ZURN AQUASPEC Z84300-XL SERIES Technical Information

AQUASPEC FAUCETS

TECHNICAL INFORMATION

MAXIMUM PRESSURE: 125 PSI
MAXIMUM TEMPERATURE: 160
HANDLE NUT TORQUE: 15-20 FT - LBS.
CARTRIDGE STYLE: QUARTER TURN CERAMIC DISK

INSTALLATION INSTRUCTIONS

1. 1/2" IP NIPPLE SHOULD PROTRUDE 3/8" FROM THE FINISHED WALL ON 8" CENTERS. SUPPLY PIPES SHOULD BE
SECURED TO SUPPORT THE FAUCET.
2. APPLY PIPE SEALANT TO 1/2" THREADS OF SUPPLY PIPE AND SCREW SUPPLY ARM ASSEMBLY (ITEM #2) ONTO PIPE.
POSITION SUPPLIES SO THAT THE BODY CONNECTIONS END UP AT 8" CENTERS ON A HORIZONTAL PLANE.
3. INSERT SINK FAUCET BODY (ITEM #1D) TO SUPPLY ARMS PLACING GASKET (ITEM #2A) BETWEEN BODY AND SUPPLY
ARM.
4. ASSEMBLE SPOUT TO BODY USING HARDWARE.
5. INSTALL WALL BRACE BY SCREWING THE SUPPORT ROD INTO THE THREADED SPOUT CONNECTION. ADJUST THE
SUPPORT ROD TO DESIRED LENGTH AND SECURE TO FINISHED WALL USING THE TWO WOOD SCREWS PROVIDED.
NOTE: SUPPORT FOR FINISHED WALL IS RECOMMENDED WHERE WALL BRACE MOUNTS FOR MAXIMUM SUPPORT.
6. TURN WATER SUPPLY ON AND OPERATE FAUCET CHECKING FOR LEAKS.
7. IT MAY BE NECESSARY TO SHUT WATER OFF AND REMOVE CARTRIDGES TO CLEAN SUPPLY LINES. CARTRIDGES
CAN BE REMOVED BY FIRST REMOVING THE HANDLES. COLOR INDEXES CAN BE REMOVED BY INSERTING A PIN
INTO THE HOLE ON THE UNDERSIDE OF THE HANDLE. AFTER THE HANDLES HAVE BEEN REMOVED UNSCREW THE
HANDLE NUTS AND PULL OUT ON THE CARTRIDGE. ZURN WILL SUPPLY HANDLE PORT PLUGS (ZURN PART
#61094001) AT YOUR REQUEST.
8. REPLACE CARTRIDGES IN BODY AND HAND TIGHTEN HANDLE NUTS. PLACE HANDLES ON THE CARTRIDGE STEM
AND LOCATE THEM AS DESIRED. TIGHTEN HANDLE NUTS.
9. REPLACE HANDLE SCREWS AND COLOR INDEX BUTTON.
10. IF NECESSARY, INSTALL AERATOR ONTO SPOUT AND HAND TIGHTEN. IT MAY BE NECESSARY TO UNSCREW AND
CLEAN AERATOR AT START-UP.
CAUTION-FOR INSTALLATION WITH ATMOSPHERIC VACUUM BREAKERS (AVB'S)
BE USED IN INSTALLATIONS THAT ARE UNDER CONTINUOUS PRESSURE WHEN INSTALLED WITH SPOUTS HAVING
ATMOSPHERIC VACUUM BREAKERS (AVB'S). THEREFORE, NEVER PLACE A SELF-CLOSING, SHUT-OFF VALVE DOWN-
STREAM OF AN AVB.

SERVICE INSTRUCTIONS

1. YOUR ZURN AQUASPEC FAUCET IS FURNISHED WITH INTEGRAL SUPPLY STOPS (ITEM #4B) TO PROVIDE A COMPLETE
SHUT OFF OF THE WATER SUPPLY. TURN SCREW STOPS INTO BODY USING 5/16" HEX KEY WRENCH UNTIL WATER
SHUTS OFF COMPLETELY. TURN STOP NO MORE THAN THREE (3) COMPLETE TURNS TO ACTIVATE WATER FLOW.
ZURN INDUSTRIES, LLC ♦ ♦ ♦ ♦ ♦ COMMERCIAL BRASS OPERATION ♦ ♦ ♦ ♦ ♦ 2640 SOUTH WORK STREET ♦ ♦ ♦ ♦ ♦ FALCONER NY 14733
In Canada: ZURN INDUSTRIES LIMITED ♦ ♦ ♦ ♦ ♦ 3544 Nashua Drive ♦ ♦ ♦ ♦ ♦ Mississauga, Ontario L4V1L2 ♦ ♦ ♦ ♦ ♦ Phone: 905/405-8272 Fax: 905/405-1292
MODEL - Z84300-XL SERIES
SINK FAUCET
F
F
O
Phone: 1-800-997-3876 ♦ ♦ ♦ ♦ ♦ Fax: 1-919-775-3541 ♦ ♦ ♦ ♦ ♦ www.zurn.com
PAGE 1 OF 2
®
.
THIS DEVICE SHOULD NEVER
CF1576 1/14/11
