- Page 1 TECHNICAL MANUAL version 4.0 100 Yellow | 25 Magenta 100 Black...
-
Page 2: Table Of Contents
Table of Contents Manual Product Software Visum Monitor v. 4.0 v. 3.0 v. 4.4 - 4.7 TECHNICAL INSTRUCTIONS ........4 100 Yellow | 25 Magenta 100 Black System’s basic parameters ......... 4 Tweaking your system ..........6 This device contains FCC ID 2AD66-RF2401F20 Sensor’s parameters: TIME and SENSITIVITY .. -
Page 3: Technical Instructions
The MANEUVER DELAY, which is related with the time that the monitors wait to send a failure alarm or enter in a maneuver state. | J.Assy Agricultural | TECHNICAL INSTRUCTIONS TECHNICAL INSTRUCTIONS | Visum Monitor |... -
Page 4: Tweaking Your System
OR percent of sensors to enter in a maneuver state). Which one is used depends on how many sensors are present to the monitor. | J.Assy Agricultural | TECHNICAL INSTRUCTIONS TECHNICAL INSTRUCTIONS | Visum Monitor |... -
Page 5: A) If The System Has Maximum 12 Rows
After 3 seconds that the maneuver delay started S7 send a “no flow” message. Maneuver delay is reseted and starts over. After 5 seconds any other message was received: Monitor show a failure alert for row 3 and 7. | J.Assy Agricultural | TECHNICAL INSTRUCTIONS TECHNICAL INSTRUCTIONS | Visum Monitor |... -
Page 6: B) If The System Has More Than 12 Rows
5 seconds (maneuver delay) for the second Monitor alert: “no flow” message and that will go on until 8 sensors 9 10 11 Maneuver send a “no flow” message. 13 14 15 16 | J.Assy Agricultural | TECHNICAL INSTRUCTIONS TECHNICAL INSTRUCTIONS | Visum Monitor |... -
Page 7: Advanced Functions Description
13 14 15 16 confirm. The function A1 configures sensor parameters for one particular sensor and the function A2 does it for all sensor at once. | J.Assy Agricultural | TECHNICAL INSTRUCTIONS TECHNICAL INSTRUCTIONS | Visum Monitor |... -
Page 8: A1 | Configure One Sensor
NOT confi gured. To retry 11. When the monitor fi nishes the confi guration of the confi gure the missing sensors press selected sensor the display will show “ok”. | J.Assy Agricultural | TECHNICAL INSTRUCTIONS TECHNICAL INSTRUCTIONS | Visum Monitor |... -
Page 9: A3 | Configure Maneuvering Delay
If there are wireless video cameras or any other 2.4GHz wireless device in your implement, there is a chance of the camera’s radio interfere in the Visum network. If for some reason the sensors stop communicating with the monitor (e.g. no longer appears on F1 list sensor... -
Page 10: A5 | Self Test
3. Select the desired value by pressing . If a lower number is wanted just press long enough to start all the sequence again. 4. Confirm by pressing | J.Assy Agricultural | TECHNICAL INSTRUCTIONS TECHNICAL INSTRUCTIONS | Visum Monitor |... -
Page 11: Troubleshooting Table
Sensitivity level is too low and/ Increase the Sensitivity level of the sensor and/or decrease inform absence of flow. or sensor time is too high. sensor time on advanced function A1. | J.Assy Agricultural | TECHNICAL INSTRUCTIONS TECHNICAL INSTRUCTIONS | Visum Monitor |... - Page 12 _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ | J.Assy Agricultural | NOTES NOTES | Visum Monitor |...
