SRS Labs GMC12-WLV-3H24 Instruction Manual

Wireless controller for low voltage hoist
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Wireless Controller for
Low Voltage Hoist
Instruction Manual
Models:
GMC12-WLV-3H24, -12H6
GMC8-WLV-2H24
version 1.0 since 6 November 2018
ATTENTION!
This instruction manual contains important information about the installation and the use of
the equipment. Please read and follow these instructions carefully.
Always ensure that the power to the equipment is disconnected before opening the
equipment or commencing any maintenance work.
GMC12-WLV-3H24_en_manual_M237
(1 /16)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GMC12-WLV-3H24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SRS Labs GMC12-WLV-3H24

Summary of Contents for SRS Labs GMC12-WLV-3H24

  • Page 1 Wireless Controller for Low Voltage Hoist Instruction Manual Models: GMC12-WLV-3H24, -12H6 GMC8-WLV-2H24 version 1.0 since 6 November 2018 ATTENTION! This instruction manual contains important information about the installation and the use of the equipment. Please read and follow these instructions carefully.

  • Page 2: Important Instructions

    Safety information IMPORTANT INSTRUCTIONS All safety and operating instructions should be read before the equipment is installed or operated. IMPORTANT SAFETY INFORMATION The following general safety precautions have to be observed during all phases of operation, service, and the repair of this equipment. Failure to comply with these precautions or with specific warnings in this manual violates safety standards of design, manufacture, and the intended use of this equipment.

  • Page 3: Functions And Control

    Functions and Control Motor Controller has been designed to control from 1 to 12 electrically compatible motors, either separately or simultaneously – controlled via switches located on front panel or wireless remote/pendant. Optionally you can link GO/STOP button by link connector. Each device is equipped with unique APA /Automatic Phase Align/ module that guarantees that on any alignment of input phases the motors will move in the correct direction.
  • Page 4 To Move a single/several hoist(s): Set the UP/DOWN toggle switch for certain motor to the desired direction. The associated  LED should light green for UP, or red for DOWN direction Hold the GO button until the motor is moved the desired height, then release. ...

  • Page 5: Direction Switches

    STOP: This latching pushbutton switch turns the Hoist Control system off. Once the STOP button has been pressed, it locks the unit to OFF position and must be rotated clockwise and released before disengaging. This pushbutton switch turns the selected channels of Hoist Control system ON, when the unit is active.
  • Page 6 Link of WMC remotes: Up to two WMC remotes can be linked together to group the operation of STOP and GO buttons. To link two WMC units, 5-pin miniXLR cable with custom wire connection is needed. Never use 1:1 cable – remotes can be destroyed. When WMC remotes are linked, the GO and STOP buttons are linked –...
  • Page 7 GMC12-WLV series Base unit GMCseries front panel Hoist protection: GMC12: Each three hoists are protected by single C16/3p MCB  Power key switch positions: OFF: Power OFF /Only battery charger is active in this state/  PICKLE: Power to the hoist is enabled ...

  • Page 8: Emergency Stop

    EMERGENCY STOP: E-STOP is a red color mushroom. Once the E-STOP button has been pressed, it locks the unit into active position and must be rotated clockwise and released before disengaging. After engaging the E-STOP button, the RESET button needs to be pressed to reset the system. This green pushbutton turns the selected channels of Hoist Control system ON when is active.
  • Page 9 GMCseries rear panel (9 /16)

  • Page 10: Aux Output

    MAINS: Mains input on 1.5m cable + fuse for mains transformer T2.5A. AUX output: AUX output for additional AC230 powered devices. Protected by C16/1p breaker on the front panel. Output connectors wiring Harting 24 Female Function M2 down M2 common M2 UP M4 down M4 common...
  • Page 11 Remote/link connector Neutrik NC5-MAH/FAH Connectors are used for a link operation of LV unit or for an additional digital remote CMC-xx-DIGI connection. Up to 30 units can be linked. They are then controlled via one GO and E-STOP button in the local operation mode.

  • Page 12: Technical Data

     Front panel: 3mm steel housing with gray powder coating  Dimensions /W x D x H/: GMC12-WLV-3H24: 8U box Warranty GMCseries hoist controller comes with a 2-year manufacturer’s warranty. For extended warranty conditions, please contact the manufacturer at sales@srs-group.com.

  • Page 13: Declaration Of Conformity

    Declaration of conformity DECLARATION OF CONFORMITY According to guide lines 89/336 EEC and 92/31 EEC, 90/337 CEE Annex II A: Name of producer: SRS Group s.r.o. Address of producer: Rybnicna 36/D, SK- 83106 Bratislava, Slovak Republic www.srs-group.com/sales@srs-group.com, +421244681417 Declares that the product Name of product: GMCseries hoist controller: GMC12-WLV + GMC8-WLV + variants Types...
  • Page 14 (14 /16)
  • Page 15 (15 /16)
  • Page 16 Copyright 2018 SRS Group s.r.o. | Specifications subject to change without notice. Document:GMC12-WLV-3H24_en_manual_M237 | Version1.0| Actual as of: 6 November 2018 SRS Group s.r.o. Rybnicna 36/D | 831 07 Bratislava | Slovakia Phone: +421 2 44 681 417 | Fax: +421 2 4468 1419 Email: sales@srs-group.com | www.srs-group.com (16 /16)

This manual is also suitable for:

Gmc12-wl-12h6Gmc8-wlv-2h24
