© 2006, THE STANLEY WORKS, ALL RIGHTS RESERVED
OPS USA
59020 - 5/2006 Ver 3
HYDRAULIC POST PULLER
Safety and Operation
PP10
User's Manual
SERIOUS INJURY OR DEATH COULD
RESULT FROM THE IMPROPER RE-
PAIR OR SERVICE OF THIS TOOL.
REPAIRS AND / OR SERVICE TO THIS
TOOL MUST ONLY BE DONE BY
AN AUTHORIZED AND CERTIFIED
DEALER.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Stanley PP10

  • Page 1 RESULT FROM THE IMPROPER RE- PAIR OR SERVICE OF THIS TOOL. REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE DONE BY © 2006, THE STANLEY WORKS, ALL RIGHTS RESERVED AN AUTHORIZED AND CERTIFIED OPS USA DEALER. 59020 - 5/2006 Ver 3...
  • Page 2: Table Of Contents

    Troubleshooting ........................10 Warranty ..........................14 SERVICING THE PP10 POST PULLER: This manual contains safety, operation, service and rou- tine maintenance instructions. Stanley Hydraulic Tools recommends that servicing of hydraulic tools, other than routine maintenance, must be performed by an authorized and certifi ed dealer.
  • Page 3: Safety Precautions

    The models PP10 Hydraulic Post Puller will provide safe and dependable service if operated in accor- dance with the instructions given in this manual. Read and understand this manual and any stickers and tags attached to the PP10 before operation. Failure to do so could result in personal injury or equipment damage.
  • Page 4 SAFETY SYMBOLS Safety symbols and signal words, as shown below, are used to emphasize all operator, maintenance and repair actions which, if not strictly followed, could result in a life-threatening situation, bodily injury or damage to equipment. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 5: Tool Stickers And Tags

    The information listed on these stickers and tags must be legible at all times. Always replace those that have become worn or damaged. Re- placements are available from your Stanley distributor. PINCH POINT...
  • Page 6 PINCH POINT WARNING PINCH POINT WARNING STICKER p/n 17572 STICKER p/n 17572 NAME TAG PP10 p/n 17573 GPM/PRESSURE STICKER p/n 16599 1. FAILURE TO USE HYDRAULIC HOSE LABELED AND CERTIFIED D DO NOT LIFT OR CARRY TOOL BY THE HOSES. DO AS NON-CONDUCTIVE WHEN USING HYDRAULIC TOOLS NOT ABUSE HOSE.
  • Page 7 SAFETY TAGS To help ensure your safety, the following DANGER tags are attached to all hose purchased from Stanley Hydrau- lic Tools. DO NOT REMOVE THESE TAGS.
  • Page 8 HYDRAULIC CIRCUIT CONTROL PANEL PRESSURE RETURN RETURN PRESSURE TOOL...
  • Page 9: Hydraulic Hose Requirements

    • Always replace hoses, couplings and other parts with replacement parts recommended by Stanley • The recommended hose size is .500 inch/12 mm Hydraulic Tools. Supply hoses must have a mini- I.D.
  • Page 10: Operation

    OPERATION diffi cult to connect. When possible, connect PREOPERATION the free ends of operating hoses together. PROCEDURES 4. Observe all safety precautions. PREPARATION FOR INITIAL 5. Move the hydraulic circuit control valve to the “ON” position to operate the tool. Each unit as shipped has no special unpacking or assembly requirements prior to usage.
  • Page 11: Troubleshooting

    TROUBLESHOOTING source is supplying the correct hydraulic fl ow and If symptoms of poor performance develop, the fol- pressure to the post puller as listed in the table. lowing chart can be used as a guide to correct the Use a fl owmeter known to be accurate. Check problem.
  • Page 13: Parts List

    Jaw, L.H. (Model PP10100A) 17541 Pivot Block 00569 Capscrew, 5/16-18 x 1 Hex Hd 03031 Lockwasher, 5/16 16599 GPM Sticker 05152 Stanley Sticker 17572 Pinch Point Warning Sticker 17573 Name Tag 19220 TFE Ring 19221 O-ring The Following Items Are Not Pictured 35213 Swivel, Hydraulic Inc.#956P6-P6...
  • Page 14: Specifi Cations

    SPECIFICATIONS Capacity (Lift per Stroke).......................8 in./20 Pulling Force........................9800 lbs/4450 Weight............................62 lbs/28 Flow Range ........................3-9 gpm/ 11-34 lpm Pressure Range........................2000 psi/140 Porting......................3/8 NPT Female Pipe Thread Connect Size ........................90° Elbow 3/8 Note Weights, dimensions, and operating specifi cations listed are subject to change without notice. Where specifi cations are critical to your application, please consult the factory.
  • Page 15: Warranty

    Stanley Hydraulic Tools (hereinafter called “Stanley”), subject to the exceptions contained below, warrants new hydraulic tools for a period of one year from the date of sale to the fi rst retail purchaser, or for a period of 2 years from the shipping date from Stanley, whichever period expires fi rst, to be free of defects in material and/or workmanship at the time of delivery, and will, at its option, repair or replace any tool or part of a tool, or new part, which is found upon examination by a Stanley authorized service outlet or by Stanley’s factory in Milwaukie, Oregon to be DEFECTIVE IN MATERIAL AND/OR...
  • Page 16: Accessories

    Hydraulic Tools 3810 S.E. Naef Road Milwaukie, Oregon 97267-5698 Phone: 503/659-5660 Fax: 503/652-1780...
