- Page 1 USB4485 USB to 4 ports RS485/422 converter User manual Shenzhen 3onedata Technology Co.,Ltd Tel: +86-755-26702688 Fax: +86-755-26703485 www.3onedata.com...
-
Page 2: Table Of Contents
USB4485 User Manual Contents 1. Introduction ............................3 2. Packing List ............................3 3. Features ..............................3 4. Specifications ............................3 5. Panel Layout ............................4 5.1 Front Panel............................4 5.2 Front Panel............................4 5.3 RS-232 Pinout..........................5 6. Dimension ............................... 5 7. Driver Installation ..........................5... -
Page 3: Introduction
PC. Edge port USB-to-Serial converters are intelligent expansion units that connect to a PC, thin client or server via a USB port. USB4485 provides four RS-485/422 serial ports, is compliant with USB 1.1 and 2.0 specifications, and meet the 480 Mbps high-speed requirement of Hi-Speed USB 2.0. -
Page 4: Panel Layout
USB4485 User Manual Transmission: 1200m Interface protection: 1500W surge protection,15KV ESD protection Baud rate: 300bps to 230400bps Parity: None, Even, Odd, Space, Mark Data bits: 7, 8 Stop bits: 1, 2 Flow Control: RTS/CTS, XON/XOFF FIFO: 128bytes Driver Support Operating System: Support Windows98/ME and Windows2000/XP,Windows Server... -
Page 5: Rs-232 Pinout
USB4485 User Manual Power input jack: 5VDC power supply 5.3 RS-485/422 Pinout RS-485: 1 D-(B) 2 D+(A) RS-422: 1 TX-(B) 2 TX+(A) 3 RX+(A) 4 RX-(B) DB9M 6. Dimension 7. Driver Installation 7.1 Installing the Driver for the Converter(first time use the USB4232) The operating system will automatically detect the USB232. - Page 6 USB4485 User Manual Product information prompting: USB to RS485/422 Driver installation guide. Select Yes, this time only. Click Next to start the installation. installation path. III. Select the rogram loading. IV. P Page 6 of 9...
- Page 7 USB4485 User Manual oader success, indicates that Windows has completed the driver installation. Click V. L Finish to proceed with the rest of the installation procedure. installation path again. VI. Found virtual port elect the Page 7 of 9...
-
Page 8: Change Serial Port Properties
You can see them in Device Manager as follows(COM4~COM7): 7.2 Configuring serial port properties After the driver has been installed, use Windows’ Device Manager to configure the USB4485 serial ports. (click Start → Settings → Control Panel → System, select the Page 8 of 9... - Page 9 USB4485 User Manual Hardware tab, and then click Device Manager. ) Right click the serial port, select properties, you can see the information of serial port properties in General, Port Setting, Driver, Details (generally, configuring is not necessarily, cause USB4485 can automatically detect data Select Advanced settings for COM, you can redistribute the port.(If you click the Restore...
