I.
LIMITED WARRANTY: Progressive Dynamics Warrants its power inverters to be free from defects in material or workmanship under normal use and ser-
vice; and limits the remedies to repair or replacement.
II.
DURATION: This warranty shall extend for a period of two years from the original date of purchase, and is valid only within the continental limits of the
United States and Canada.
III. WARRANTY EXCLUSIONS: This warranty does not apply to:
A.
Any product which has been repaired or altered in any way by an unauthorized person or service station
B.
Damage caused by excessive input voltage, misuse, negligence, or accident; or an external force
C.
Any product which has been connected, installed, or adjusted or used other than in accordance with the instructions furnished, or has had the serial number
altered, defaced, or removed
D.
Cost of all services performed in removing and reinstalling the power inverter
E.
ANY LOST PROFITS, LOST SAVINGS, LOSS OF USE OF ENJOYMENT OR OTHERINCIDENTAL DAMAGES ARISING OUR OF THE USE OF,
OR INABILITY TO USE, THE PRODUCT. THIS INCLUDES DAMAGES TO PROPERTY AND, TO THE EXTENT PERMITTED BY LAW, DAM-
AGES FOR PERSONAL INJURY. THIS WARRANTY IN IN LIEU OF ALL OTHER WARRANTIES, INCLUDING WARRANTIES OF MER-
CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSES.
IV. PROOF OF PURCHASE: A warranty claim must be accompanied by proof of the date of purchase.
V.
CLAIM PROCEDURE: Upon discovery of a defect, Progressive Dynamics shall be supplied the following information a the address listed below:
A.
Name and address of claimant
B.
Name, model, and serial number of the product
C.
Name year and model of the recreational vehicle in which the product was installed
D.
Date of purchase
E.
Complete description of the claimed defect
Upon determination that a warranty claim exists (a defect in material or workmanship occurring under normal use and service) the inverter shall be shipped postage
prepaid to Progressive Dynamics together with proof of purchase. The product will be repaired or replaced and returned postage prepaid.
Mail Returns to: Progressive Dynamics
507 Industrial Road
Marshall, MI 49068
For Warranty Service Call: (269) 781-4242
Record the unit's model and serial number in case you need provide this information in the future. It is
much easier to record this information now, instead of trying to gather it after the unit has been installed.
© 2018 Progressive Dynamics Enterprises, LLC. All rights reserved.
Installation and Operation Guide for
Model: Serial Number:
PD1201 (Remote Display)
Consult a licensed electrician or RV technician for installation assistance
PD1201 Inverter Remote Display
See website www.progressivedyn.com
for more trouble shooting information and return instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the PD1201 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Progressive Dynamics PD1201

  • Page 1 PD1201 Inverter Remote Display Member LIMITED WARRANTY: Progressive Dynamics Warrants its power inverters to be free from defects in material or workmanship under normal use and ser- vice; and limits the remedies to repair or replacement. DURATION: This warranty shall extend for a period of two years from the original date of purchase, and is valid only within the continental limits of the United States and Canada.
  • Page 2 Included Items & Connecting the Remote The PD1201 Remote Display is designed for use with all PD1200 Series Inverters. The remote will allow complete monitoring of your in- verter. This guide will help you install and use the remote control to monitor the functions of your inverter.
  • Page 3 Using the Controls Select Button Display Power Button Figure 3 Inverter Remote Display Figure 4 Remote Display Panel ERROR CODES Error Code Condition Description Low battery volt- Input voltage has dropped beneath 10.5V for age detected several seconds. The PD1200 Series inverter will automatically restart when the input Display Features voltage reaches 12.0V.
  • Page 4 2.250 MOUNTING HOLE Figure 5 PD1201 Remote Display Mounting Template Installing the remote display on the wall 1. Place the template on the wall. 2. Mark the corners (or trace the dotted lines) of the recess outline on the wall.
