- Page 1 S id e k i ck S MOK ER USER MANUAL AND MAINTENANCE FCC-G-19999 FOR OUTDOOR USE ONLY READ THE OPERATING INSTRUCTIONS BEFORE USING THE APPLIANCE!
-
Page 2: Table Of Contents
Table of content Parts List and Hardware ................4 Exploded Drawing ....................5 Assembly Instructions ..................6 Prepare Smoker for use ..................1 1 Maintenance ......................12 Tips when Cooking ...................13 Consumer Contact ..................14 SID E k ic k S M OKE R... - Page 3 Read carefully WARNING FOR YOUR SAFETY: • IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE INJURY OR PROPERTY DAMAGE. • READ THE INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING, USING OR SERVICING THIS APPLIANCE. • FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN FIRE OR EXPLOSION, WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH.
- Page 4 Sidekick Smoker is securely fastened to the side burner of your gas BBQ. Do not store items of interest to children near the Sidekick Smoker as it is very hot during operation and afterwards until the Sidekick Smoker sufficiently cooled.
-
Page 5: Parts List And Hardware
Parts list and hardware DELEOVERSIKT PART DESCRIPTION Body Main Door Guide Vent Grids Water Tray Wood Chip Tray lid Wood Chip Tray Lifter Heat Shield Magnetic Legs Securing Bolt Heat Indicator Logo Door Handle Door Latch PART DRAWING DESCRIPTION PART DRAWING DESCRIPTION Small phillips... -
Page 6: Exploded Drawing
Exploded Drawing MONTERING TOOLS REQUIRED FOR ASSEMBLY (not provided) Phillips Screwdriver and a Small Adjustable Wrench SI D E k ic k S MOKE R... - Page 7 (See Fig 2). Tighten with the nut supplied with the Heat Indicator. 2. Mount Sidekick Smoker Logo (14) in the bottom set of holes in the door. Tighten with the logo clips (E) (See Fig 2).
- Page 8 Heat Shield Find the Heat Shield (10) and mount to the bottom of the Sidekick Smoker with small bolt (A), small washer (B) and small hex nut (F) (see Fig. 5). Do not over tighten the Heat Shield as you may damage the porcelain finish (See Fig 3 or 4).
- Page 9 1. Set the Sidekick Smoker on your side burner. Position the magnetic legs (11) on the side burner so that the Sidekick Smoker is level. You may need a small level for accuracy (See Fig 8). If the Sidekick Smoker position is not level, move the magnetic legs along the “L”...
- Page 10 1. Slide water tray (6) onto the 2nd Guides (3). (See Fig 13) 2. The water tray can be removed with the lifter (9). NOTE: ALLOW THE SIDEKICK SMOKER SMOKER AND ALL COMPONENTS TO COOL COMPLETELY BEFORE HANDLING Cooking Grids 1.
- Page 11 Assembly KLARGJØRING FØR BRUK Adjustable Guides 1. Note that the Sidekick Smoker comes with an extra cooking grid position located in the upper section of the appliance to accommodate many methods of cooking. Simply remove the 4 bolts from the upper section (See Fig 15).
-
Page 12: Prepare Smoker For Use
BEFORE USE: “Seasoning” the Sidekick Smoker should be done before the first time you use it. Apply a thin coat of cooking oil, any kind will do, to the inside including the grids. Turn on to medium heat and open the vents so they are 2/3 open. Leave on for 1 hour. You should not have to “season”... -
Page 13: Tips When Cooking
Oppvarming: Den beste løsningen for matlaging til mange mennesker! Sidekick Smoker holder alt varmt og fungerer ypperlig som et varmeskap når du har grillfest til mange mennesker. Enten det er å holde ribs, steken eller pølsene varme, eller om det rett og slett er for å varme tallerknene før servering. -
Page 14: Consumer Contact
Always attach your receipt when making a warranty claim. Produced in China for FCC Products Co., Ltd. We are always looking for ways we can improve our products. Therefore, we reserve the right to change technical specifications at any time. You will always find the latest manual on www.fccproducts.no.
