PLUS+1® Compliant IX012-010 Function Block
IX012-010 Function Block

CAN Message Identifiers

I/O Module CAN Message Identifiers
CAN Shield Voltage [mV]
0 – 299
300 – 599
600 – 899
900 – 1199
1200 – 1499
1500 – 1799
1800 – 2099
2100 – 2399
2400 – 2699
2700 – 2999
3000 – 3299
3300 – 3599
3600 – 3899
3900 – 4199
4200 – 4499
4500 –
10 | © Danfoss | July 2018

Non-Volatile Parameters

After volatile parameters are configured, the function block sends a request for the configuration CRC to
the I/O module.
If this number matches the locally calculated value, then the configurations stored on the I/O module
match those set in the function block. If the numbers do not match, then all configuration commands are
sent and the CRC is requested again.
You can use the PLUS+1 ® Service Tool to access all non-volatile parameters on the I/O module.

Timing Configurations

Timing for messages to and from the I/O module is established after all other configurations are sent.

CAN Bus Load

Adjust the average amount of message transmissions on the CAN bus to allow for bursts and other
increased message transmission situations.
Any CAN bus has a maximum message transmission capacity. So, to allow for situations that can cause
increases in messages, minimize the CAN bus load.
The CAN bus load is the average amount of message transmission on a CAN bus. Use the PLUS+1
USB/CAN gateway and CANKing software to view CAN bus loads.
PLUS+1 ® I/O modules communicate with their associated controllers over a CAN bus. System developers
can adjust I/O module RepTime and TimeOut parameters to manage CAN bus loading. Increasing these
times reduces the CAN bus load. Decreasing these times increases CAN bus load.
The function block uses the following message identifiers to enable communication between the
controller and the I/O module.
N1 KWP2000 Node
0 0
1 8
2 16
3 24
4 32
5 40
6 48
7 56
8 64
9 72
10 80
11 88
12 96
13 104
14 112
15 120
Tx ID Rx ID
0x180 0x300
0x188 0x308
0x190 0x310
0x198 0x318
0x1A0 0x320
0x1A8 0x328
0x1B0 0x330
0x1B8 0x338
0x1C0 0x340
0x1C8 0x348
0x1D0 0x350
0x1D8 0x358
0x1E0 0x360
0x1E8 0x368
0x1F0 0x370
0x1F8 0x378
11063398 | AQ00000107en-US0101
