SKV20130A
V SERIES SINKER DRILL
USER MANUAL
Safety, Operation and Maintenance
7/2019 Ver. 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Stanley V Series

  • Page 1: Declaration Of Conformity

    SKV20130A V SERIES SINKER DRILL USER MANUAL Safety, Operation and Maintenance 7/2019 Ver. 4...
  • Page 2: Table Of Contents

    REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE DONE BY AN AUTHORIZED AND CERTIFIED DEALER. For the nearest authorized and certified dealer, call Stanley Hydraulic Tools at (503-659-5660) and ask for a Cus- tomer Service Representative. SKV20 User Manual ◄ 3...
  • Page 3: Safety Symbols

    SAFETY SYMBOLS Safety symbols and signal words, as shown below, are used to emphasize all operator, maintenance and repair ac- tions which, if not strictly followed, could result in a life-threatening situation, bodily injury or damage to equipment. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 4: Safety Precautions

    Operator must start in a work area without bystand- • Always replace parts with replacement parts recom- ers. The operator must be familiar with all prohibited mended by Stanley. work areas such as excessive slopes and danger- • Check fastener tightness often and before each use ous terrain conditions.
  • Page 5: Hose Types

    HOSE SAFETY TAGS To help ensure your safety, the following DANGER tags are attached to all hose purchased from Stanley Hydraulic Tools. DO NOT REMOVE THESE TAGS.
  • Page 6: Hose Recommendations

    19-40 51-100 15-30 Both 2500 This chart is intended to be used for hydraulic Pressure 2500 tool applications only based on Stanley Hy- 5-10.5 19-40 100-300 30-90 Return 2500 draulic tools tool operating requirements and should not be used for any other applications.
  • Page 7: Htma Requirements

    HTMA / EHTMA REQUIREMENTS HTMA / EHTMA REQUIREMENTS HTMA TOOL TYPE HYDRAULIC SYSTEM REQUIREMENTS TYPE I TYPE II TYPE RR TYPE III 4-6 gpm 7-9 gpm 9-10.5 gpm 11-13 gpm Flow Range (15-23 lpm) (26-34 lpm) (34-40 lpm) (42-49 lpm) 1500 psi 1500 psi 1500 psi...
  • Page 8: Operation

    OPERATION PREOPERATION PROCEDURES 3. Focus on the object you plan to work on. CHECK POWER SOURCE 1. Each sinker drill has been assembled before IMPORTANT leaving the factory, so it is necessary to check whether there is any damage caused in the shipping process or whether there is debris Never point the hose at bystanders.
  • Page 9: Troubleshooting

    TROUBLESHOOTING If symptoms of poor performance develop, the following chart can be used as a guide to correct the problem. When diagnosing faults in operation of the tool, always make sure the hydraulic power source is supplying the cor- rect hydraulic flow and pressure as listed in the table. Use a flowmeter know to be accurate. check the flow with the hydraulic fluid temperature at least 80 °F/27 °C.
  • Page 10: Specifications

    SPECIFICATIONS Weight ..............................20 kg Flow Range ............................. 20-25lpm Working pressure ............................ 90-140bar Nitrogen pressure ........................... 40bar Size ................................. 550x350x130mm Rotate speed ............................0-400rpm Drill bit diameter ............................38-50mm Max drill depth ............................3m Percussive Power ........................... 50J Torque ..............................15Nm Air compressor pressure ........................0.08m3/min , 2bar SKV20 User Manual ◄...
  • Page 11 NOTES 12 ►SKV20 User Manual...
  • Page 12: Parts Illustration

    PARTS ILLUSTRATION SKV20 User Manual ◄ 13...
  • Page 13: Parts List

    PARTS LIST Item Description MFJ0001 ROD WIPER LBK16003 OIL SEAT MFJ0145 O-RING MFJ0002 CUP SEAL BZJ0001 CIRCLIP LDHD2042 SWITCH VALVE BZJ0035 COMPRESSION SPRING LBK18004 TRIGGER BZJ0420 ROLL PIN LDHD2041 HANDLE LDHD2040 HANDLE FIXING BOLT LBK18005 HANDLE GRIP LBK18033 3/8 FEMAIE COUPLER LBK18034 3/8 MALE COUPLER LBK18032...
  • Page 14 LDHD2019 INLET BOX LDHD2034 SPONGE LDHD2033 FILTER SPONGE LDHD2018 INLET BOX CAP BZJ0164 WASHER BZJ0342 WASHER BZJ0364 M6*20 HEX SOCKET SCREW LDHD2031 SEAL LDHD2022 PISTON LDHD2027 BEARING SLEEVE LDHD2016 PISTON BUSH BZJ1204 SPRING MFJ0014 O-RING BZJ1203 SPRING BZJ0091 STEEL BALL LDHD2011 ROTATE VALVE CAP MFJ0120...
  • Page 15 Hefei INTACA Science-Technology Development Co.,Ltd. Add: A-7 Building Gongtou-Liheng Industry Square, Western Section Fanhua Street(the Cross Wenshan Road),Hefei,Anhui,China Tel:0551-63498781/2/3 Fax:0551-63498780 P.C.:230601 http://www.stanleyinfrastructure.com.cn/...
