Troubleshooting Guide - Progressive Dynamics PD4045 Installation And Operation Manual

AC RATING
COPPER WIRE ONLY. RATED 75 C MIN
MAXIMUM SERVICE: 30 AMPS, 120V 50/60 HZ SINGLE PHASE
LINE TERMINALS SIZE 6-14 AWG
LOAD TERMINALS SIZE 6-14 AWG
NEUTRAL AND GROUND SIZE 6 - 14 AWG
SHORT CIRCUIT CURRENT RATING:
SUITABLE FOR USE ON NO MORE THAN
120 VOLTS AC, 10,000 AMPERES MAX,
LIMITED TO THE LOWEST INTERRUPTING
CAPACITY OF ANY BREAKER INSTALLED
NEUTRAL/GND WIRE COMBINATIONS:
(1) #12 STRANDED & (1) #14 SOLID
(1) #12 STRANDED & (1) #14 STRANDED
(1) #12 SOLID & (1) #14 STRANDED
(1) #12 SOLID & (1) #14 SOLID
(2) #14 STRANDED OR (2) #14 SOLID
(2) #12 STRANDED OR (2) #12 SOLID
(2) #10 STRANDED OR (2) #10 SOLID
Model
AC Section
DC Section
Converter
Section
* Consult local regulatory authority for possible branch circuit restrictions
PROBLEM
120 VAC supply not connected
Reverse battery fuses blown
(See page 2 for location)
Short circuit
No Output
Unit has shutdown due to overheating
Unit has shutdown due to over voltage
(Converter will shut down if the input voltage exceeds 132 VAC)
Compartment gets too hot
Excessive load for converter
Low Output
Input voltage not between 105-130 VAC
Bad battery cell(s)
Unit has shutdown due to over voltage.
Intermittent or no Output
on Generator, works on
Some generators exhibit excessive voltage spikes on
Shore Power
the AC power output, this may cause the over voltage
protection to shut the unit down
Consult a licensed electrician or an RV technician for installation assistance
(Specifications subject to change without notice)
PD4045
120 VAC 30 Amps Maximum - 7 Branch Circuits Max *
12 VDC 60A Max. - 12 Branch Circuits
Input: 105-130 VAC 50/60 Hz
725 Watts
Output: 13.6 VDC,
45 Amps
Weight: 5.70 lbs

TROUBLESHOOTING GUIDE

POSSIBLE CAUSES
MAXIMUM CONTINUOUS LOADS ON
MAINS OR BRANCH CIRCUITS NOT TO
EXCEED 80% OF THE CIRCUIT
BREAKER RATINGS
LINE TERMINAL: SEE CIRCUIT BREAKER
Specifications
12 VDC 75A Max - 12 Branch Circuits
Input: 105-130 VAC 50/60 Hz
Connect power supply
Check AC distribution panel for proper operation
Check for reverse battery connection.
Replace fuses with same type and rating (See page 2)
Trace RV circuits for possible fault
Check air flow
Allow unit to cool
Check input voltage
Correct input voltage
Check air flow to the converter
Improve ventilation to the compartment
Reduce load requirements or install larger converter
Correct input supply voltage
Replace battery
Add another load to the generator, this may reduce the "spikes" to an
acceptable level
Contact generator manufacturer for possible defect in the generator
TORQUE DATA
NEUTRAL BAR & GROUND:
#4 - #6 35 IN. LBS
#8 30 IN. LBS
#10 - #14 25 IN. LBS
PD4060
1000 Watts
Output: 13.6 VDC,
60 Amps
Weight: 6.35 lbs
ACTION
Page 3
