Model
AC Section (PD4500)
AC Section (PD4300)
DC Section
Converter Section
* Consult local regulatory authority for possible branch circuit restrictions
Breakers: Recommended breakers rated maximum 50A for PD4500 series and 30A for PD4300 series
The following breakers are
suitable for MAIN and
BRANCH breakers
ITE/Siemens—QP,QT
Thomas & Betts—TB & TBBD
Series
Square D—HOM, HOMT
Cutler Hammer/Bryant—
BR,BRD Series
GE—HACR
PROBLEM
No Output
Low Output
Intermittent or no Output
on Generator, works on
Shore Power
Open Fuse Indicator
(See page 1 for location)
Consult a licensed electrician or an RV technician for installation assistance
(Specifications subject to change without notice)
PD4345 / PD4545
120 VAC 50A Maximum Output - 12 Branch Circuits Max.
120 VAC 30A Max. - 7 Branch Circuits Max.*
12 VDC 60A Max.
Input: 105-130 VAC
50/60 Hz
725 Watts
Output: 13.6 VDC,
45 Amps
Weight: 8 lbs
50 Amp
MAIN
50A Dual
TROUBLE SHOOTING GUIDE
POSSIBLE CAUSES
120 VAC supply not connected
Reverse battery fuses blown
(See page 1 for location)
Short circuit
Unit has shutdown due to overheating
Unit has shutdown due to over voltage
(Converter will shut down if the input voltage exceeds 132 VAC)
Compartment gets too hot
Excessive load for converter
Input voltage not between 105-130 VAC
Bad battery cell(s)
Unit has shutdown due to over voltage.
Some generators exhibit excessive voltage spikes
on the AC power output, this may cause the over
voltage protection to shut the unit down
Fuse open.
Specifications
PD4360 / PD4560
240/120 VAC 50A Maximum Input
12 VDC 80A Max.
Input: 105-130 VAC
50/60 Hz
1000 Watts
Output: 13.6 VDC,
60 Amps
Weight: 8 lbs
30 Amp 45/60 Amp
MAIN Converter
Branch
30A 15A
Connect power supply
Check AC distribution panel for proper operation
Check for reverse battery connection.
Replace fuses with same type and rating (See page 2)
Trace RV circuits for possible fault
Check air flow
Allow unit to cool
Check input voltage
Correct input voltage
Check air flow to the converter
Improve ventilation to the compartment
Reduce load requirements or install larger converter
Correct input supply voltage
Replace battery
Add another load to the generator, this may reduce the "spikes" to
an acceptable level
Contact generator manufacturer for possible defect in the generator
Replace fuse with same type and rating.
PD4590
-
12 VDC 100A Max.
Input: 105-130 VAC
50/60 Hz
1550 Watts
Output: 13.6 VDC,
90 Amps
Weight: 10 lbs
90 Amp Con-
verter Branch Filler Plate
ITE/Siemens QF3
20A GE TQLFPI
ACTION
Page 3
