JBI Alpha-Doc Mk4 Operating Instructions Manual page 7

2. General
2.2.2 You will find below the different shapes of warping or any kind of out of
shape material which our machine can allow :
L
L
CAUTION
It is possible to punch acetate or similar paper only if each sheet is
interleaved with 10 sheets minimum (plain copying paper) without
any responsibility on our part insofar as the acetate may have a
diversified composition. It is advisable to contact us and to send us
some samples before any trial. We will advise you on the feasibility
of its use.
N.B.
ALPHAM4/V1
Inferior to L/2
Inferior to L/2
Make sure that you are using antistatic acetate
- 1 -
LOCATED ON THE SIDE OF THE
PICK-UP OF THE SHEET – CURVED
DOWNWARDS.
- 2 -
SPREAD OVER ALL THE SHEET –
CURVED UPWARDS.
- 3 -
SPREAD OVER ALL THE SHEET –
CURVED DOWNWARDS.
- 4 -
LOCATED ON THE SIDE OF THE
PICK-UP OF SHEET – CURVED
UPWARDS.
- 5 -
MIXED WARPING SPREAD OVER THE
SHEET.
2
Section 2 Page
SEPT 2011
