FCC Part 15
EMI TEST REPORT
E.U.T.
MODEL
FCC ID
Frequency Range : 2433MHz~2473MHz
APPLICANT : Sennheiser Electric Corp.
ADDRESS
ELECTRONICS TESTING CENTER, TAIWAN
NO. 34. LIN 5, DINGFU VIL., LINKOU DIST.,
NEW TAIPEI CITY, TAIWAN, 24442, R.O.C.
TEL : (02)26023052
http ： // www.etc.org.tw; e-mail ： emc@etc.org.tw
of
: XS WIRELESS
: EM-XSW2
: DMOEMXSW2
for
: 1 Enterprise Drive, Old Lyme, CT 06371, USA
Test Performed by
Report Number : 16-11-RBF-029-01
FAX: (02)26010910
I
