Depth Measurement 45º Angle Method - SubSurface Instruments PL-VF Series User Manual

d
Move to the location you want to measure depth. Stay at least 15 feet away from the t
Move the r
1. Mark the path on the ground as precisely as possible using the Null method.
2. Place the r
Bubble Level on top of the meter is centered (45º).
3. Pull the r
centered.
4. When the receiver indicates a Null reading, mark the location of the receiver's foot.
5. The distance between the r
depth reading may be caused by nearby buried metallic objects, such as a second cable, pipe,
sewer, fence or railroad track.
6. Confirm the depth measurement by repeating the above steps on the opposite side of the pipe or
cable.
7. A variance greater than 5 inches in depth measurement may indicate interference from adjacent
cables, pipes or other objects.
18
SERIES
m
epth easurement
left to right across the path until the cable is located.
eceIver
on the ground with the LCD meter facing up. Position the unit so that the
eceIver
away from the cable path (at 90º to the cable path) keeping the Bubble Level
eceIver
eceIver
Bubble level
centered
2nd
Null
45º a m
ngle ethod
and the cable path is the depth of the pipe or cable. A false
1st
Path
Null
locate
Depth
45°
Buried cable or pipe
(end view)
ransmItter
Earth
