. Gas Train Replacement Parts List Stainless Burner F4151 F4151 Assembly, Igniter and Flame Rod J6548 J6548 Pilot Bracket F4152 F4152 Orifice Holder J6127 J6127 Orifice...
  • Page 29: Warranty

    ® 20 Year Limited Warranty THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Superior Brand gas fireplace, Stove or Insert ("Product") to be free from defects in materials ® and workmanship at the time of manufacture. The product body, firebox and barrier carry the 20 Year Limited Warranty. Ceramic glass carries the 20 Year Limited Warranty against thermal breakage only.
  • Page 30 SuperiorFireplaces.us.com Record the following important information about your fireplace: Appliance model number Appliance serial number Date appliance was Installed Type of gas appliance uses Dealer name Innovative Hearth Products (IHP) reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
