- Page 1 Installation and Operating Instructions ABSOLYTE GX Batteries ® SECTION 92.80 2012-04...
- Page 2 TABLE OF CONTENTS SECTION 1: GENERAL ...........................6 SECTION 2: SAFETY MESSAGES .........................6 Sulfuric Acid Electrolyte Burns ....................6 Explosive Gases..........................6 Electrical Shock and Burns ......................6 2.2.1 Static Discharge Precautions for Batteries..................6 Safety Alert ..........................6 Important Message........................6 SECTION 3: DELIVERY INFORMATION ......................6 Receipt of Shipment ........................6 Concealed Damage........................7 SECTION 4:...
- Page 3 SECTION 7: SYSTEM ARRANGEMENTS ....................11 Module Arrangements .......................11 SECTION 8: SYSTEM ASSEMBLY ........................11 Module Assembly Identification ....................11 Bottom Supports (I-beams) .......................11 Handling of Modules........................12 Tip Over Procedure ........................12 Horizontal-Multiple Stacks ......................13 8.4.1 Stacking Base Modules ......................13 8.4.2 Stack Tie Plates.........................13 8.4.3 Horizontal Stacking........................14 SECTION 9:...
-
Page 4: Table Of Contents
SECTION 13: BATTERY OPERATION......................17 13.0 Cycle Method of Operation......................17 13.1 Floating Charge Method ......................17 13.2 Float Charge - Float Voltages....................17 13.3 Recharge ...........................19 13.4 Determining State-of-Charge ....................19 13.5 Effects of Float Voltage......................19 13.6 Float Current and Thermal Management ..................19 13.7 AC Ripple ..........................19 13.8 Ohmic Measurements .......................19... - Page 5 LIST OF ILLUSTRATIONS PAGE FIGURE DESCRIPTION Fig. 1 Typical System Spacing Fig. 2 Packaged Modules Fig. 3 Unpacking Modules Fig. 4 Handling - Lifting Strap Placement Fig. 5 Handling - Module Fig. 6 Typical System Arrangements Fig. 7 I-Beam Hardware Installation Fig.
- Page 6 GNB representa- DANGER! tive. Local conditions may introduce situations not covered by GNB Safety Precautions. If so, contact the nearest GNB rep- SULFURIC ACID ELECTROLYTE resentative for guidance with your particular safety problem;...
-
Page 7: Temperature Effects On Life
Any modifications, alterations or additions to an Absolyte GX system, without the expressed written consent of GNB’s Engineering, may void any warranties The storage interval from the date of battery shipment to the and/or seismic qualifications. Contact your GNB repre- date of installation and initial charge should not exceed six (6) sentative for additional information. -
Page 8: Typical System Spacing
TYPICAL SYSTEM SPACING (TOP VIEW) -
Page 9: Absolyte Gx Stacking Limitations
Temperature Variations DO NOT SELECT CABLE SIZE BASED ON CURRENT CAR- RYING CAPACITY ONLY. Cable size selection should provide no greater voltage drop between the battery system and operat- Sources of heat or cooling directed on portions of the battery can ing equipment than necessary. -
Page 10: Packaged Modules
SECTION 6: UNPACKING • Chalk line • Line Cord • Torpedo level (Plastic) • Plywood straight edge 1/2” x 4” x 48” • Torque wrenches (100 in-lbs, 35 ft-lbs) • Ratchet wrench with 10, 13, 17, 19 mm and 1/2 in. sockets •... -
Page 11: Handling Module
NOTE (for Figure 4): shipment for completeness before continuing further. The 1) Straps must be criss-crossed. Absolyte GX has a standard module configuration of two cells 2) Observe lifting shackle orientation and per module. Where application voltage requires, a module may proper channel hole use. -
Page 12: Tip-Over Procedure - Shackle-Strap Usage
Handling of Modules The module/I-beam assembly may now be removed from the pallet using methods outlined in Section 6.5. See Figures 4 and 5. Remaining modules may be removed in a similar manner. Tip Over Procedure In order to stack modules in the horizontal position, refer to Figures 9 through 11 to perform the tip-over procedure. -
Page 13: Handling And Stacking Horizontal Modules
chalk line floor mark should be used to assure all stacks will be in a straight line. This applies for stacks end-to-end or end-to-end and back-to-back. Refer to Sections 6.5 and 8.1.3 for handling and tip over procedures. For stacks end-to-end, module ends should be butted together so that module side channel ends meet (see Figure 17). -
Page 14: Stack Connections
8.3.3 Horizontal Stacking Connections - Inter-MODULE When all base modules are set in place, continue with stacking Consult layout/wiring diagram for correct quantity of lead-tin plat- of subsequent modules. Procedures for assembly of multiple copper connectors required each horizontal stacks are the same as outlined in section 8.1.3. Also connection. - Page 15 Benchmark values for connection resistances should also be established for terminal plates, where used, as well as cable The cover is then installed by grasping it so that the GNB logo is connections. Benchmark values should preferably be estab- upright. Locate slots at bottom of cover to the bottom standoff lished upon installation.
-
Page 16: Fig
BILL OF MATERIALS — TOP TERMINAL PLATE ASSEMBLY ITEM DESCRIPTION QTY PER SYSTEM PLATE, TOP TERMINAL BRACKET, TERMINAL SUPPORT LOCK WASHER, M10 FLAT WASHER, M10 NUT, M10 X .8D BOLT, M10 X 40 COVER, FRONT COVER, BACK NUT, M6 X .8D BOLT, M6 X 25 VARIES WASHER, M6... -
Page 17: Battery Operation
2.25 VPC on a 24-cell system, you would set the Modern constant voltage output charging equipment is recom- charger voltage to 54 volts. mended for the floating charger method of operation of GNB SECTION 13: BATTERY OPERATION Absolyte batteries. This type of charger, properly adjusted to the recommended float voltages and following recommended sur- 13.0... - Page 18 Install standoff legs and standoff keys to module channel as shown. The cover is then installed by grasp- ing it so that the GNB logo is upright. Locate slots at bottom of cover to bottom standoff legs and slide in place.
-
Page 19: Recharge
Do not use float voltages higher or lower than those recom- obtain the optimum service life from the battery, it is important to mended. Reduced capacity or battery life will result. make sure the battery’s float voltage is within the recommended range. -
Page 20: Equalizing Charge
If users wish to enhance normal maintenance and record-keep- shortest period of time (not to exceed 2.35 VPC applicable at ing with ohmic measurements, GNB recommends the trending 77°F, 25°C). Refer to Table E for voltages and recommended time of this data over time. Use a first set of readings taken 6 months periods. -
Page 21: Recordkeeping
If any cell parts appear to be damp with elec- requirements. trolyte or show signs of corrosion, contact your local GNB repre- • Individual cell voltages sentative. • Overall string voltage CAUTION! •... -
Page 22: Capacity Testing
All terminal and intercell connections should be retorqued at least once every year to 11.3 Newton-meters (100 inch pounds). NOTE: Design and/or specifications subject to change without notice. If questions arise, contact your local sales rep- resentative for clarification. SECTION 20: CAPACITY TESTING 20.0 Capacity Testing When a capacity discharge test is desired, it is recommended... - Page 23 Figure 22.1...
- Page 24 Figure 22.2...
-
Page 25: Temperature Corrected Float Voltages
APPENDIX A Temperature Corrected Float Voltages Expressed in Volts per Cell Float Voltage at 25°C Float Voltage at 77°F 2.23 2.24 2.25 2.26 2.27 2.23 2.24 2.25 2.26 2.27 2.35 2.30 2.31 2.32 2.33 2.34 2.35 2.35 2.29 2.30 2.31 2.32 2.33 2.34... -
Page 26: Maximum Storage Interval Between Freshening Charges
APPENDIX B MAXIMUM STORAGE INTERVAL BETWEEN FRESHENING CHARGES VERSUS AVERAGE STORAGE TEMPERATURE Maximum Storage Interval Maximum Storage Interval Months Days Months Days... - Page 27 APPENDIX C BONDING & GROUNDING OF BATTERY RACK INTRODUCTION 1. To insure personnel safety, and equipment protection, operation, and reliability, the battery rack should be connected to the Common Bonding Network (CBN). 2. Electrical continuity between modules is provided through the use of serrated hardware. Testing has shown that standard sys- tems are compliant with the GR-1089-CORE, Issue 4, Section 9 requirements of the Bonding and Grounding tests.
